Запчасти Komatsu SAA6D125E-5B ПОРШЕНЬ И ШАТУН (№77-) ПОРШЕНЬ И ШАТУН

1

6251-31-2510

Piston

SN: 567007-UP

3шт.

2

6151-31-2410

Pin

SN: 567007-UP

6шт.

3

04065-04818

Ring, Snap

SN: 567007-UP

12шт.

3

6251-31-2030

Piston Ring Assembly

SN: 567007-UP

6шт.

4

Ring

SN: 567007-UP

1шт.

5

Ring

SN: 567007-UP

1шт.

6

Ring

SN: 567007-UP

1шт.

6

6251-31-3100

Connecting Rod Assembly

SN: 567007-UP

6шт.

7

Rod, Connecting

SN: 567007-UP

1шт.

8

Cap

SN: 567007-UP

1шт.

9

6251-31-3130

Bushing

SN: 567007-UP

1шт.

10

6150-31-3310

Bolt

SN: 567007-UP

2шт.

11

02400-10413

Pin, Dowel

SN: 567007-UP

2шт.

|$13

Metal, Standard

SN: 567007-UP

3шт.

|$14

Metal, Standard

SN: 567007-UP

3шт.

12

6151-31-3050

Metal Assembly, Standard

SN: 567007-UP

6шт.

12

6151-39-3050

Metal Assembly, Undersize 0.25mm

SN: 567007-UP

6шт.

12

6151-38-3050

Metal Assembly, Undersize 0.50mm

SN: 567007-UP

6шт.

12

6151-37-3050

Metal Assembly, Undersize 0.75mm

SN: 567007-UP

6шт.

12

6151-36-3050

Metal Assembly, Undersize 1.00mm

SN: 567007-UP

6шт.

12

Metal, Standard

SN: 567007-UP

3шт.

12

Metal, Undersize 0.25mm

SN: 567007-UP

3шт.

12

Metal, Undersize 0.50mm

SN: 567007-UP

3шт.

12

Metal, Undersize 0.75mm

SN: 567007-UP

3шт.

12

Metal, Undersize 1.00mm

SN: 567007-UP

3шт.

12

Metal, Standard

SN: 567007-UP

3шт.

12

Metal, Undersize 0.25mm

SN: 567007-UP

3шт.

12

Metal, Undersize 0.50mm

SN: 567007-UP

3шт.

12

Metal, Undersize 0.75mm

SN: 567007-UP

3шт.

12

Metal, Undersize 1.00mm

SN: 567007-UP

3шт.
