Запчасти Komatsu SAA6D125E-5C КОЛЕНВАЛ ДВИГАТЕЛЬ БЛОК ЦИЛИНДРОВ И ITS КОМПОНЕНТЫ

|1

6151-35-1010

Crankshaft Assembly

SN: 560016-UP

1шт.

1

Crankshaft

SN: 560016-UP

1шт.

2

6150-35-1120

Gear

SN: 560016-UP

1шт.

3

6150-31-1130

Key

SN: 560016-UP

1шт.

4

6150-21-8010

Main Metal Assembly, Standard

SN: 560016-UP

7шт.

|4

Metal, Upper Standard

SN: 560016-UP

1шт.

|4

Metal, Lower Standard

SN: 560016-UP

1шт.

|4

6150-29-8010

Main Metal Assembly, Undersize 0.25mm

SN: 560016-UP

7шт.

|4

Metal, Upper Undersize 0.25mm

SN: 560016-UP

1шт.

|4

Metal, Lower Undersize 0.25mm

SN: 560016-UP

1шт.

|4

6150-28-8010

Main Metal Assembly, Undersize 0.50mm

SN: 560016-UP

7шт.

|4

Metal, Upper Undersize 0.50mm

SN: 560016-UP

1шт.

|4

Metal, Lower Undersize 0.50mm

SN: 560016-UP

1шт.

|4

6150-27-8010

Main Metal Assembly, Undersize 0.75mm

SN: 560016-UP

7шт.

|4

Metal, Upper Undersize 0.75mm

SN: 560016-UP

1шт.

|4

Metal, Lower Undersize 0.75mm

SN: 560016-UP

1шт.

|4

6150-26-8010

Main Metal Assembly, Undersize 1.00mm

SN: 560016-UP

7шт.

|4

Metal, Upper Undersize 1.00mm

SN: 560016-UP

1шт.

|4

Metal, Lower Undersize 1.00mm

SN: 560016-UP

1шт.

5

6150-21-8050

Metal Assembly, Thrust Standard

SN: 560016-UP

1шт.

|5

Metal, Thrust Standard

SN: 560016-UP

3шт.

|5

6150-29-8050

Metal Assembly, Thrust Oversize 0.25mm

SN: 560016-UP

1шт.

|5

Metal, Thrust Oversize 0.25mm

SN: 560016-UP

3шт.

|5

6150-28-8050

Metal Assembly, Thrust Oversize 0.50mm

SN: 560016-UP

1шт.

|5

Metal, Thrust Oversize 0.50mm

SN: 560016-UP

3шт.

|5

6150-27-8050

Metal Assembly, Thrust Oversize 0.75mm

SN: 560016-UP

1шт.

|5

Metal, Thrust Oversize 0.75mm

SN: 560016-UP

3шт.

|5

6150-26-8050

Metal Assembly, Thrust Oversize 1.00mm

SN: 560016-UP

1шт.

|5

Metal, Thrust Oversize 1.00mm

SN: 560016-UP

3шт.
