|$2
6251-11-1100
CYLINDER HEAD ASS'Y
SN: 560001-UP
6шт.
1
0
HEAD,CYLINDER
SN: 560001-UP
1шт.
2
6150-11-1320
INSERT,EXHAUST VALVE (STD)
SN: 560001-UP
2шт.
|$5
6150-19-1320
INSERT, 0.25MM,EXHAUST VALVE (OS)
SN: 560001-UP
2шт.
|$6
6150-18-1320
INSERT, 0.50MM,EXHAUST VALVE (OS)
SN: 560001-UP
2шт.
|$7
6150-17-1320
INSERT, 0.75MM,EXHAUST VALVE (OS)
SN: 560001-UP
2шт.
|$8
6150-16-1320
INSERT, 1.00MM,EXHAUST VALVE (OS)
SN: 560001-UP
2шт.
3
6251-11-1380
SEAT,INTAKE VALVE (STD)
SN: 560001-UP
2шт.
|$10
6251-19-1380
INSERT, 0.25MM,INTAKE VALVE (OS)
SN: 560001-UP
2шт.
|$11
6251-18-1380
INSERT, 0.50MM,INTAKE VALVE (OS)
SN: 560001-UP
2шт.
|$12
6251-17-1380
INSERT, 0.75MM,INTAKE VALVE (OS)
SN: 560001-UP
2шт.
|$13
6251-16-1380
INSERT, 1.00MM,INTAKE VALVE (OS)
SN: 560001-UP
2шт.
4
6150-12-1370
GUIDE,VALVE (SERVICE ONLY)
SN: 560001-UP
4шт.
5
6162-13-1150
PLUG,EXPANSION
SN: 560001-UP
11шт.
6
04260-00793
BALL
SN: 560001-UP
1шт.
7
07043-70108
PLUG
SN: 560001-UP
3шт.
8
6150-42-4110
VALVE,INTAKE
SN: 560001-UP
12шт.
9
6150-42-4210
VALVE,EXHAUST
SN: 560001-UP
12шт.
10
6150-41-4510
SEAT,UPPER
SN: 560001-UP
24шт.
11
6150-41-4430
SEAT,LOWER
SN: 560001-UP
24шт.
12
6136-42-4520
COTTER,VALVE
SN: 560001-UP
48шт.
13
6251-41-4450
SPRING,VALVE
SN: 560001-UP
24шт.
14
6150-41-4570
SEAL,VALVE STEM
SN: 560001-UP
24шт.
15
6210-11-1140
GUIDE,CROSSHEAD
SN: 560001-UP
12шт.
16
04020-00820
PIN
SN: 560001-UP
12шт.
|$28
6150-42-5600
CROSSHEAD ASS'Y
SN: 560001-UP
12шт.
17
6150-42-5610
CROSSHEAD
SN: 560001-UP
1шт.
18
6150-41-5621
SCREW
SN: 560001-UP
1шт.
19
6150-41-5630
NUT
SN: 560001-UP
1шт.
20
6251-11-1810
GASKET,CYLINDER HEAD
SN: 560001-UP
6шт.
|$33
6150-11-1970
GROMMET,OIL
SN: 560001-UP
1шт.
|$34
6150-11-1930
GROMMET,OIL
SN: 560001-UP
1шт.
|$35
6150-11-1950
GROMMET,WATER
SN: 560001-UP
4шт.
|$36
6150-12-1960
GROMMET,WATER
SN: 560001-UP
1шт.
|$37
6150-11-1960
GROMMET,OIL
SN: 560001-UP
5шт.
21
6150-11-1620
BOLT
SN: 560001-UP
36шт.
22
6164-31-3330
WASHER
SN: 560001-UP
36шт.
23
01438-01020
BOLT
SN: 560001-UP
6шт.
