Запчасти Komatsu SAA6D108E-2A-C ТОПЛ. НАСОС (ПОДКАЧИВАЮЩ. НАСОС) (ВНУТР. ЧАСТИ) ДВИГАТЕЛЬ

|1

6222-73-1111

INJECTION PUMP ASS'Y

SN: 34724-UP

1шт.

|1

0

INJECTION PUMP ASS'Y

SN: 19030-34723

1шт.

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.A4010-B2D1 T0 A4010-G2D1.

-1шт.

|$$4

THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

ND092100-1761

FEED PUMP ASS'Y

SN: 19030-UP

1шт.

1

ND092120-0370

HOUSING

SN: 19030-UP

1шт.

2

ND092168-0150

ROD,PUSH

SN: 19030-UP

1шт.

3

ND092171-0011

PISTON

SN: 19030-UP

1шт.

4

ND092182-0060

SPRING,PISTON

SN: 19030-UP

1шт.

5

ND092184-0021

PLUG,CHAMBER

SN: 19030-UP

1шт.

6

ND949018-1240

WASHER¤ 1MM

SN: 19030-UP

1шт.

7

ND092174-0050

TAPPET

SN: 19030-UP

1шт.

8

ND092176-0010

ROLLER,TAPPET

SN: 19030-UP

1шт.

9

ND092178-0040

PIN,ROLLER

SN: 19030-UP

1шт.

10

ND092179-0070

BLOCK,SLIDING

SN: 19030-UP

2шт.

11

ND949072-0940

RING,SNAP

SN: 19030-UP

1шт.

12

ND092121-0011

VALVE,CHECK

SN: 19030-UP

2шт.

13

ND092124-0010

SPRING,VALVE

SN: 19030-UP

2шт.

14

ND092130-0220

PUMP ASS'Y,PRIMING

SN: 19030-UP

1шт.

15

ND092126-0010

PLUG,CHAMBER

SN: 19030-UP

1шт.

16

ND092125-0010

GASKET

SN: 19030-UP

2шт.

17

ND090061-0011

COVER

SN: 19030-UP

1шт.

18

ND949180-0310

SCREW

SN: 19030-UP

1шт.

19

ND949181-0420

NIPPLE

SN: 19030-UP

1шт.

20

ND092223-0070

SCREW

SN: 19030-UP

1шт.

21

ND092220-0040

FILTER,FUEL

SN: 19030-UP

1шт.

22

ND090222-0070

WASHER

SN: 19030-UP

4шт.
