|1
6221-13-1100
CYLINDER HEAD ASS'Y
SN: 19030-UP
1шт.
1
0
HEAD,CYLINDER
SN: 19030-UP
1шт.
2
6221-15-1310
GUIDE,VALVE
SN: 24891-UP
12шт.
|2
0
GUIDE,VALVE
SN: 19030-24890
12шт.
3
6221-13-1360
SEAT,INTAKE VALVE (STD)
SN: 22226-UP
6шт.
|3
0
SEAT,INTAKE VALVE (STD)
SN: 19030-22225
6шт.
|3
6221-19-1360
SEAT¤ 0.25MM,INTAKE VALVE (OS)
SN: 22226-UP
6шт.
|3
0
SEAT¤ 0.25MM,INTAKE VALVE (OS)
SN: 19030-22225
6шт.
|3
6221-18-1360
SEAT¤ 0.50MM,INTAKE VALVE (OS)
SN: 22226-UP
6шт.
|3
0
SEAT¤ 0.50MM,INTAKE VALVE (OS)
SN: 19030-22225
6шт.
|3
6221-17-1360
SEAT¤ 0.75MM,INTAKE VALVE (OS)
SN: 22226-UP
6шт.
|3
0
SEAT¤ 0.75MM,INTAKE VALVE (OS)
SN: 19030-22225
6шт.
|3
6221-16-1360
SEAT¤ 1.00MM,INTAKE VALVE (OS)
SN: 22226-UP
6шт.
|3
0
SEAT¤ 1.00MM,INTAKE VALVE (OS)
SN: 19030-22225
6шт.
4
6221-11-1320
SEAT,EXHAUST VALVE (STD)
SN: 19030-UP
6шт.
|4
6221-19-1320
SEAT¤ 0.25MM,EXHAUST VALVE (OS)
SN: 19030-UP
6шт.
|4
6221-18-1320
SEAT¤ 0.50MM,EXHAUST VALVE (OS)
SN: 19030-UP
6шт.
|4
6221-17-1320
SEAT¤ 0.75MM,EXHAUST VALVE (OS)
SN: 19030-UP
6шт.
|4
6221-16-1320
SEAT¤ 1.00MM,EXHAUST VALVE (OS)
SN: 19030-UP
6шт.
5
07046-41810
PLUG
SN: 19030-UP
9шт.
6
07046-42816
PLUG
SN: 19030-UP
17шт.
7
07046-44016
PLUG
SN: 19030-UP
4шт.
8
07043-70108
PLUG
SN: 19030-UP
7шт.
9
6221-43-4110
VALVE,INTAKE
SN: 19030-UP
6шт.
10
6221-43-4210
VALVE,EXHAUST
SN: 19030-UP
6шт.
11
6221-41-4510
GUIDE,SPRING
SN: 19030-UP
12шт.
12
6136-42-4520
COTTER,VALVE
SN: 19030-UP
24шт.
13
6221-41-4410
SPRING,VALVE
SN: 19030-UP
12шт.
14
6221-43-4540
SEAL,VALVE
SN: 19030-UP
12шт.
15
6221-41-4550
CAP,STEM
SN: 19030-UP
12шт.
16
6221-17-1810
GASKET,HEAD (K1)
SN: 19030-UP
1шт.
17
6221-11-1610
BOLT
SN: 19030-UP
26шт.
