Запчасти Komatsu SAA6D125E-5E ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

|$2

6251-11-1100

CYLINDER HEAD ASS'Y

SN: 560001-UP

6шт.

1

0

HEAD,CYLINDER

SN: 560001-UP

1шт.

2

6150-11-1320

INSERT,EXHAUST VALVE (STD)

SN: 560001-UP

2шт.

|$5

6150-19-1320

INSERT, 0.25MM,EXHAUST VALVE (OS)

SN: 560001-UP

2шт.

|$6

6150-18-1320

INSERT, 0.50MM,EXHAUST VALVE (OS)

SN: 560001-UP

2шт.

|$7

6150-17-1320

INSERT, 0.75MM,EXHAUST VALVE (OS)

SN: 560001-UP

2шт.

|$8

6150-16-1320

INSERT, 1.00MM,EXHAUST VALVE (OS)

SN: 560001-UP

2шт.

3

6251-11-1380

SEAT,INTAKE VALVE (STD)

SN: 560001-UP

2шт.

|$10

6251-19-1380

INSERT, 0.25MM,INTAKE VALVE (OS)

SN: 560001-UP

2шт.

|$11

6251-18-1380

INSERT, 0.50MM,INTAKE VALVE (OS)

SN: 560001-UP

2шт.

|$12

6251-17-1380

INSERT, 0.75MM,INTAKE VALVE (OS)

SN: 560001-UP

2шт.

|$13

6251-16-1380

INSERT, 1.00MM,INTAKE VALVE (OS)

SN: 560001-UP

2шт.

4

6150-12-1370

GUIDE,VALVE (SERVICE ONLY)

SN: 560001-UP

4шт.

5

6162-13-1150

PLUG,EXPANSION

SN: 560001-UP

11шт.

6

04260-00793

BALL

SN: 560001-UP

1шт.

7

07043-70108

PLUG

SN: 560001-UP

3шт.

8

6150-42-4110

VALVE,INTAKE

SN: 560001-UP

12шт.

9

6150-42-4210

VALVE,EXHAUST

SN: 560001-UP

12шт.

10

6150-41-4510

SEAT,UPPER

SN: 560001-UP

24шт.

11

6150-41-4430

SEAT,LOWER

SN: 560001-UP

24шт.

12

6136-42-4520

COTTER,VALVE

SN: 560001-UP

48шт.

13

6251-41-4450

SPRING,VALVE

SN: 560001-UP

24шт.

14

6150-41-4570

SEAL,VALVE STEM

SN: 560001-UP

24шт.

15

6210-11-1140

GUIDE,CROSSHEAD

SN: 560001-UP

12шт.

16

04020-00820

PIN

SN: 560001-UP

12шт.

|$28

6150-42-5600

CROSSHEAD ASS'Y

SN: 560001-UP

12шт.

17

6150-42-5610

CROSSHEAD

SN: 560001-UP

1шт.

18

6150-41-5621

SCREW

SN: 560001-UP

1шт.

19

6150-41-5630

NUT

SN: 560001-UP

1шт.

|$$30

STANDARD

-1шт.

20

6251-11-1810

GASKET,CYLINDER HEAD

SN: 560001-UP

6шт.

|$34

6150-11-1970

GROMMET,OIL

SN: 560001-UP

1шт.

|$35

6150-11-1930

GROMMET,OIL

SN: 560001-UP

1шт.

|$36

6150-11-1950

GROMMET,WATER

SN: 560001-UP

4шт.

|$37

6150-12-1960

GROMMET,WATER

SN: 560001-UP

1шт.

|$38

6150-11-1960

GROMMET,OIL

SN: 560001-UP

5шт.

|$$37

OVERSIZE 0.4MM

-1шт.

20

6251-19-1810

GASKET,CYLINDER HEAD

SN: .-UP

6шт.

|$41

6150-19-1970

GROMMET,OIL

SN: .-UP

1шт.

|$42

6150-19-1930

GROMMET,OIL

SN: .-UP

1шт.

|$43

6150-19-1950

GROMMET,WATER

SN: .-UP

4шт.

|$44

6150-19-1960

GROMMET,WATER

SN: .-UP

1шт.

|$45

6251-19-1960

GROMMET,WATER

SN: .-UP

1шт.

21

6150-11-1620

BOLT

SN: 560001-UP

36шт.

22

6164-31-3330

WASHER

SN: 560001-UP

36шт.

23

01438-01020

BOLT

SN: 560001-UP

6шт.
