|1
6261-31-1200
CRANKSHAFT ASS'Y
SN: 530043-UP
1шт.
1
0
CRANKSHAFT
SN: 530043-UP
1шт.
2
6150-31-1130
KEY
SN: 530043-UP
1шт.
3
6210-31-1120
GEAR,CRANK
SN: 530043-UP
1шт.
4
6211-31-1420
PIN
SN: 530043-UP
1шт.
|5
6261-21-8000
METAL ASS'Y
SN: 530043-UP
1шт.
|5
6261-21-8010
MAIN METAL ASS'Y,STANDARD
SN: 530043-UP
7шт.
|5
6261-29-8010
MAIN METAL ASS'Y,UNDERSIZE 0.25MM
SN: 530043-UP
7шт.
|5
6261-28-8010
MAIN METAL ASS'Y,UNDERSIZE 0.50MM
SN: 530043-UP
7шт.
|5
6261-27-8010
MAIN METAL ASS'Y,UNDERSIZE 0.75MM
SN: 530043-UP
7шт.
|5
6261-26-8010
MAIN METAL ASS'Y,UNDERSIZE 1.00MM
SN: 530043-UP
7шт.
5
0
METAL,UPPER¤ STANDARD
SN: 530043-UP
1шт.
|5
0
METAL,UPPER¤ UNDERSIZE 0.25MM
SN: 530043-UP
1шт.
|5
0
METAL,UPPER¤ UNDERSIZE 0.50MM
SN: 530043-UP
1шт.
|5
0
METAL,UPPER¤ UNDERSIZE 0.75MM
SN: 530043-UP
1шт.
|5
0
METAL,UPPER¤ UNDERSIZE 1.00MM
SN: 530043-UP
1шт.
6
0
METAL,LOWER¤ STANDARD
SN: 530043-UP
1шт.
|6
0
METAL,LOWER¤ UNDERSIZE 0.25MM
SN: 530043-UP
1шт.
|6
0
METAL,LOWER¤ UNDERSIZE 0.50MM
SN: 530043-UP
1шт.
|6
0
METAL,LOWER¤ UNDERSIZE 0.75MM
SN: 530043-UP
1шт.
|6
0
METAL,LOWER¤ UNDERSIZE 1.00MM
SN: 530043-UP
1шт.
7
6210-21-8050
THRUST METAL ASS'Y,STANDARD
SN: 530043-UP
1шт.
|7
6210-29-8050
THRUST METAL ASS'Y,OVERSIZE 0.25MM
SN: 530043-UP
1шт.
|7
6210-28-8050
THRUST METAL ASS'Y,OVERSIZE 0.50MM
SN: 530043-UP
1шт.
|7
6210-27-8050
THRUST METAL ASS'Y,OVERSIZE 0.75MM
SN: 530043-UP
1шт.
|7
6210-26-8050
THRUST METAL ASS'Y,OVERSIZE 1.00MM
SN: 530043-UP
1шт.
|7
0
METAL,THRUST¤ STANDARD
SN: 530043-UP
3шт.
|7
0
METAL,THRUST¤ OVERSIZE 0.25MM
SN: 530043-UP
3шт.
|7
0
METAL,THRUST¤ OVERSIZE 0.50MM
SN: 530043-UP
3шт.
|7
0
METAL,THRUST¤ OVERSIZE 0.75MM
SN: 530043-UP
3шт.
|7
0
METAL,THRUST¤ OVERSIZE 1.00MM
SN: 530043-UP
3шт.
8
04020-01228
PIN,DOWEL
SN: 530043-UP
1шт.
