Запчасти Komatsu SAA6D114E-2BA ГЕНЕРАТОР (A) (ВНУТР. ЧАСТИ) ДВИГАТЕЛЬ

|$0

6743-82-6140

ALTERNATOR,PRODUCTION (F1)

SN: .-UP

1шт.

|$1

1286 822 H91

ALTERNATOR,SERVICE

SN: .-UP

1шт.

1

1268 345 H1

HOUSING,RECTIFIER

SN: .-UP

1шт.

2

1268 346 H91

ROTOR

SN: .-UP

1шт.

3

1268 347 H91

STATOR

SN: .-UP

1шт.

4

1268 348 H1

FRAME

SN: .-UP

1шт.

5

1268 349 H91

RECTIFIER,BRIDGE

SN: .-UP

1шт.

6

1268 350 H1

DIODE,TRIO

SN: .-UP

1шт.

7

1268 351 H91

FIELD COIL

SN: .-UP

1шт.

8

1268 352 H1

COVER,END

SN: .-UP

1шт.

9

1218 115 H1

REGULATOR

SN: .-UP

1шт.

10

1268 354 H1

CONNECTOR,OUTPUT TERMINAL

SN: .-UP

1шт.

11

1238 355 H1

CONNECTOR,RELAY TERMINAL

SN: .-UP

1шт.

12

1268 356 H1

CONNECTOR,REGULATOR

SN: .-UP

1шт.

13

1268 357 H91

PACKAGE,OUTPUT TERMINAL

SN: .-UP

1шт.

14

1268 358 H91

PACKAGE,RELAY TERMINAL

SN: .-UP

1шт.

15

1268 359 H1

CAPACITOR

SN: .-UP

1шт.

16

98 819

BRACKET,CAPACITOR MOUNTING

SN: .-UP

1шт.

17

1218 121 H1

PLATE,RETAINER - INSIDE

SN: .-UP

1шт.

18

1268 360 H1

PLATE,RETAINER - OUTSIDE

SN: .-UP

1шт.

19

1213 268 H1

BEARING,BALL

SN: .-UP

1шт.

20

1268 361 H1

COLLAR,INSIDE

SN: .-UP

1шт.

21

1218 123 H1

COLLAR,OUTSIDE

SN: .-UP

1шт.

22

1268 362 H91

FAN

SN: .-UP

1шт.

23

1218 126 H1

NUT,CONNECTOR

SN: .-UP

1шт.

24

1218 126 H1

NUT

SN: .-UP

1шт.

25

19 830 R1

NUT,SHAFT

SN: .-UP

1шт.

26

1268 363 H1

SCREW,MOUNTING

SN: .-UP

3шт.

27

1268 364 H1

SCREW,MOUNTING

SN: .-UP

2шт.

28

1268 363 H1

SCREW,MOUNTING

SN: .-UP

5шт.

29

1213 252 H1

SCREW,ATTACHING

SN: .-UP

4шт.

30

1268 365 H1

SCREW,MOUNTING

SN: .-UP

1шт.

31

1268 366 H1

SCREW,MOUNTING

SN: .-UP

1шт.

32

1268 367 H1

SCREW,ATTACHING

SN: .-UP

1шт.

33

1268 365 H1

SCREW,MOUNTING

SN: .-UP

1шт.

34

1268 368 H1

WASHER,FELT

SN: .-UP

1шт.

35

88 803

WASHER,FELT

SN: .-UP

1шт.

36

1268 369 H1

WASHER

SN: .-UP

1шт.

37

1268 370 H1

WASHER,SHAFT

SN: .-UP

1шт.

38

389 603 C91

BEARING,RECTIFIER HOUSING

SN: .-UP

1шт.

39

1268 371 H1

BOLT,THRU

SN: .-UP

4шт.

40

1213 242 H1

BUSHING,PIVOT

SN: .-UP

1шт.

41

1268 372 H1

BUSHING,MOUNTING SCREW

SN: .-UP

1шт.

42

1213 274 H1

CAP,RELAY TERMINAL

SN: .-UP

1шт.

43

1268 373 H1

CUP,FELT WASHER

SN: .-UP

1шт.

44

1268 374 H1

GROMMET

SN: .-UP

1шт.

45

1268 375 H1

INSULATOR

SN: .-UP

1шт.

46

1218 131 H1

SHIELD,BEARING RETAINER PLATE

SN: .-UP

1шт.

|$$49

(F1)

-1шт.

|$$50

WHEN REPLACING THIS ALTERNATOR,PURCHASE 60 AMP ALTERNATOR P/N 600-861-6110.

-1шт.

|$$51

AT THAT TIME ALSO REPLACE 50 AMP MOUNTING, BELT TENSIONER AND ALTERNATOR DRIVE PULLEY

-1шт.

|$$52

WITH 60 AMP MOUNTING, BELT TENSIONER AND ALTERNATOR DRIVE PULLEY.

-1шт.

|$0

6743-82-6140

ALTERNATOR,PRODUCTION (F1)

SN: .-UP

1шт.

|$1

1286 822 H91

ALTERNATOR,SERVICE

SN: .-UP

1шт.

1

1268 345 H1

HOUSING,RECTIFIER

SN: .-UP

1шт.

2

1268 346 H91

ROTOR

SN: .-UP

1шт.

3

1268 347 H91

STATOR

SN: .-UP

1шт.

4

1268 348 H1

FRAME

SN: .-UP

1шт.

5

1268 349 H91

RECTIFIER,BRIDGE

SN: .-UP

1шт.

6

1268 350 H1

DIODE,TRIO

SN: .-UP

1шт.

7

1268 351 H91

FIELD COIL

SN: .-UP

1шт.

8

1268 352 H1

COVER,END

SN: .-UP

1шт.

9

1218 115 H1

REGULATOR

SN: .-UP

1шт.

10

1268 354 H1

CONNECTOR,OUTPUT TERMINAL

SN: .-UP

1шт.

11

1238 355 H1

CONNECTOR,RELAY TERMINAL

SN: .-UP

1шт.

12

1268 356 H1

CONNECTOR,REGULATOR

SN: .-UP

1шт.

13

1268 357 H91

PACKAGE,OUTPUT TERMINAL

SN: .-UP

1шт.

14

1268 358 H91

PACKAGE,RELAY TERMINAL

SN: .-UP

1шт.

15

1268 359 H1

CAPACITOR

SN: .-UP

1шт.

16

98 819

BRACKET,CAPACITOR MOUNTING

SN: .-UP

1шт.

17

1218 121 H1

PLATE,RETAINER - INSIDE

SN: .-UP

1шт.

18

1268 360 H1

PLATE,RETAINER - OUTSIDE

SN: .-UP

1шт.

19

1213 268 H1

BEARING,BALL

SN: .-UP

1шт.

20

1268 361 H1

COLLAR,INSIDE

SN: .-UP

1шт.

21

1218 123 H1

COLLAR,OUTSIDE

SN: .-UP

1шт.

22

1268 362 H91

FAN

SN: .-UP

1шт.

23

1218 126 H1

NUT,CONNECTOR

SN: .-UP

1шт.

24

1218 126 H1

NUT

SN: .-UP

1шт.

25

19 830 R1

NUT,SHAFT

SN: .-UP

1шт.

26

1268 363 H1

SCREW,MOUNTING

SN: .-UP

3шт.

27

1268 364 H1

SCREW,MOUNTING

SN: .-UP

2шт.

28

1268 363 H1

SCREW,MOUNTING

SN: .-UP

5шт.

29

1213 252 H1

SCREW,ATTACHING

SN: .-UP

4шт.

30

1268 365 H1

SCREW,MOUNTING

SN: .-UP

1шт.

31

1268 366 H1

SCREW,MOUNTING

SN: .-UP

1шт.

32

1268 367 H1

SCREW,ATTACHING

SN: .-UP

1шт.

33

1268 365 H1

SCREW,MOUNTING

SN: .-UP

1шт.

34

1268 368 H1

WASHER,FELT

SN: .-UP

1шт.

35

88 803

WASHER,FELT

SN: .-UP

1шт.

36

1268 369 H1

WASHER

SN: .-UP

1шт.

37

1268 370 H1

WASHER,SHAFT

SN: .-UP

1шт.

38

389 603 C91

BEARING,RECTIFIER HOUSING

SN: .-UP

1шт.

39

1268 371 H1

BOLT,THRU

SN: .-UP

4шт.

40

1213 242 H1

BUSHING,PIVOT

SN: .-UP

1шт.

41

1268 372 H1

BUSHING,MOUNTING SCREW

SN: .-UP

1шт.

42

1213 274 H1

CAP,RELAY TERMINAL

SN: .-UP

1шт.

43

1268 373 H1

CUP,FELT WASHER

SN: .-UP

1шт.

44

1268 374 H1

GROMMET

SN: .-UP

1шт.

45

1268 375 H1

INSULATOR

SN: .-UP

1шт.

46

1218 131 H1

SHIELD,BEARING RETAINER PLATE

SN: .-UP

1шт.

|$$49

(F1)

-1шт.

|$$50

WHEN REPLACING THIS ALTERNATOR,PURCHASE 60 AMP ALTERNATOR P/N 600-861-6110.

-1шт.

|$$51

AT THAT TIME ALSO REPLACE 50 AMP MOUNTING, BELT TENSIONER AND ALTERNATOR DRIVE PULLEY

-1шт.

|$$52

WITH 60 AMP MOUNTING, BELT TENSIONER AND ALTERNATOR DRIVE PULLEY.

-1шт.
