Запчасти Komatsu SAA6D108E-2A-P ТОПЛ. НАСОС (РЕГУЛЯТОР) (/) (ВНУТР. ЧАСТИ) ДВИГАТЕЛЬ

|1

6222-73-1111

INJECTION PUMP ASS'Y

SN: 34724-UP

1шт.

|1

0

INJECTION PUMP ASS'Y

SN: 19030-34723

1шт.

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.A4010-B2D1 T0 A4010-G2D1.

-1шт.

|$$4

THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

ND190800-4581

GOVERNOR ASS'Y

SN: 34724-UP

1шт.

|1

ND190800-4580

GOVERNOR ASS'Y

SN: 19030-34723

1шт.

|$$7

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.A4010-D2D1 T0 A4010-F2D1.

-1шт.

1

ND090810-0540

HOUSING

SN: 19030-UP

1шт.

2

ND090878-0260

PLATE

SN: 19030-UP

1шт.

3

ND091024-0031

SCREW,ADJUSTING

SN: 19030-UP

2шт.

4

ND090901-0150

LEVER ASS'Y,TENSION

SN: 19030-UP

1шт.

5

ND090940-0480

LEVER ASS'Y

SN: 19030-UP

1шт.

6

ND90400-02101

E-RING

SN: 19030-UP

1шт.

7

ND090959-0160

LEVER ASS'Y,CONTROL

SN: 19030-UP

1шт.

8

ND090894-0010

E-RING

SN: 19030-UP

1шт.

9

ND090987-0010

SHIM

SN: 19030-UP

1шт.

10

ND948053-0051

NUT

SN: 19030-UP

2шт.

11

ND091046-0010

SLIDER,SUPPORTING

SN: 19030-UP

1шт.

12

ND090970-0350

SHACKLE ASS'Y

SN: 19030-UP

1шт.

13

ND949130-0050

KEY

SN: 19030-UP

1шт.

14

ND090840-0310

FLYWEIGHT ASS'Y

SN: 19030-UP

1шт.

15

ND949015-0500

WASHER¤ 2.5MM,SPRING

SN: 19030-UP

1шт.

16

ND090844-0010

NUT

SN: 19030-UP

1шт.

17

ND090860-0200

SLEEVE SUB ASS'Y,GOVERNOR

SN: 19030-UP

1шт.

18

ND090868-0040

PLATE,THRUST

SN: 19030-UP

1шт.

19

ND90567-30000

RING,SNAP

SN: 19030-UP

1шт.

20

ND949013-4090

WASHER¤ 0.1MM

SN: 19030-UP

-2шт.

|20

ND949013-4060

WASHER¤ 0.2MM

SN: 19030-UP

-2шт.

|20

ND949013-4070

WASHER¤ 0.3MM

SN: 19030-UP

-2шт.

|20

ND949013-4080

WASHER¤ 0.4MM

SN: 19030-UP

-2шт.

|20

ND949013-4100

WASHER¤ 1.0MM

SN: 19030-UP

-2шт.

21

ND090880-0110

LEVER,SWIVEL

SN: 19030-UP

1шт.

22

ND949071-0090

WASHER,SNAP

SN: 19030-UP

2шт.

23

ND090992-0410

SPRING,CONTROL

SN: 19030-UP

1шт.

24

ND090993-0200

SPRING,START

SN: 19030-UP

1шт.

25

ND090224-0140

PLUG,SCREW

SN: 19030-UP

1шт.

26

ND949018-1550

WASHER

SN: 19030-UP

1шт.

27

ND949130-0030

KEY

SN: 19030-UP

1шт.

28

ND090119-0160

GASKET,BODY

SN: 19030-UP

1шт.

29

ND090823-0420

GASKET

SN: 19030-UP

1шт.

30

ND090245-0230

SCREW

SN: 19030-UP

1шт.

31

ND090222-0120

WASHER

SN: 19030-UP

2шт.

32

ND949047-6880

BOLT,WITH WASHER

SN: 19030-UP

2шт.

33

ND949047-6910

BOLT,WITH WASHER

SN: 19030-UP

1шт.

34

ND949047-6890

BOLT,WITH WASHER

SN: 19030-UP

4шт.

35

ND949047-6900

BOLT,WITH WASHER

SN: 19030-UP

1шт.
