1
6217-11-1610
BOLT, HEAD
SN: 530001-UP
18шт.
2
6217-11-1620
BOLT, HEAD
SN: 530001-UP
18шт.
|$3
STANDARD
-1шт.
3
6210-17-1814
GASKET, HEAD
SN: 530001-UP
6шт.
|3
6210-11-1820
GROMMET, OIL
SN: 530001-UP
1шт.
|3
6210-11-1831
GROMMET, OIL
SN: 530001-UP
1шт.
|3
6210-11-1840
GROMMET, OIL
SN: 530001-UP
1шт.
|3
6210-11-1962
GROMMET, WATER
SN: 530001-UP
1шт.
|3
0
GROMMET, WATER
SN: 530001-UP
4шт.
|3
6210-11-1940
GROMMET, WATER
SN: 530001-UP
4шт.
|$11
OVERSIZE 0.4MM
-1шт.
3
6210-19-1814
GASKET, HEAD
SN: 530001-UP
6шт.
|3
6210-19-1820
GROMMET, OIL
SN: 530001-UP
1шт.
|3
6210-19-1831
GROMMET, OIL
SN: 530001-UP
1шт.
|3
6210-19-1840
GROMMET, OIL
SN: 530001-UP
1шт.
|3
6210-19-1962
GROMMET, WATER
SN: 530001-UP
1шт.
|3
0
GROMMET, WATER
SN: 530001-UP
4шт.
|3
6210-19-1940
GROMMET, WATER
SN: 530001-UP
4шт.
4
6210-41-5620
CROSSHEAD
SN: 530001-UP
12шт.
5
6210-41-5641
SCREW
SN: 530001-UP
12шт.
6
6162-43-5630
NUT, LOCK
SN: 530001-UP
12шт.
7
6136-41-4520
COTTER, VALVE
SN: 530001-UP
48шт.
8
6210-11-1140
GUIDE, CROSSHEAD
SN: 530001-UP
12шт.
9
6210-41-4430
SPRING, OUTER
SN: 530001-UP
24шт.
10
6210-41-4440
SPRING, INNER
SN: 530001-UP
24шт.
11
6210-41-4510
SEAT, UPPER
SN: 530001-UP
24шт.
12
6215-41-4220
VALVE, EXHAUST
SN: 530001-UP
12шт.
13
6217-41-4110
VALVE, INTAKE
SN: 530001-UP
12шт.
14
6217-41-4531
SEAT, LOWER
SN: 530001-UP
24шт.
15
6217-41-4540
SEAL
SN: 530001-UP
24шт.
|16
6261-11-1100
CYLINDER HEAD ASSEMBLY
SN: 530001-UP
6шт.
16
0
HEAD, CYLINDER
SN: 530001-UP
1шт.
17
6216-11-1330
INSERT, INTAKE VALVE (STD)
SN: 530001-UP
2шт.
|17
6216-19-1330
INSERT, 0.25MM, INTAKE VALVE (OS)
SN: 530001-UP
2шт.
|17
6216-18-1330
INSERT, 0.50MM, INTAKE VALVE (OS)
SN: 530001-UP
2шт.
|17
6216-17-1330
INSERT, 0.75MM, INTAKE VALVE (OS)
SN: 530001-UP
2шт.
|17
6216-16-1330
INSERT, 1.00MM, INTAKE VALVE (OS)
SN: 530001-UP
2шт.
18
6217-11-1321
INSERT, EXHAUST VALVE (STD)
SN: 530001-UP
2шт.
|18
6217-19-1321
INSERT, 0.25MM, EXHAUST VALVE (OS)
SN: 530001-UP
2шт.
|18
6217-18-1321
INSERT, 0.50MM, EXHAUST VALVE (OS)
SN: 530001-UP
2шт.
|18
6217-17-1321
INSERT, 0.75MM, EXHAUST VALVE (OS)
SN: 530001-UP
2шт.
|18
6217-16-1321
INSERT, 1.00MM, EXHAUST VALVE (OS)
SN: 530001-UP
2шт.
19
6217-16-1441
GUIDE, VALVE
SN: 530001-UP
4шт.
20
6210-11-1150
PIPE
SN: 530001-UP
1шт.
21
07000-73025
O-RING
SN: 530001-UP
1шт.
22
6162-13-1150
PLUG, EXPANSION
SN: 530001-UP
13шт.
23
07043-50108
PLUG
SN: 530001-UP
1шт.
24
708-21-12541
PLUG
SN: 530001-UP
2шт.
25
01438-01020
BOLT
SN: 530001-UP
6шт.
26
01643-51645
WASHER
SN: 530001-UP
36шт.
