|1
6261-31-1200
Crankshaft Assembly
SN: 530019-UP
1шт.
1
6261-31-1210
Crankshaft
SN: 530019-UP
1шт.
2
6150-31-1130
Key
SN: 530019-UP
1шт.
3
6210-31-1120
Gear, Crank
SN: 530019-UP
1шт.
4
6211-31-1420
Pin
SN: 530019-UP
1шт.
|5
6261-21-8000
Metal Assembly
SN: 530019-UP
1шт.
|5
6261-21-8010
Metal Assembly, Main Standard
SN: 530019-UP
7шт.
|5
6261-29-8010
Metal Assembly, Main Undersize 0.25mm
SN: 530019-UP
7шт.
|5
6261-28-8010
Metal Assembly, Main Undersize 0.50mm
SN: 530019-UP
7шт.
|5
6261-27-8010
Metal Assembly, Main Undersize 0.75mm
SN: 530019-UP
7шт.
|5
6261-26-8010
Metal Assembly, Main Undersize 1.00mm
SN: 530019-UP
7шт.
5
6210-21-8110
Metal, Upper Standard
SN: 530019-UP
1шт.
|5
6210-29-8110
Metal, Upper Undersize 0.25mm
SN: 530019-UP
1шт.
|5
6210-28-8110
Metal, Upper Undersize 0.50mm
SN: 530019-UP
1шт.
|5
6210-27-8110
Metal, Upper Undersize 0.75mm
SN: 530019-UP
1шт.
|5
6210-26-8110
Metal, Upper Undersize 1.00mm
SN: 530019-UP
1шт.
6
6218-21-8120
Metal, Lower Standard
SN: 530019-UP
1шт.
|6
6218-29-8120
Metal, Lower Undersize 0.25mm
SN: 530019-UP
1шт.
|6
6218-28-8120
Metal, Lower Undersize 0.50mm
SN: 530019-UP
1шт.
|6
6218-27-8120
Metal, Lower Undersize 0.75mm
SN: 530019-UP
1шт.
|6
6218-26-8120
Metal, Lower Undersize 1.00mm
SN: 530019-UP
1шт.
7
6210-21-8050
Metal Assembly, Thrust Standard
SN: 530019-UP
1шт.
|7
6210-29-8050
Metal Assembly, Thrust Oversize 0.25mm
SN: 530019-UP
1шт.
|7
6210-28-8050
Metal Assembly, Thrust Oversize 0.50mm
SN: 530019-UP
1шт.
|7
6210-27-8050
Metal Assembly, Thrust Oversize 0.75mm
SN: 530019-UP
1шт.
|7
6210-26-8050
Metal Assembly, Thrust Oversize 1.00mm
SN: 530019-UP
1шт.
|7
6210-21-8210
Metal, Thrust Standard
SN: 530019-UP
3шт.
|7
6210-29-8210
Metal, Thrust Oversize 0.25mm
SN: 530019-UP
3шт.
|7
6210-28-8210
Metal, Thrust Oversize 0.50mm
SN: 530019-UP
3шт.
|7
6210-27-8210
Metal, Thrust Oversize 0.75mm
SN: 530019-UP
3шт.
|7
6210-26-8210
Metal, Thrust Oversize 1.00mm
SN: 530019-UP
3шт.
8
04020-01228
Pin
SN: 530019-UP
1шт.
