Запчасти Komatsu SAA6D125E-5F ТОПЛИВН. НАСОС, ВНУТР. ЧАСТИ, НАСОС (/) (№7-) ТОПЛИВН. НАСОС

|$0

6251-71-1121

Pump Assembly, Fuel Injection

SN: 567336-UP

1шт.

|$1

ND094100-0460

Body Assembly

SN: 560001-UP

1шт.

1

ND094110-0210

Housing Assembly

SN: 560001-UP

1шт.

2

ND094040-0370

Element Assembly

SN: 567336-UP

2шт.

3

ND094086-0090

O-ring

SN: 560001-UP

2шт.

4

ND094140-0040

Valve Assembly

SN: 560001-UP

2шт.

5

ND094086-0100

O-ring

SN: 560001-UP

4шт.

6

ND949013-5880

Washer

SN: 560001-UP

4шт.

7

ND92156-08081

Nut

SN: 560001-UP

4шт.

8

ND094162-0040

Seat

SN: 560001-UP

2шт.

9

ND094164-0010

Spring

SN: 560001-UP

2шт.

10

ND094165-0021

Seat

SN: 560001-UP

2шт.

11

ND094170-0100

Tappet Assembly

SN: 560001-UP

2шт.

12

ND094191-0161

Camshaft

SN: 560001-UP

1шт.

13

ND949101-0230

Bearing, Roller

SN: 560001-UP

2шт.

14

ND094104-0100

Cover

SN: 560001-UP

1шт.

15

ND949150-3030

Seal, Oil

SN: 560001-UP

1шт.

16

ND094086-0120

O-ring

SN: 560001-UP

1шт.

17

ND094095-0100

Shim, T=0.05mm

SN: 560001-UP

-2шт.

17

ND094095-0130

Shim, T=0.10mm

SN: 560001-UP

-2шт.

17

ND094095-0140

Shim, T=0.20mm

SN: 560001-UP

-2шт.

17

ND094095-0150

Shim, T=0.30mm

SN: 560001-UP

-2шт.

17

ND094095-0160

Shim, T=0.50mm

SN: 560001-UP

-2шт.

18

ND094092-0010

Washer

SN: 560001-UP

4шт.

19

ND949044-3320

Bolt

SN: 560001-UP

4шт.

20

ND094086-0110

O-ring

SN: 560001-UP

1шт.

21

ND094086-0130

O-ring

SN: 560001-UP

1шт.

22

ND094093-0050

Shim, T=0.40mm

SN: 560001-UP

-2шт.

22

ND094093-0060

Shim, T=0.60mm

SN: 560001-UP

-2шт.

22

ND094093-0070

Shim, T=0.80mm

SN: 560001-UP

-2шт.

22

ND094093-0080

Shim, T=1.00mm

SN: 560001-UP

-2шт.

23

ND949979-1300

Sensor Assembly

SN: 560001-UP

1шт.

23

ND949140-6310

O-ring

SN: 560001-UP

1шт.

24

ND094096-0050

Shim, T=0.15mm

SN: 560001-UP

-2шт.

24

ND094096-0060

Shim, T=0.20mm

SN: 560001-UP

-2шт.

24

ND094096-0070

Shim, T=0.25mm

SN: 560001-UP

-2шт.

24

ND094096-0080

Shim, T=0.40mm

SN: 560001-UP

-2шт.

25

ND90200-06081

Washer

SN: 560001-UP

1шт.

26

ND90107-06161

Bolt

SN: 560001-UP

1шт.

27

ND090310-0500

Valve Assembly

SN: 560001-UP

1шт.

28

ND090222-0070

Washer

SN: 560001-UP

5шт.

29

ND949180-0310

Screw

SN: 560001-UP

1шт.

30

ND090222-0120

Washer

SN: 560001-UP

2шт.

31

ND949180-0060

Screw

SN: 560001-UP

1шт.

32

ND949018-0350

Washer

SN: 560001-UP

1шт.

33

ND090317-0480

Plug

SN: 560001-UP

1шт.

34

ND090207-0100

Ring

SN: 560001-UP

1шт.

35

ND090244-0010

Screw

SN: 560001-UP

1шт.

36

ND949010-3020

Washer

SN: 560001-UP

1шт.

37

ND094086-0210

O-ring

SN: 560001-UP

1шт.
