Запчасти Komatsu SAA6D108E-2A ТОПЛ. НАСОС (РЕГУЛЯТОР) (/) (ВНУТР. ЧАСТИ) ДВИГАТЕЛЬ

|1

6222-73-1111

INJECTION PUMP ASS'Y

SN: 34724-UP

1шт.

|1

0

INJECTION PUMP ASS'Y

SN: 19030-34723

1шт.

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.A4010-B2D1 T0 A4010-G2D1.

-1шт.

|$$4

THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

ND190800-4581

GOVERNOR ASS'Y

SN: 34724-UP

1шт.

|1

ND190800-4871

GOVERNOR ASS'Y

SN: 19030-34723

1шт.

|$$7

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.A4010-D2D1 T0 A4010-F2D1.

-1шт.

|1

ND192600-0420

COMPENSATOR SUB A.,BOOST

SN: 19030-UP

1шт.

1

ND192611-0030

HOUSING

SN: 19030-UP

1шт.

2

ND192620-0050

COVER SUB ASS'Y

SN: 19030-UP

1шт.

3

ND192633-0010

WASHER,THRUST

SN: 19030-UP

1шт.

4

ND192632-0010

SEAT

SN: 19030-UP

1шт.

5

ND192627-0020

ROD,PUSH

SN: 19030-UP

1шт.

6

ND192635-0010

BUSHING,GUIDE

SN: 19030-UP

1шт.

7

ND90160-06051

NUT

SN: 19030-UP

1шт.

8

ND192628-0010

SCREW

SN: 19030-UP

1шт.

9

ND192634-0030

SPRING

SN: 19030-UP

1шт.

10

ND192631-0010

DIAPHRAGM

SN: 19030-UP

1шт.

11

ND90160-06051

NUT

SN: 19030-UP

1шт.

12

ND949017-0490

WASHER

SN: 19030-UP

1шт.

13

ND949018-1020

WASHER¤ 1.0MM

SN: 19030-UP

2шт.

14

ND091031-0020

NUT,CAP

SN: 19030-UP

1шт.

15

ND091166-0110

SCREW

SN: 19030-UP

1шт.

16

ND948053-0130

NUT

SN: 19030-UP

1шт.

17

ND090524-0041

PLUG

SN: 19030-UP

1шт.

18

ND949018-1040

WASHER

SN: 19030-UP

1шт.

19

ND90107-06121

BOLT

SN: 19030-UP

3шт.

20

ND949045-0120

BOLT

SN: 19030-UP

1шт.
