Запчасти Komatsu SAA6D114E-2B ГЕНЕРАТОР (A) (ВНУТР. ЧАСТИ) ДВИГАТЕЛЬ
№
Артикул
Название
Примечание
Количество
|$0
6743-82-6140
ALTERNATOR,PRODUCTION (F1)
SN: .-UP
1шт.
|$1
1286 822 H91
ALTERNATOR,SERVICE
SN: .-UP
1шт.
1
1268 345 H1
HOUSING,RECTIFIER
SN: .-UP
1шт.
2
1268 346 H91
ROTOR
SN: .-UP
1шт.
3
1268 347 H91
STATOR
SN: .-UP
1шт.
4
1268 348 H1
FRAME
SN: .-UP
1шт.
5
1268 349 H91
RECTIFIER,BRIDGE
SN: .-UP
1шт.
6
1268 350 H1
DIODE,TRIO
SN: .-UP
1шт.
7
1268 351 H91
FIELD COIL
SN: .-UP
1шт.
8
1268 352 H1
COVER,END
SN: .-UP
1шт.
9
1218 115 H1
REGULATOR
SN: .-UP
1шт.
10
1268 354 H1
CONNECTOR,OUTPUT TERMINAL
SN: .-UP
1шт.
11
1238 355 H1
CONNECTOR,RELAY TERMINAL
SN: .-UP
1шт.
12
1268 356 H1
CONNECTOR,REGULATOR
SN: .-UP
1шт.
13
1268 357 H91
PACKAGE,OUTPUT TERMINAL
SN: .-UP
1шт.
14
1268 358 H91
PACKAGE,RELAY TERMINAL
SN: .-UP
1шт.
15
1268 359 H1
CAPACITOR
SN: .-UP
1шт.
16
98 819
BRACKET,CAPACITOR MOUNTING
SN: .-UP
1шт.
17
1218 121 H1
PLATE,RETAINER - INSIDE
SN: .-UP
1шт.
18
1268 360 H1
PLATE,RETAINER - OUTSIDE
SN: .-UP
1шт.
19
1213 268 H1
BEARING,BALL
SN: .-UP
1шт.
20
1268 361 H1
COLLAR,INSIDE
SN: .-UP
1шт.
21
1218 123 H1
COLLAR,OUTSIDE
SN: .-UP
1шт.
22
1268 362 H91
FAN
SN: .-UP
1шт.
23
1218 126 H1
NUT,CONNECTOR
SN: .-UP
1шт.
24
1218 126 H1
NUT
SN: .-UP
1шт.
25
19 830 R1
NUT,SHAFT
SN: .-UP
1шт.
26
1268 363 H1
SCREW,MOUNTING
SN: .-UP
3шт.
27
1268 364 H1
SCREW,MOUNTING
SN: .-UP
2шт.
28
1268 363 H1
SCREW,MOUNTING
SN: .-UP
5шт.
29
1213 252 H1
SCREW,ATTACHING
SN: .-UP
4шт.
30
1268 365 H1
SCREW,MOUNTING
SN: .-UP
1шт.
31
1268 366 H1
SCREW,MOUNTING
SN: .-UP
1шт.
32
1268 367 H1
SCREW,ATTACHING
SN: .-UP
1шт.
33
1268 365 H1
SCREW,MOUNTING
SN: .-UP
1шт.
34
1268 368 H1
WASHER,FELT
SN: .-UP
1шт.
35
88 803
WASHER,FELT
SN: .-UP
1шт.
36
1268 369 H1
WASHER
SN: .-UP
1шт.
37
1268 370 H1
WASHER,SHAFT
SN: .-UP
1шт.
38
389 603 C91
BEARING,RECTIFIER HOUSING
SN: .-UP
1шт.
39
1268 371 H1
BOLT,THRU
SN: .-UP
4шт.
40
1213 242 H1
BUSHING,PIVOT
SN: .-UP
1шт.
41
1268 372 H1
BUSHING,MOUNTING SCREW
SN: .-UP
1шт.
42
1213 274 H1
CAP,RELAY TERMINAL
SN: .-UP
1шт.
43
1268 373 H1
CUP,FELT WASHER
SN: .-UP
1шт.
44
1268 374 H1
GROMMET
SN: .-UP
1шт.
45
1268 375 H1
INSULATOR
SN: .-UP
1шт.
46
1218 131 H1
SHIELD,BEARING RETAINER PLATE
SN: .-UP
1шт.
|$$49
(F1)
-1шт.
|$$50
WHEN REPLACING THIS ALTERNATOR,PURCHASE 60 AMP ALTERNATOR P/N 600-861-6110.
-1шт.
|$$51
AT THAT TIME ALSO REPLACE 50 AMP MOUNTING, BELT TENSIONER AND ALTERNATOR DRIVE PULLEY
-1шт.
|$$52
WITH 60 AMP MOUNTING, BELT TENSIONER AND ALTERNATOR DRIVE PULLEY.
-1шт.
|$0
6743-82-6140
ALTERNATOR,PRODUCTION (F1)
SN: .-UP
1шт.
|$1
1286 822 H91
ALTERNATOR,SERVICE
SN: .-UP
1шт.
1
1268 345 H1
HOUSING,RECTIFIER
SN: .-UP
1шт.
2
1268 346 H91
ROTOR
SN: .-UP
1шт.
3
1268 347 H91
STATOR
SN: .-UP
1шт.
4
1268 348 H1
FRAME
SN: .-UP
1шт.
5
1268 349 H91
RECTIFIER,BRIDGE
SN: .-UP
1шт.
6
1268 350 H1
DIODE,TRIO
SN: .-UP
1шт.
7
1268 351 H91
FIELD COIL
SN: .-UP
1шт.
8
1268 352 H1
COVER,END
SN: .-UP
1шт.
9
1218 115 H1
REGULATOR
SN: .-UP
1шт.
10
1268 354 H1
CONNECTOR,OUTPUT TERMINAL
SN: .-UP
1шт.
11
1238 355 H1
CONNECTOR,RELAY TERMINAL
SN: .-UP
1шт.
12
1268 356 H1
CONNECTOR,REGULATOR
SN: .-UP
1шт.
13
1268 357 H91
PACKAGE,OUTPUT TERMINAL
SN: .-UP
1шт.
14
1268 358 H91
PACKAGE,RELAY TERMINAL
SN: .-UP
1шт.
15
1268 359 H1
CAPACITOR
SN: .-UP
1шт.
16
98 819
BRACKET,CAPACITOR MOUNTING
SN: .-UP
1шт.
17
1218 121 H1
PLATE,RETAINER - INSIDE
SN: .-UP
1шт.
18
1268 360 H1
PLATE,RETAINER - OUTSIDE
SN: .-UP
1шт.
19
1213 268 H1
BEARING,BALL
SN: .-UP
1шт.
20
1268 361 H1
COLLAR,INSIDE
SN: .-UP
1шт.
21
1218 123 H1
COLLAR,OUTSIDE
SN: .-UP
1шт.
22
1268 362 H91
FAN
SN: .-UP
1шт.
23
1218 126 H1
NUT,CONNECTOR
SN: .-UP
1шт.
24
1218 126 H1
NUT
SN: .-UP
1шт.
25
19 830 R1
NUT,SHAFT
SN: .-UP
1шт.
26
1268 363 H1
SCREW,MOUNTING
SN: .-UP
3шт.
27
1268 364 H1
SCREW,MOUNTING
SN: .-UP
2шт.
28
1268 363 H1
SCREW,MOUNTING
SN: .-UP
5шт.
29
1213 252 H1
SCREW,ATTACHING
SN: .-UP
4шт.
30
1268 365 H1
SCREW,MOUNTING
SN: .-UP
1шт.
31
1268 366 H1
SCREW,MOUNTING
SN: .-UP
1шт.
32
1268 367 H1
SCREW,ATTACHING
SN: .-UP
1шт.
33
1268 365 H1
SCREW,MOUNTING
SN: .-UP
1шт.
34
1268 368 H1
WASHER,FELT
SN: .-UP
1шт.
35
88 803
WASHER,FELT
SN: .-UP
1шт.
36
1268 369 H1
WASHER
SN: .-UP
1шт.
37
1268 370 H1
WASHER,SHAFT
SN: .-UP
1шт.
38
389 603 C91
BEARING,RECTIFIER HOUSING
SN: .-UP
1шт.
39
1268 371 H1
BOLT,THRU
SN: .-UP
4шт.
40
1213 242 H1
BUSHING,PIVOT
SN: .-UP
1шт.
41
1268 372 H1
BUSHING,MOUNTING SCREW
SN: .-UP
1шт.
42
1213 274 H1
CAP,RELAY TERMINAL
SN: .-UP
1шт.
43
1268 373 H1
CUP,FELT WASHER
SN: .-UP
1шт.
44
1268 374 H1
GROMMET
SN: .-UP
1шт.
45
1268 375 H1
INSULATOR
SN: .-UP
1шт.
46
1218 131 H1
SHIELD,BEARING RETAINER PLATE
SN: .-UP
1шт.
|$$49
(F1)
-1шт.
|$$50
WHEN REPLACING THIS ALTERNATOR,PURCHASE 60 AMP ALTERNATOR P/N 600-861-6110.
-1шт.
|$$51
AT THAT TIME ALSO REPLACE 50 AMP MOUNTING, BELT TENSIONER AND ALTERNATOR DRIVE PULLEY
-1шт.
|$$52
WITH 60 AMP MOUNTING, BELT TENSIONER AND ALTERNATOR DRIVE PULLEY.
-1шт.
Выбрано товаров: 104
