Артикул
Название
Примечание
Количество
|1
6222-73-1351
INJECTION PUMP ASS'Y
SN: 35434-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B2F6 TO A4010-G2F6.
-1шт.
|1
ND190800-6840
GOVERNOR ASS'Y
SN: 35434-UP
1шт.
|$$4
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-D2F6 TO A4010-F2F6.
-1шт.
1
ND090810-0501
HOUSING
SN: 35434-UP
1шт.
2
ND090878-0200
PLATE
SN: 35434-UP
1шт.
3
ND091024-0211
SCREW,ADJUSTING
SN: 35434-UP
1шт.
4
ND090901-0150
LEVER ASS'Y,TENSION
SN: 35434-UP
1шт.
5
ND090940-0480
LEVER ASS'Y
SN: 35434-UP
1шт.
6
ND90400-02101
E-RING
SN: 35434-UP
1шт.
7
ND090959-0010
LEVER ASS'Y,CONTROL
SN: 35434-UP
1шт.
8
ND090894-0010
E-RING
SN: 35434-UP
1шт.
9
ND090987-0010
SHIM
SN: 35434-UP
1шт.
10
ND90190-08051
NUT
SN: 35434-UP
1шт.
11
ND091046-0010
SLIDER,SUPPORTING
SN: 35434-UP
1шт.
12
ND090970-0400
SHACKLE
SN: 35434-UP
1шт.
13
ND090840-0720
FLYWEIGHT ASS'Y
SN: 35434-UP
1шт.
14
ND949015-0500
WASHER¤ 2.5MM,SPRING
SN: 35434-UP
1шт.
16
ND090861-0010
SLEEVE,GOVERNOR
SN: 35434-UP
1шт.
17
ND949100-0010
BEARING,BALL
SN: 35434-UP
1шт.
18
ND949013-4090
WASHER¤ 0.1MM
SN: 35434-UP
-2шт.
|18
ND949013-4060
WASHER¤ 0.2MM
SN: 35434-UP
-2шт.
|18
ND949013-4070
WASHER¤ 0.3MM
SN: 35434-UP
-2шт.
|18
ND949013-4080
WASHER¤ 0.4MM
SN: 35434-UP
-2шт.
|18
ND949013-4100
WASHER¤ 1.0MM
SN: 35434-UP
-2шт.
19
ND090880-0110
LEVER,SWIVEL
SN: 35434-UP
1шт.
20
ND949071-0090
WASHER,SNAP
SN: 35434-UP
2шт.
21
ND090992-0410
SPRING,CONTROL
SN: 35434-UP
1шт.
23
ND090224-0140
PLUG,SCREW
SN: 35434-UP
1шт.
25
ND949130-0030
KEY
SN: 35434-UP
1шт.
28
ND090245-0230
SCREW
SN: 35434-UP
1шт.
30
ND949072-1500
RING,SNAP
SN: 35434-UP
1шт.
31
ND949140-4060
O-RING
SN: 35434-UP
1шт.
32
ND091031-0360
NUT,CAP
SN: 35434-UP
1шт.
33
ND949047-6880
BOLT,WITH WASHER
SN: 35434-UP
2шт.
34
ND949047-6910
BOLT,WITH WASHER
SN: 35434-UP
1шт.
35
ND949047-6890
BOLT,WITH WASHER
SN: 35434-UP
4шт.
36
ND949047-6900
BOLT,WITH WASHER
SN: 35434-UP
1шт.
Выбрано товаров: 44
