2
6218-K2-9900
GASKET KIT,CYLINDER BLOCK
SN: 110003-UP
1шт.
2
07000-72025
O-RING,(SEE FIG.A2010)
SN: 110003-UP
1шт.
2
07000-72021
O-RING,(SEE FIG.A2010)
SN: 110003-UP
1шт.
2
6210-21-2270
SEAL,CREVICE (SEE FIG.A2010)
SN: 110003-UP
6шт.
2
6210-21-2240
O-RING,LINER (SEE FIG.A2010)
SN: 110003-UP
6шт.
2
6210-21-2230
O-RING,LINER (SEE FIG.A2010)
SN: 110003-UP
6шт.
2
6210-21-1971
GASKET,(SEE FIG.A2011)
SN: 110003-UP
1шт.
2
6696-61-9921
GASKET,(SEE FIG.A2011)
SN: 110003-UP
1шт.
2
07000-73040
O-RING,(SEE FIG.A2011)
SN: 110003-UP
2шт.
2
07000-73025
O-RING,(SEE FIG.A2011)
SN: 110003-UP
3шт.
2
6711-21-3521
SEAL, FRONT,(SEE FIG.A2040)
SN: 110003-UP
1шт.
2
07005-01212
GASKET,(SEE FIG.A2041)
SN: 110003-UP
2шт.
2
07000-72060
O-RING,(SEE FIG.A2041)
SN: 110003-UP
1шт.
2
6210-21-6860
O-RING,(SEE FIG.A2060)
SN: 110003-UP
3шт.
2
6210-21-5820
GASKET,(SEE FIG.A2110)
SN: 110003-UP
1шт.
2
07000-73028
O-RING,(SEE FIG.A2110)
SN: 110003-UP
1шт.
2
07000-73040
O-RING,(SEE FIG.A2110)
SN: 110003-UP
1шт.
2
6151-21-4150
SEAL, REAR,(SEE FIG.A2210)
SN: 110003-UP
1шт.
2
07005-02216
GASKET,(SEE FIG.A2210)
SN: 110003-UP
1шт.
2
07000-73038
O-RING,(SEE FIG.A3010)
SN: 110003-UP
1шт.
2
07000-73040
O-RING,(SEE FIG.A3110)
SN: 110003-UP
2шт.
2
07000-73025
O-RING,(SEE FIG.A3110)
SN: 110003-UP
2шт.
2
6210-61-2520
O-RING,(SEE FIG.A3310)
SN: 110003-UP
2шт.
2
6150-61-2520
O-RING,(SEE FIG.A3310)
SN: 110003-UP
4шт.
2
07000-63042
O-RING,(SEE FIG.A3310)
SN: 110003-UP
1шт.
2
6210-61-2550
O-RING,(SEE FIG.A3310)
SN: 110003-UP
1шт.
2
07005-01412
GASKET,(SEE FIG.A3310)
SN: 110003-UP
1шт.
2
6210-61-2811
GASKET,(SEE FIG.A3310)
SN: 110003-UP
1шт.
2
07005-01412
GASKET,(SEE FIG.A4010)
SN: 110003-UP
2шт.
2
07005-01412
GASKET,(NOT SHOWN) (SEE FIG.A4010)
SN: 110003-UP
10шт.
2
07005-01412
GASKET,(SEE FIG.A4110)
SN: 110003-UP
4шт.
2
07005-01212
GASKET,(SEE FIG.A4230)
SN: 110003-UP
2шт.
2
07005-01412
GASKET,(SEE FIG.A4230)
SN: 110003-UP
2шт.
2
6210-61-6870
GASKET,(SEE FIG.A5010)
SN: 110003-UP
1шт.
2
07003-01015
GASKET,(SEE FIG.A5010)
SN: 110003-UP
1шт.
2
6210-61-6421
GASKET,(SEE FIG.A5010)
SN: 110003-UP
1шт.
2
6162-13-6440
SEAL,(SEE FIG.A5010)
SN: 110003-UP
2шт.
2
6210-61-6441
GASKET,(SEE FIG.A5010)
SN: 110003-UP
1шт.
2
07005-01412
GASKET,(SEE FIG.A5210)
SN: 110003-UP
8шт.
2
6221-81-6810
GASKET,(SEE FIG.A6210)
SN: 110003-UP
1шт.
|$$41
THE FOLLOWING PARTS ARE NOT USED FOR THIS MODEL.
-1шт.
2
6150-21-1190
O-RING
SN: 110003-UP
1шт.
2
07000-73025
O-RING
SN: 110003-UP
1шт.
2
07005-01412
GASKET
SN: 110134-UP
1шт.
2
07000-03050
O-RING
SN: 110003-UP
1шт.
2
07000-72070
O-RING
SN: 110134-UP
1шт.
2
07000-72055
O-RING
SN: 110134-UP
1шт.
2
6150-21-6391
PACKING
SN: 110003-UP
9шт.
2
07005-02216
GASKET
SN: 110003-UP
1шт.
2
6136-21-5870
GASKET
SN: 110003-UP
1шт.
2
07002-23634
O-RING
SN: 110430-UP
1шт.
2
6151-21-4160
SEAL, REAR
SN: 110003-UP
1шт.
2
07000-02060
O-RING
SN: 110003-UP
1шт.
2
07000-73039
O-RING
SN: 110003-UP
2шт.
2
07000-72045
O-RING
SN: 110430-UP
1шт.
2
07000-72060
O-RING
SN: 110430-UP
1шт.
2
ND094086-0210
O-RING
SN: 110003-UP
1шт.
2
07000-E2015
O-RING
SN: 110003-UP
6шт.
2
07005-01412
GASKET
SN: 110134-UP
12шт.
|$$60
THE FOLLOWING PARTS ARE THE PARTS NOT INCLUDED IN THE GASKET KIT.
-1шт.
2
6150-21-1150
O-RING,(SEE FIG.A2011)
SN: 111534-UP
1шт.
2
07000-03025
O-RING,(SEE FIG.A2011)
SN: 111534-UP
1шт.
2
6217-21-3250
GASKET,(SEE FIG.A2041)
SN: 110003-UP
1шт.
2
07000-73050
O-RING,(SEE FIG.A2041)
SN: 111534-UP
1шт.
2
6136-11-8180
PACKING,(SEE FIG.A2060)
SN: 111534-UP
9шт.
2
6221-81-6810
GASKET,(SEE FIG.A6210)
SN: 111534-UP
1шт.
