2
6218-K2-9900
GASKET KIT,CYLINDER BLOCK
SN: 110003-UP
1шт.
|2
07000-72025
O-RING,(SEE FIG.A2010)
SN: 110003-UP
1шт.
|2
07000-72021
O-RING,(SEE FIG.A2010)
SN: 110003-UP
1шт.
|2
6210-21-2270
SEAL,CREVICE (SEE FIG.A2010)
SN: 110003-UP
6шт.
|2
6210-21-2240
O-RING,LINER (SEE FIG.A2010)
SN: 110003-UP
6шт.
|2
6210-21-2230
O-RING,LINER (SEE FIG.A2010)
SN: 110003-UP
6шт.
|2
6210-21-1971
GASKET,(SEE FIG.A2011)
SN: 110003-UP
1шт.
|2
6150-21-1190
O-RING,(SEE FIG.A2011)
SN: 110003-UP
1шт.
|2
6696-61-9921
GASKET,(SEE FIG.A2011)
SN: 110003-UP
1шт.
|2
07000-73040
O-RING,(SEE FIG.A2011)
SN: 110003-UP
2шт.
|2
07000-73025
O-RING,(SEE FIG.A2011)
SN: 110003-UP
4шт.
|2
07000-73034
O-RING,(FOR PC750-6) (SEE FIG.A2011)
SN: 110003-UP
1шт.
|2
07005-01412
GASKET,(FOR PC1800E-6)(SEE FIG.A2011)
SN: 110134-UP
1шт.
|2
07000-73034
O-RING,(SEE FIG.A2011)
SN: 110812-UP
1шт.
|2
6711-21-3521
SEAL¤ FRONT,(SEE FIG.A2040)
SN: 110003-UP
1шт.
|2
6217-21-3250
GASKET,(SEE FIG.A2041)
SN: 110003-UP
1шт.
|2
07000-03050
O-RING,(SEE FIG.A2041)
SN: 110003-UP
1шт.
|2
07005-01212
GASKET,(SEE FIG.A2041)
SN: 110003-UP
2шт.
|2
07000-72060
O-RING,(HD325¤HM400¤PC750¤800)(A2041)
SN: 110003-UP
1шт.
|2
07000-72070
O-RING,(FOR PC1800E-6)(SEE FIG.A2041)
SN: 110134-UP
1шт.
|2
07000-72055
O-RING,(FOR PC1800E-6)(SEE FIG.A2041)
SN: 110134-UP
1шт.
|2
6210-21-6860
O-RING,(SEE FIG.A2060)
SN: 110003-UP
3шт.
|2
6150-21-6391
PACKING,(SEE FIG.A2060)
SN: 110003-UP
9шт.
|2
6210-21-5820
GASKET,(SEE FIG.A2110)
SN: 110003-UP
1шт.
|2
07000-73028
O-RING,(FOR HD325-6¤HM400-1) (A2110)
SN: 110003-UP
1шт.
|2
07005-02216
GASKET,(FOR PC750-6) (SEE FIG.A2110)
SN: 110003-112098
1шт.
|2
6136-21-5870
GASKET,(FOR HD325-6) (SEE FIG.A2110)
SN: 110003-UP
1шт.
|2
07002-23634
O-RING,(FOR WT800E-1) (SEE FIG.A2110)
SN: 110430-UP
1шт.
|2
07000-73040
O-RING,(SEE FIG.A2110)
SN: 110003-UP
1шт.
|2
6151-21-4150
SEAL¤ REAR,(FOR HD325-6¤HM400-1) (A2210)
SN: 110003-UP
1шт.
|2
6151-21-4160
SEAL¤ REAR,(FOR PC750-6) (SEE FIG.A2210)
SN: 110003-UP
1шт.
|2
07005-02216
GASKET,(SEE FIG.A2210)
SN: 110003-UP
1шт.
|2
07000-02060
O-RING,(FOR PC750¤800¤1800) (A2610)
SN: 110003-UP
1шт.
|2
07000-73038
O-RING,(SEE FIG.A3010)
SN: 110003-UP
1шт.
|2
07000-73040
O-RING,(FOR HD325-6¤HM400-1) (A3110)
SN: 110003-UP
2шт.
|2
07000-73025
O-RING,(FOR HD325-6¤HM400-1) (A3110)
SN: 110003-UP
2шт.
|2
07000-73039
O-RING,(FOR PC1800E-6)(SEE FIG.A3110)
SN: 110003-UP
2шт.
|2
07000-72045
O-RING,(FOR WT800E-1) (SEE FIG.A3110)
SN: 110430-UP
1шт.
|2
07000-73025
O-RING,(FOR PC1800E-6)(SEE FIG.A3110)
SN: 110003-UP
2шт.
|2
07000-72060
O-RING,(FOR WT800E-1) (SEE FIG.A3110)
SN: 110430-UP
1шт.
|2
6210-61-2520
O-RING,(SEE FIG.A3310)
SN: 110003-UP
2шт.
|2
6150-61-2520
O-RING,(SEE FIG.A3310)
SN: 110003-UP
4шт.
|2
07000-63042
O-RING,(SEE FIG.A3310)
SN: 110003-UP
1шт.
|2
6150-61-2540
SEAL,(SEE FIG.A3310)
SN: 110003-UP
1шт.
|2
6210-61-2550
O-RING,(SEE FIG.A3310)
SN: 110003-UP
1шт.
|2
6210-61-2811
GASKET,(SEE FIG.A3310)
SN: 110003-UP
1шт.
|2
07005-01412
GASKET,(SEE FIG.A3310)
SN: 110003-UP
1шт.
|$$48
THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|2
ND094086-0210
O-RING,(SEE FIG.A4010)
SN: 110003-UP
1шт.
|2
07005-01412
GASKET,(SEE FIG.A4010)
SN: 110003-UP
2шт.
|2
07005-01412
GASKET,(NOT SHOWN) (SEE FIG.A4010)
SN: 110003-UP
10шт.
|2
07000-E2015
O-RING,(SEE FIG.A4030)
SN: 110003-UP
6шт.
|2
07005-01412
GASKET,(SEE FIG.A4060)
SN: 110003-UP
2шт.
|2
07005-01412
GASKET,(SEE FIG.A4110)
SN: 110003-UP
4шт.
|2
07005-01212
GASKET,(SEE FIG.A4230)
SN: 110003-UP
2шт.
|2
07005-01412
GASKET,(SEE FIG.A4230)
SN: 110003-UP
2шт.
|2
6210-61-6870
GASKET,(FOR HD325-6¤HM400-1) (A5010)
SN: 110003-UP
1шт.
|2
07003-01015
GASKET,(FOR HM400-1) (SEE FIG.A5010)
SN: 110003-UP
1шт.
|2
6210-61-6421
GASKET,(SEE FIG.A5010)
SN: 110003-UP
1шт.
|2
6162-13-6440
SEAL,(SEE FIG.A5010)
SN: 110003-UP
2шт.
|2
6210-61-6441
GASKET,(FOR HD325¤HM400¤WT800)(A5010)
SN: 110003-UP
1шт.
|2
07005-01412
GASKET,(SEE FIG.A5210)
SN: 110003-UP
8шт.
|2
07005-01412
GASKET,(FOR PC1800E-6)(SEE FIG.A5210)
SN: 110134-UP
12шт.
|2
6221-81-6810
GASKET,(SEE FIG.A6210)
SN: 110003-UP
1шт.
|$$65
THE FOLLOWING PARTS ARE THE PARTS NOT INCLUDED IN THE GASKET KIT.
-1шт.
|2
6217-21-5660
GASKET
SN: 112099-UP
1шт.
