Запчасти Komatsu SAA6D108E-2C-N8 ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

|$1

6221-13-1100

CYLINDER HEAD ASS'Y

SN: 19030-UP

1шт.

1

0

HEAD,CYLINDER

SN: 19030-UP

1шт.

2

6221-15-1310

GUIDE,VALVE

SN: 24891-UP

12шт.

2

0

GUIDE,VALVE

SN: 19030-24890

12шт.

3

6221-13-1360

SEAT,INTAKE VALVE (STD)

SN: 22226-UP

6шт.

3

0

SEAT,INTAKE VALVE (STD)

SN: 19030-22225

6шт.

3

6221-19-1360

SEAT, 0.25MM,INTAKE VALVE (OS)

SN: 22226-UP

6шт.

3

0

SEAT, 0.25MM,INTAKE VALVE (OS)

SN: 19030-22225

6шт.

3

6221-18-1360

SEAT, 0.50MM,INTAKE VALVE (OS)

SN: 22226-UP

6шт.

3

0

SEAT, 0.50MM,INTAKE VALVE (OS)

SN: 19030-22225

6шт.

3

6221-17-1360

SEAT, 0.75MM,INTAKE VALVE (OS)

SN: 22226-UP

6шт.

3

0

SEAT, 0.75MM,INTAKE VALVE (OS)

SN: 19030-22225

6шт.

3

6221-16-1360

SEAT, 1.00MM,INTAKE VALVE (OS)

SN: 22226-UP

6шт.

3

0

SEAT, 1.00MM,INTAKE VALVE (OS)

SN: 19030-22225

6шт.

4

6221-11-1320

SEAT,EXHAUST VALVE (STD)

SN: 19030-UP

6шт.

4

6221-19-1320

SEAT, 0.25MM,EXHAUST VALVE (OS)

SN: 19030-UP

6шт.

4

6221-18-1320

SEAT, 0.50MM,EXHAUST VALVE (OS)

SN: 19030-UP

6шт.

4

6221-17-1320

SEAT, 0.75MM,EXHAUST VALVE (OS)

SN: 19030-UP

6шт.

4

6221-16-1320

SEAT, 1.00MM,EXHAUST VALVE (OS)

SN: 19030-UP

6шт.

5

07046-41810

PLUG

SN: 19030-UP

9шт.

6

07046-42816

PLUG

SN: 19030-UP

17шт.

7

07046-44016

PLUG

SN: 19030-UP

4шт.

8

07043-70108

PLUG

SN: 19030-UP

7шт.

9

6221-43-4110

VALVE,INTAKE

SN: 19030-UP

6шт.

10

6221-43-4210

VALVE,EXHAUST

SN: 19030-UP

6шт.

11

6221-41-4510

GUIDE,SPRING

SN: 19030-UP

12шт.

12

6136-42-4520

COTTER,VALVE

SN: 19030-UP

24шт.

13

6221-41-4410

SPRING,VALVE

SN: 19030-UP

12шт.

14

6221-43-4540

SEAL,VALVE

SN: 19030-UP

12шт.

15

6221-41-4550

CAP,STEM

SN: 19030-UP

12шт.

16

6221-17-1810

GASKET,HEAD (K1)

SN: 19030-UP

1шт.

17

6221-11-1610

BOLT

SN: 19030-UP

26шт.
