Запчасти Komatsu SAA6D107E-2C СТАРТЕР (№7-) СТАРТЕР, .KW

Схема запчастей Komatsu SAA6D107E-2C - СТАРТЕР (№7-) СТАРТЕР, .KW
39
5
33
46
31
11
45
7
6
8
9
20
10
28
27
26
38
35
24
25
12
42
36
44
14
15
16
17
19
29
37
43
23
30
32
1
34
3
41
39
22
37
21
40
4
2
18
13
39
5
33
46
31
11
45
7
6
8
9
20
10
28
27
26
38
35
24
25
12
42
36
44
14
15
16
17
19
29
37
43
23
30
32
1
34
3
41
39
22
37
21
40
4
2
18
13

Артикул

Название

Примечание

Количество

|$0

600-863-5130

Starting Motor Assembly

SN: 26600007-UP

1шт.

1

ND028100-5410

Yoke Assembly

SN: 26600007-UP

1шт.

2

ND028200-5250

Armature Assembly

SN: 26600007-UP

1шт.

3

ND949100-3161

Bearing, Ball

SN: 26600007-UP

1шт.

3

ND949100-5290

Bearing, Ball

SN: 26600007-UP

1шт.

4

ND949100-3540

Bearing, Ball

SN: 26600007-UP

1шт.

4

ND028300-6551

Clutch Assembly

SN: 26600007-UP

1шт.

5

ND028099-3270

Starting Motor Kit

SN: 26600007-UP

1шт.

6

ND028300-6751

Clutch Assembly

SN: 26600007-UP

1шт.

7

ND949100-4500

Bearing, Ball

SN: 26600007-UP

1шт.

8

ND949100-1920

Bearing, Ball

SN: 26600007-UP

1шт.

9

ND949170-4040

Spring

SN: 26600007-UP

1шт.

10

ND028381-0071

Shaft

SN: 26600007-UP

1шт.

11

ND128401-5621

Housing

SN: 26600007-UP

1шт.

12

ND153400-9890

Switch Assembly

SN: 26600007-UP

1шт.

13

ND128099-5770

Starting Motor Kit

SN: 26600007-UP

1шт.

14

ND028099-5100

Starting Motor Kit

SN: 26600007-UP

1шт.

15

ND053660-0443

Plunger

SN: 26600007-UP

1шт.

16

ND053404-0240

Gasket

SN: 26600007-UP

1шт.

17

ND053505-0290

Cover

SN: 26600007-UP

1шт.

18

ND053480-7560

Bolt Assembly

SN: 26600007-UP

1шт.

19

ND949047-4440

Bolt

SN: 26600007-UP

3шт.

20

ND028065-0250

Bushing

SN: 26600007-UP

1шт.

21

ND028510-0880

Holder Assembly, Brush

SN: 26600007-UP

1шт.

22

ND028520-0011

Spring

SN: 26600007-UP

4шт.

23

ND128501-1090

Frame

SN: 26600007-UP

1шт.

24

ND949120-0240

Ball

SN: 26600007-UP

1шт.

25

ND949170-4070

Spring

SN: 26600007-UP

1шт.

26

ND028371-3210

Pinion

SN: 26600007-UP

1шт.

27

ND028306-0070

Roller

SN: 26600007-UP

5шт.

28

ND028063-0030

Retainer

SN: 26600007-UP

1шт.

29

ND028062-0130

Cover

SN: 26600007-UP

1шт.

30

ND949042-3680

Bolt

SN: 26600007-UP

1шт.

31

ND90801-10050

O-ring

SN: 26600007-UP

3шт.

32

ND949042-3690

Bolt

SN: 26600007-UP

1шт.

33

ND949006-4720

Screw

SN: 26600007-UP

3шт.

34

ND949056-4480

Nut

SN: 26600007-UP

1шт.

35

ND028327-0171

Retainer

SN: 26600007-UP

1шт.

36

ND90258-10001

Washer

SN: 26600007-UP

1шт.

37

ND028901-0361

Seal

SN: 26600007-UP

2шт.

38

ND028371-3200

Pinion

SN: 26600007-UP

1шт.

39

ND949007-6530

Screw

SN: 26600007-UP

4шт.

40

ND028530-1090

Brush Assembly

SN: 26600007-UP

2шт.

41

ND028530-1100

Brush Assembly

SN: 26600007-UP

2шт.

42

ND949007-6850

Screw

SN: 26600007-UP

1шт.

43

ND028062-5790

Cover

SN: 26600007-UP

1шт.

44

ND90170-10061

Nut

SN: 26600007-UP

1шт.

45

ND028901-5190

Seal

SN: 26600007-UP

1шт.

46

ND90200-06241

Washer

SN: 26600007-UP

3шт.
