Запчасти Komatsu SAA6D125E-5F ТОПЛИВН. НАСОС (/) (ВНУТР. ЧАСТИ) ДВИГАТЕЛЬ

|$1

6251-71-1120

FUEL PUMP ASS'Y

SN: 560001-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-D3Y7 AND A4010-E3Y7.

-1шт.

|$4

0

BODY ASS'Y

SN: 560001-UP

1шт.

1

0

HOUSING ASS'Y

SN: 560001-UP

1шт.

2

0

PCV ELEMENT ASS'Y

SN: 560001-UP

2шт.

3

0

O-RING

SN: 560001-UP

2шт.

4

0

GASKET

SN: 560001-UP

2шт.

5

0

VALVE ASS'Y

SN: 560001-UP

2шт.

6

0

O-RING

SN: 560001-UP

4шт.

7

0

WASHER

SN: 560001-UP

4шт.

8

0

NUT

SN: 560001-UP

4шт.

9

0

SEAT,SPRING UPPER

SN: 560001-UP

2шт.

10

0

SPRING,PLUNGER

SN: 560001-UP

2шт.

11

0

SEAT,SPRING LOWER

SN: 560001-UP

2шт.

12

0

TAPPET ASS'Y

SN: 560001-UP

2шт.

13

0

CAMSHAFT

SN: 560001-UP

1шт.

14

0

BEARING,ROLLER

SN: 560001-UP

2шт.

15

0

COVER,BEARING

SN: 560001-UP

1шт.

16

0

SEAL,OIL

SN: 560001-UP

1шт.

17

0

O-RING

SN: 560001-UP

1шт.

18

0

SHIM, 0.05MM

SN: 560001-UP

-2шт.

|$23

0

SHIM, 0.10MM

SN: 560001-UP

-2шт.

|$24

0

SHIM, 0.20MM

SN: 560001-UP

-2шт.

|$25

0

SHIM, 0.30MM

SN: 560001-UP

-2шт.

|$26

0

SHIM, 0.50MM

SN: 560001-UP

-2шт.

19

0

WASHER

SN: 560001-UP

4шт.

20

0

BOLT

SN: 560001-UP

4шт.

21

0

O-RING

SN: 560001-UP

1шт.

22

0

O-RING

SN: 560001-UP

1шт.

23

0

SHIM, 0.40MM

SN: 560001-UP

-2шт.

|$32

0

SHIM, 0.60MM

SN: 560001-UP

-2шт.

|$33

0

SHIM, 0.80MM

SN: 560001-UP

-2шт.

|$34

0

SHIM, 1.00MM

SN: 560001-UP

-2шт.

24

0

SENSOR ASS'Y

SN: 560001-UP

1шт.

|$36

0

O-RING

SN: 560001-UP

1шт.

25

0

SHIM, 0.15MM

SN: 560001-UP

-2шт.

|$38

0

SHIM, 0.20MM

SN: 560001-UP

-2шт.

|$39

0

SHIM, 0.25MM

SN: 560001-UP

-2шт.

|$40

0

SHIM, 0.40MM

SN: 560001-UP

-2шт.

26

0

WASHER

SN: 560001-UP

1шт.

27

0

BOLT

SN: 560001-UP

1шт.

28

ND090310-0500

VALVE ASS'Y,OVERFLOW

SN: 560001-UP

1шт.

29

ND090222-0070

WASHER

SN: 560001-UP

5шт.

30

ND949180-0310

SCREW

SN: 560001-UP

1шт.

31

ND090222-0120

WASHER

SN: 560001-UP

2шт.

32

ND949180-0060

SCREW

SN: 560001-UP

1шт.

33

0

WASHER

SN: 560001-UP

1шт.

34

0

PLUG,SCREW

SN: 560001-UP

1шт.

35

0

RING

SN: 560001-UP

1шт.

36

ND090244-0010

SCREW

SN: 560001-UP

1шт.

37

ND949010-3020

WASHER

SN: 560001-UP

1шт.

38

ND094086-0210

O-RING

SN: 560001-UP

1шт.
