Запчасти Komatsu SAA6D108E-2A-C ТОПЛ. НАСОС (РЕГУЛЯТОР) (/) (ВНУТР. ЧАСТИ) ДВИГАТЕЛЬ

|1

6222-73-1111

INJECTION PUMP ASS'Y

SN: 34724-UP

1шт.

|1

0

INJECTION PUMP ASS'Y

SN: 19030-34723

1шт.

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.A4010-B2D1 T0 A4010-G2D1.

-1шт.

|$$4

THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

ND190800-4581

GOVERNOR ASS'Y

SN: 34724-UP

1шт.

|1

ND190800-4580

GOVERNOR ASS'Y

SN: 19030-34723

1шт.

|$$7

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.A4010-D2D1 T0 A4010-F2D1.

-1шт.

1

ND091011-2020

COVER

SN: 19030-UP

1шт.

2

ND949192-2580

COLLAR

SN: 19030-UP

1шт.

3

ND091031-0151

NUT,CAP

SN: 19030-UP

1шт.

4

ND091006-0190

SCREW,ADJUSTING

SN: 19030-UP

1шт.

5

ND090944-0610

BUSHING

SN: 34724-UP

1шт.

|5

ND090944-0310

BUSHING

SN: 19030-34723

1шт.

6

ND090989-0010

SHAFT,LEVER SUPPORT

SN: 19030-UP

1шт.

7

ND090991-0010

PLUG

SN: 19030-UP

2шт.

8

ND090560-0370

CAPSULE,FULL STOP

SN: 19030-UP

1шт.

9

ND949140-6330

O-RING

SN: 19030-UP

1шт.

10

ND090892-0160

BUSHING,LEVER

SN: 19030-UP

2шт.

11

ND949140-5760

O-RING

SN: 19030-UP

2шт.

|12

ND090910-0870

ADAPTER ASS'Y

SN: 19030-UP

1шт.

12

ND090911-0010

SCREW,ADAPTER

SN: 19030-UP

1шт.

13

ND090919-0010

ADAPTER

SN: 19030-UP

1шт.

14

ND090918-0020

SPRING,GOVERNOR

SN: 19030-UP

1шт.

15

ND090894-0010

E-RING

SN: 19030-UP

1шт.

16

ND949013-3880

WASHER¤ 0.1MM

SN: 19030-UP

-2шт.

|16

ND949013-4040

WASHER¤ 0.2MM

SN: 19030-UP

-2шт.

|16

ND949013-4020

WASHER¤ 0.25MM

SN: 19030-UP

-2шт.

|16

ND949013-4030

WASHER¤ 0.5MM

SN: 19030-UP

-2шт.

|16

ND949013-7880

WASHER¤ 1.0MM

SN: 19030-UP

-2шт.

17

ND090923-0011

NUT,ADAPTER LOCK

SN: 19030-UP

1шт.

18

ND949047-1760

BOLT

SN: 19030-UP

4шт.

19

ND949047-1750

BOLT

SN: 19030-UP

2шт.

20

ND949150-2690

SEAL,OIL

SN: 19030-UP

1шт.

21

ND091071-1420

LEVER,ADJUSTING

SN: 19030-UP

1шт.

22

ND091071-4111

LEVER,ADJUSTING

SN: 19030-UP

1шт.

23

ND949047-1190

BOLT

SN: 19030-UP

1шт.

24

ND091094-0060

CAP,LEVER

SN: 19030-UP

1шт.

25

ND091090-0940

LEVER

SN: 19030-UP

1шт.

26

ND949047-1790

BOLT

SN: 19030-UP

2шт.

27

ND91418-06161

BOLT

SN: 19030-UP

2шт.

28

ND091050-0410

PLATE,COVER

SN: 19030-UP

1шт.

29

ND949047-2701

BOLT

SN: 34724-UP

2шт.

|29

ND949047-2700

BOLT

SN: 19030-34723

2шт.

30

ND91418-06141

BOLT

SN: 19030-UP

3шт.

31

ND91418-06201

BOLT

SN: 19030-UP

2шт.

32

ND090241-0010

WASHER¤ 1.6MM

SN: 19030-UP

1шт.

33

ND090923-0080

NUT,CAP

SN: 19030-UP

1шт.

34

ND949062-1270

PACKING,RUBBER PLATE

SN: 19030-UP

1шт.

35

ND091038-0040

SPRING

SN: 19030-UP

1шт.

36

ND949140-6170

O-RING

SN: 19030-UP

1шт.

37

ND091016-0360

BUSHING

SN: 34724-UP

1шт.

|37

ND091016-0020

BUSHING

SN: 19030-34723

1шт.

38

ND091043-0010

COVER

SN: 19030-UP

1шт.

39

ND091038-0050

SPRING

SN: 19030-UP

1шт.

40

ND091035-0240

SHAFT

SN: 19030-UP

1шт.

41

ND091036-0010

CUP

SN: 19030-UP

1шт.

42

ND091034-0130

LEVER

SN: 19030-UP

1шт.

43

ND091042-0220

SPRING

SN: 19030-UP

1шт.

44

ND091033-0030

PLATE

SN: 19030-UP

1шт.

45

ND091038-0030

SPRING

SN: 19030-UP

1шт.

46

ND90218-06140

WASHER¤ 0.50MM

SN: 19030-UP

1шт.

47

ND90577-05000

E-RING

SN: 19030-UP

1шт.

48

ND192600-0420

COMPENSATOR SUB A.

SN: 19030-UP

1шт.

49

ND949140-4670

O-RING

SN: 19030-UP

1шт.

50

ND090813-0141

PIN

SN: 19030-UP

1шт.

51

ND090940-0530

LEVER ASS'Y

SN: 19030-UP

1шт.

52

ND091042-1230

SPRING

SN: 19030-UP

1шт.

53

ND090944-0440

BUSHING

SN: 19030-UP

1шт.

54

ND949013-8210

WASHER¤ 0.3MM

SN: 19030-UP

-2шт.

|54

ND949013-8220

WASHER¤ 0.6MM

SN: 19030-UP

-2шт.

|54

ND949013-8230

WASHER¤ 0.9MM

SN: 19030-UP

-2шт.

55

ND949050-3390

NUT

SN: 19030-UP

1шт.

56

ND949018-1020

WASHER¤ 1.0MM

SN: 19030-UP

2шт.

57

ND949140-5740

O-RING

SN: 19030-UP

1шт.

58

ND090222-0120

WASHER

SN: 19030-UP

2шт.

59

ND949180-0060

SCREW

SN: 19030-UP

1шт.

60

ND090944-0410

BUSHING

SN: 19030-UP

1шт.

61

ND090894-0070

E-RING

SN: 19030-UP

1шт.

62

ND949181-0430

JOINT

SN: 19030-UP

1шт.
