Артикул
Название
Примечание
Количество
|1
6152-72-1280
INJECTION PUMP ASS'Y
SN: 210001-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B3T8 TO A4010-H3T8.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
DK105407-7771
GOVERNOR ASS'Y
SN: 210001-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-D3T8 AND A4010-E3T8.
-1шт.
1
DK154000-5720
HOUSING
SN: 210001-UP
1шт.
2
DK154007-1600
PLUG
SN: 210001-UP
1шт.
3
DK154350-6000
PLATE
SN: 210001-UP
1шт.
4
DK020106-2040
BOLT
SN: 210001-UP
8шт.
5
DK154013-5000
SCREW
SN: 210001-UP
1шт.
9
DK154101-0020
FLYWEIGHT ASS'Y
SN: 210001-UP
1шт.
|10
DK025803-1610
KEY¤ 16MM
SN: 210001-UP
1шт.
12
DK029231-2030
NUT
SN: 210001-UP
1шт.
|14
DK029311-0180
SHIM¤ 0.30MM
SN: 210001-UP
-2шт.
|14
DK139410-0000
SHIM¤ 0.50MM
SN: 210001-UP
-2шт.
|14
DK029311-0210
SHIM¤ 1.00MM
SN: 210001-UP
-2шт.
|14
DK139410-0100
SHIM¤ 1.50MM
SN: 210001-UP
-2шт.
|14
DK139410-3100
SHIM¤ 3.00MM
SN: 210001-UP
-2шт.
|14
DK139410-3200
SHIM¤ 4.00MM
SN: 210001-UP
-2шт.
16
DK154177-3520
CAPSULE,SPRING
SN: 210001-UP
1шт.
17
DK029201-6010
NUT
SN: 210001-UP
1шт.
18
DK154216-7220
GUIDE LEVER ASS'Y
SN: 210001-UP
1шт.
19
DK029310-5170
SHIM
SN: 210001-UP
3шт.
20
DK025520-1210
PIN,SPLIT
SN: 210001-UP
3шт.
21
DK154230-2920
LINK
SN: 210001-UP
1шт.
23
DK155412-5300
IMPELLER
SN: 210001-UP
1шт.
25
DK154401-3620
LEVER
SN: 210001-UP
1шт.
26
DK154401-1320
LINK
SN: 210001-UP
1шт.
27
DK016010-0540
RING,SNAP
SN: 210001-UP
1шт.
28
DK154222-6200
PIN
SN: 210001-UP
1шт.
29
DK029300-4010
WASHER
SN: 210001-UP
1шт.
30
DK016010-0440
RING,SNAP
SN: 210001-UP
1шт.
31
DK154062-3520
CAP
SN: 210001-UP
1шт.
Выбрано товаров: 45
