Запчасти Komatsu SAA6D108E-2A-C ТОПЛ. НАСОС (НАСОС) (/) (ВНУТР. ЧАСТИ) ДВИГАТЕЛЬ

|1

6222-73-1111

INJECTION PUMP ASS'Y

SN: 34724-UP

1шт.

|1

0

INJECTION PUMP ASS'Y

SN: 19030-34723

1шт.

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.A4010-B2D1 T0 A4010-G2D1.

-1шт.

|$$4

THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

ND190100-0612

PUMP ASS'Y

SN: 34724-UP

1шт.

|1

ND190100-0610

PUMP ASS'Y

SN: 19030-34723

1шт.

|$$7

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.A4010-B2D1 AND A4010-C2D1.

-1шт.

1

ND090110-5720

HOUSING

SN: 34724-UP

1шт.

|1

ND090110-4350

HOUSING

SN: 19030-34723

1шт.

2

ND949043-0010

STUD

SN: 19030-UP

3шт.

3

ND090206-0240

GASKET

SN: 19030-UP

1шт.

4

ND090191-1400

CAMSHAFT

SN: 19030-UP

1шт.

5

ND949101-0140

BEARING,ROLLER

SN: 19030-UP

1шт.

6

ND090193-0050

RING,ADJUST

SN: 19030-UP

1шт.

7

ND090194-0410

PLATE¤ 0.03MM

SN: 19030-UP

-2шт.

|7

ND090194-0070

PLATE¤ 0.1MM

SN: 19030-UP

-2шт.

|7

ND090194-0340

PLATE¤ 0.12MM

SN: 19030-UP

-2шт.

|7

ND090194-0350

PLATE¤ 0.14MM

SN: 19030-UP

-2шт.

|7

ND090194-0080

PLATE¤ 0.15MM

SN: 19030-UP

-2шт.

|7

ND090194-0360

PLATE¤ 0.18MM

SN: 19030-UP

-2шт.

|7

ND090194-0090

PLATE¤ 0.3MM

SN: 19030-UP

-2шт.

|7

ND090194-0100

PLATE¤ 0.5MM

SN: 19030-UP

-2шт.

8

ND949150-2820

SEAL,OIL

SN: 19030-UP

1шт.

9

ND090201-0501

COVER,BEARING

SN: 19030-UP

1шт.

10

ND91418-06201

BOLT

SN: 19030-UP

4шт.

11

ND090433-0020

RETAINER,BEARING

SN: 19030-UP

1шт.

12

ND090361-0240

BEARING,CENTER

SN: 34724-UP

1шт.

|12

ND090361-0180

BEARING,CENTER

SN: 19030-34723

1шт.

13

ND949006-7300

SCREW

SN: 34724-UP

2шт.

|13

ND949006-6510

SCREW

SN: 19030-34723

2шт.

14

ND090248-0010

WASHER

SN: 19030-UP

3шт.

15

ND090215-0060

SCREW

SN: 19030-UP

1шт.

16

ND090317-0140

PLUG,SCREW

SN: 19030-UP

1шт.

17

ND090193-0060

RING,ADJUST

SN: 19030-UP

1шт.

18

ND090222-0070

WASHER,UNION

SN: 19030-UP

4шт.

19

ND949180-0310

SCREW

SN: 19030-UP

1шт.

20

ND949140-0380

O-RING

SN: 19030-UP

1шт.

21

ND90258-06001

WASHER

SN: 19030-UP

3шт.

22

ND90160-06051

NUT

SN: 19030-UP

3шт.

23

ND090244-0160

SCREW

SN: 19030-UP

2шт.

24

ND949101-0130

BEARING,ROLLER

SN: 19030-UP

1шт.

25

ND090194-0420

PLATE¤ 0.03MM

SN: 19030-UP

-2шт.

|25

ND090194-0300

PLATE¤ 0.1MM

SN: 19030-UP

-2шт.

|25

ND090194-0370

PLATE¤ 0.12MM

SN: 19030-UP

-2шт.

|25

ND090194-0380

PLATE¤ 0.14MM

SN: 19030-UP

-2шт.

|25

ND090194-0310

PLATE¤ 0.16MM

SN: 19030-UP

-2шт.

|25

ND090194-0390

PLATE¤ 0.18MM

SN: 19030-UP

-2шт.

|25

ND090194-0320

PLATE¤ 0.3MM

SN: 19030-UP

-2шт.

|25

ND090194-0330

PLATE¤ 0.5MM

SN: 19030-UP

-2шт.

26

ND949018-0350

WASHER

SN: 19030-UP

1шт.

27

ND949018-0350

WASHER

SN: 19030-UP

2шт.

28

ND090012-0350

NUT

SN: 19030-UP

1шт.

29

ND090048-0050

WASHER

SN: 19030-UP

1шт.

30

ND90458-05750

KEY,WOODRUFF

SN: 19030-UP

1шт.

31

ND949018-1550

WASHER

SN: 19030-UP

1шт.

32

ND949140-3690

O-RING

SN: 19030-UP

1шт.

33

ND090222-0070

WASHER

SN: 19030-UP

2шт.

34

ND090310-0370

VALVE ASS'Y,OVER FLOW

SN: 19030-UP

1шт.

35

ND092575-0220

SHAFT

SN: 19030-UP

1шт.

36

ND090018-0650

COVER,RACK

SN: 19030-UP

1шт.

37

ND090910-2100

ADAPTER ASS'Y

SN: 19030-UP

1шт.

38

ND948053-0100

NUT

SN: 19030-UP

1шт.

39

ND090032-0040

CAP

SN: 19030-UP

1шт.
