1
6217-11-1610
Bolt, Head
SN: 530015-UP
18шт.
2
6217-11-1620
Bolt, Head
SN: 530015-UP
18шт.
3
6210-17-1814
Gasket, Head
SN: 530015-UP
6шт.
|3
6210-11-1820
Grommet, Oil
SN: 530015-UP
1шт.
|3
6210-11-1831
Grommet, Oil
SN: 530015-UP
1шт.
|3
6210-11-1840
Grommet, Oil
SN: 530015-UP
1шт.
|3
6210-11-1962
Grommet, Water
SN: 530015-UP
1шт.
|3
6210-11-1952
Grommet, Water
SN: 530015-UP
4шт.
|3
6210-11-1940
Grommet, Water
SN: 530015-UP
4шт.
4
6210-41-5620
Crosshead
SN: 530015-UP
12шт.
5
6210-41-5641
Screw
SN: 530015-UP
12шт.
6
6162-43-5630
Nut, Lock
SN: 530015-UP
12шт.
7
6136-41-4520
Cotter, Valve
SN: 530015-UP
48шт.
8
6210-11-1140
Guide, Crosshead
SN: 530015-UP
12шт.
9
6210-41-4430
Spring, Outer
SN: 530015-UP
24шт.
10
6210-41-4440
Spring, Inner
SN: 530015-UP
24шт.
11
6210-41-4510
Seat, Upper
SN: 530015-UP
24шт.
12
6215-41-4220
Valve, Exhaust
SN: 530015-UP
12шт.
13
6217-41-4110
Valve, Intake
SN: 530015-UP
12шт.
14
6217-41-4531
Seat, Lower
SN: 530015-UP
24шт.
15
6217-41-4540
Valve, Seal
SN: 530015-UP
24шт.
|15
6261-11-1100
Cylinder Head Assembly
SN: 530015-UP
6шт.
16
Head, Cylinder
SN: 530015-UP
1шт.
17
6216-11-1330
Insert, Intake Valve Standard
SN: 530015-UP
2шт.
|17
6216-19-1330
Insert, Intake Valve Oversize 0.25mm
SN: 530015-UP
2шт.
|17
6216-18-1330
Insert, Intake Valve Oversize 0.50mm
SN: 530015-UP
2шт.
|17
6216-17-1330
Insert, Intake Valve Oversize 0.75mm
SN: 530015-UP
2шт.
|17
6216-16-1330
Insert, Intake Valve Oversize 1.00mm
SN: 530015-UP
2шт.
18
6217-11-1321
Insert, Exhaust Valve Standard
SN: 530015-UP
2шт.
|18
6217-19-1321
Insert, Exhaust Valve Oversize 0.25mm
SN: 530015-UP
2шт.
|18
6217-18-1321
Insert, Exhaust Valve Oversize 0.50mm
SN: 530015-UP
2шт.
|18
6217-17-1321
Insert, Exhaust Valve Oversize 0.75mm
SN: 530015-UP
2шт.
|18
6217-16-1321
Insert, Exhaust Valve Oversize 1.00mm
SN: 530015-UP
2шт.
19
6217-16-1440
Guide, Valve
SN: 530015-UP
4шт.
20
6210-11-1150
Pipe
SN: 530015-UP
1шт.
21
07000-73025
O-ring
SN: 530015-UP
1шт.
22
6162-13-1150
Plug, Expansion
SN: 530015-UP
13шт.
23
07043-50108
Plug
SN: 530015-UP
1шт.
24
708-21-12541
Plug
SN: 530015-UP
2шт.
25
01438-01020
Bolt
SN: 530015-UP
6шт.
26
01643-51645
Washer
SN: 530015-UP
36шт.
