Артикул
Название
Примечание
Количество
|1
6222-73-1110
INJECTION PUMP ASS'Y
SN: 19030-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B2D1 TO A4010-F2D1.
-1шт.
|$$3
THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
ND190100-0610
PUMP ASS'Y
SN: 19030-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B2D1 AND A4010-C2D1.
-1шт.
2
ND090136-0800
SPRING,DELIVERY VALVE
SN: 19030-UP
6шт.
4
ND090140-2440
VALVE,DELIVERY
SN: 19030-UP
6шт.
5
ND090150-5680
ELEMENT,PUMP
SN: 19030-UP
6шт.
6
ND090160-0150
SLEEVE,CONTROL
SN: 19030-UP
6шт.
7
ND090212-0471
RACK,CONTROL
SN: 19030-UP
1шт.
8
ND090163-0160
SEAT,UPPER SPRING
SN: 19030-UP
6шт.
9
ND090164-0290
SPRING,PLUNGER
SN: 19030-UP
6шт.
10
ND090165-0150
SEAT,LOWER SPRING
SN: 19030-UP
6шт.
12
ND090438-0901
SHIM¤ 1.65MM
SN: 19030-UP
-2шт.
|12
ND090438-0911
SHIM¤ 1.7MM
SN: 19030-UP
-2шт.
|12
ND090438-0391
SHIM¤ 1.75MM,ELEMENT HOLDER
SN: 19030-UP
-2шт.
|12
ND090438-0401
SHIM¤ 1.8MM,ELEMENT HOLDER
SN: 19030-UP
-2шт.
|12
ND090438-0411
SHIM¤ 1.85MM,ELEMENT HOLDER
SN: 19030-UP
-2шт.
|12
ND090438-0421
SHIM¤ 1.9MM,ELEMENT HOLDER
SN: 19030-UP
-2шт.
|12
ND090438-0431
SHIM¤ 1.95MM,ELEMENT HOLDER
SN: 19030-UP
-2шт.
|12
ND090438-0441
SHIM¤ 2.0MM,ELEMENT HOLDER
SN: 19030-UP
-2шт.
|12
ND090438-0451
SHIM¤ 2.05MM,ELEMENT HOLDER
SN: 19030-UP
-2шт.
|12
ND090438-0461
SHIM¤ 2.1MM,ELEMENT HOLDER
SN: 19030-UP
-2шт.
|12
ND090438-0471
SHIM¤ 2.15MM,ELEMENT HOLDER
SN: 19030-UP
-2шт.
|12
ND090438-0481
SHIM¤ 2.2MM,ELEMENT HOLDER
SN: 19030-UP
-2шт.
|12
ND090438-0491
SHIM¤ 2.25MM,ELEMENT HOLDER
SN: 19030-UP
-2шт.
|12
ND090438-0501
SHIM¤ 2.3MM,ELEMENT HOLDER
SN: 19030-UP
-2шт.
15
ND90258-08001
WASHER
SN: 19030-UP
12шт.
18
ND90208-04610
WASHER¤ 0.1MM
SN: 19030-UP
-2шт.
|18
ND949013-5140
WASHER¤ 0.15MM
SN: 19030-UP
-2шт.
|18
ND949013-5930
WASHER¤ 0.3MM
SN: 19030-UP
-2шт.
20
ND090367-0040
BUSHING
SN: 19030-UP
1шт.
Выбрано товаров: 40
