Запчасти Komatsu SAA6D125E-5A ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ ГОЛОВКА ЦИЛИНДРОВ И ITS КОМПОНЕНТЫ

|1

6251-11-1100

Head Assembly

SN: 560004-UP

6шт.

1

6251-11-1110

Head, Cylinder

SN: 560004-UP

1шт.

2

6150-11-1320

Insert, Exhaust Valve Standard

SN: 560004-UP

2шт.

|2

6150-19-1320

Insert, Exhaust Valve Oversize 0.25mm

SN: 560004-UP

2шт.

|2

6150-18-1320

Insert, Exhaust Valve Oversize 0.50mm

SN: 560004-UP

2шт.

|2

6150-17-1320

Insert, Exhaust Valve Oversize 0.75mm

SN: 560004-UP

2шт.

|2

6150-16-1320

Insert, Exhaust Valve Oversize 1.00mm

SN: 560004-UP

2шт.

3

6251-11-1380

Insert, Intake Valve Standard

SN: 560004-UP

2шт.

|3

6251-19-1380

Insert, Intake Valve Oversize 0.25mm

SN: 560004-UP

2шт.

|3

6251-18-1380

Insert, Intake Valve Oversize 0.50mm

SN: 560004-UP

2шт.

|3

6251-17-1380

Insert, Intake Valve Oversize 0.75mm

SN: 560004-UP

2шт.

|3

6251-16-1380

Insert, Intake Valve Oversize 1.00mm

SN: 560004-UP

2шт.

4

6150-12-1370

Guide, Service Use Only

SN: 560004-UP

4шт.

5

6162-13-1150

Plug, Expansion

SN: 560004-UP

11шт.

6

04260-00793

Ball

SN: 560004-UP

1шт.

7

07043-70108

Plug

SN: 560004-UP

3шт.

8

6150-42-4110

Valve, Intake

SN: 560004-UP

12шт.

9

6150-42-4210

Valve, Exhaust

SN: 560004-UP

12шт.

10

6150-41-4510

Seat, Upper

SN: 560004-UP

24шт.

11

6150-41-4430

Seat, Lower

SN: 560004-UP

24шт.

12

6136-42-4520

Cotter, Valve

SN: 560004-UP

48шт.

13

6251-41-4450

Spring, Valve

SN: 560004-UP

24шт.

14

6150-41-4570

Seal, Valve Stem

SN: 560004-UP

24шт.

15

6210-11-1140

Guide, Crosshead

SN: 560004-UP

12шт.

16

04020-00820

Pin, Dowel

SN: 560004-UP

12шт.

|16

6150-42-5600

Crosshead Assembly

SN: 560004-UP

12шт.

17

6150-42-5610

Crosshead

SN: 560004-UP

1шт.

18

6150-41-5621

Screw

SN: 560004-UP

1шт.

19

6150-41-5630

Nut

SN: 560004-UP

1шт.

20

6251-11-1810

Gasket, Cylinder Head

SN: 560004-UP

6шт.

|20

6150-11-1970

Grommet, Oil

SN: 560004-UP

1шт.

|20

6150-11-1930

Grommet, Oil

SN: 560004-UP

1шт.

|20

6150-11-1950

Grommet, Water

SN: 560004-UP

4шт.

|20

6150-12-1960

Grommet, Water

SN: 560004-UP

1шт.

|20

6150-11-1960

Grommet, Oil

SN: 560004-UP

5шт.

21

6150-11-1620

Bolt, Head

SN: 560004-UP

36шт.

22

6164-31-3330

Washer

SN: 560004-UP

36шт.

23

01438-01020

Bolt

SN: 560004-UP

6шт.
