Запчасти Komatsu SAA6D140E-5D ПОРШЕНЬ И ШАТУН(№-) ДВИГАТЕЛЬ БЛОК ЦИЛИНДРОВ И ITS КОМПОНЕНТЫ

1

6261-31-2130

Piston

SN: 530015-UP

6шт.

2

6211-31-2410

Pin, Piton

SN: 530015-UP

6шт.

3

04065-05220

Ring, Snap

SN: 530015-UP

12шт.

|3

6261-31-2030

Ring Assembly, Piston

SN: 530015-UP

6шт.

4

Ring, Top

SN: 530015-UP

1шт.

5

Ring, Second

SN: 530015-UP

1шт.

6

Ring, Oil

SN: 530015-UP

1шт.

|6

6261-31-3100

Rod Assembly, Connecting

SN: 530015-UP

6шт.

7

Rod, Connecting

SN: 530015-UP

1шт.

8

Cap, Connecting Rod

SN: 530015-UP

1шт.

9

6261-31-3140

Bushing

SN: 530015-UP

1шт.

10

6210-31-3310

Bolt

SN: 530015-UP

2шт.

11

02400-10413

Pin, Dowel

SN: 530015-UP

2шт.

|11

6210-32-3040

Metal Assembly, Standard

SN: 530015-UP

6шт.

|11

6210-39-3042

Metal Assembly, Undersize 0.25mm

SN: 530015-UP

6шт.

|11

6210-38-3042

Metal Assembly, Undersize 0.50mm

SN: 530015-UP

6шт.

|11

6210-37-3042

Metal Assembly, Undersize 0.75mm

SN: 530015-UP

6шт.

|11

6210-36-3042

Metal Assembly, Undersize 1.00mm

SN: 530015-UP

6шт.

12

Metal, Lower Standard

SN: 530015-UP

1шт.

|12

Metal, Lower Undersize 0.25mm

SN: 530015-UP

1шт.

|12

Metal, Lower Undersize 0.50mm

SN: 530015-UP

1шт.

|12

Metal, Lower Undersize 0.75mm

SN: 530015-UP

1шт.

|12

Metal, Lower Undersize 1.00mm

SN: 530015-UP

1шт.

13

Metal, Upper Undersize

SN: 530015-UP

1шт.

|13

Metal, Upper Undersize 0.25mm

SN: 530015-UP

1шт.

|13

Metal, Upper Undersize 0.50mm

SN: 530015-UP

1шт.

|13

Metal, Upper Undersize 0.75mm

SN: 530015-UP

1шт.

|13

Metal, Upper Undersize 1.00mm

SN: 530015-UP

1шт.
