Запчасти Komatsu SAA6D140E-5B КОЛЕНВАЛ(№9-) ДВИГАТЕЛЬ БЛОК ЦИЛИНДРОВ И ITS КОМПОНЕНТЫ

|1

6261-31-1200

Crankshaft Assembly

SN: 530019-UP

1шт.

1

6261-31-1210

Crankshaft

SN: 530019-UP

1шт.

2

6150-31-1130

Key

SN: 530019-UP

1шт.

3

6210-31-1120

Gear, Crank

SN: 530019-UP

1шт.

4

6211-31-1420

Pin

SN: 530019-UP

1шт.

|5

6261-21-8000

Metal Assembly

SN: 530019-UP

1шт.

|5

6261-21-8010

Metal Assembly, Main Standard

SN: 530019-UP

7шт.

|5

6261-29-8010

Metal Assembly, Main Undersize 0.25mm

SN: 530019-UP

7шт.

|5

6261-28-8010

Metal Assembly, Main Undersize 0.50mm

SN: 530019-UP

7шт.

|5

6261-27-8010

Metal Assembly, Main Undersize 0.75mm

SN: 530019-UP

7шт.

|5

6261-26-8010

Metal Assembly, Main Undersize 1.00mm

SN: 530019-UP

7шт.

5

6210-21-8110

Metal, Upper Standard

SN: 530019-UP

1шт.

|5

6210-29-8110

Metal, Upper Undersize 0.25mm

SN: 530019-UP

1шт.

|5

6210-28-8110

Metal, Upper Undersize 0.50mm

SN: 530019-UP

1шт.

|5

6210-27-8110

Metal, Upper Undersize 0.75mm

SN: 530019-UP

1шт.

|5

6210-26-8110

Metal, Upper Undersize 1.00mm

SN: 530019-UP

1шт.

6

6218-21-8120

Metal, Lower Standard

SN: 530019-UP

1шт.

|6

6218-29-8120

Metal, Lower Undersize 0.25mm

SN: 530019-UP

1шт.

|6

6218-28-8120

Metal, Lower Undersize 0.50mm

SN: 530019-UP

1шт.

|6

6218-27-8120

Metal, Lower Undersize 0.75mm

SN: 530019-UP

1шт.

|6

6218-26-8120

Metal, Lower Undersize 1.00mm

SN: 530019-UP

1шт.

7

6210-21-8050

Metal Assembly, Thrust Standard

SN: 530019-UP

1шт.

|7

6210-29-8050

Metal Assembly, Thrust Oversize 0.25mm

SN: 530019-UP

1шт.

|7

6210-28-8050

Metal Assembly, Thrust Oversize 0.50mm

SN: 530019-UP

1шт.

|7

6210-27-8050

Metal Assembly, Thrust Oversize 0.75mm

SN: 530019-UP

1шт.

|7

6210-26-8050

Metal Assembly, Thrust Oversize 1.00mm

SN: 530019-UP

1шт.

|7

6210-21-8210

Metal, Thrust Standard

SN: 530019-UP

3шт.

|7

6210-29-8210

Metal, Thrust Oversize 0.25mm

SN: 530019-UP

3шт.

|7

6210-28-8210

Metal, Thrust Oversize 0.50mm

SN: 530019-UP

3шт.

|7

6210-27-8210

Metal, Thrust Oversize 0.75mm

SN: 530019-UP

3шт.

|7

6210-26-8210

Metal, Thrust Oversize 1.00mm

SN: 530019-UP

3шт.

8

04020-01228

Pin

SN: 530019-UP

1шт.
