Запчасти Komatsu SAA6D102E-2L СТАРТЕР (7.KW) ДВИГАТЕЛЬ

|$0

6738-82-6810

STARTING MOTOR ASS'Y,PRODUCTION (F1)

SN: .-UP

1шт.

|$1

1316 576 H91

STARTING MOTOR ASS'Y,SERVICE

SN: .-UP

1шт.

1

1308 948 H1

YOKE ASS'Y,STARTER

SN: .-UP

1шт.

2

1308 949 H1

ARMATURE ASS'Y,STARTER

SN: .-UP

1шт.

3

1308 950 H1

BEARING,BALL

SN: .-UP

1шт.

4

1308 951 H1

BEARING,BALL

SN: .-UP

1шт.

5

1308 952 H1

BEARING,BALL

SN: .-UP

1шт.

|$7

1308 862 H91

CLUTCH ASS'Y,STARTER

SN: .-UP

1шт.

6

1308 863 H1

STARTER KIT,PINION

SN: .-UP

1шт.

7

1308 953 H91

CLUTCH ASS'Y,STARTER

SN: .-UP

1шт.

8

1316 570 H1

BEARING,BALL (FRONT)

SN: .-UP

1шт.

9

1308 865 H1

BEARING,BALL (REAR)

SN: .-UP

1шт.

10

1316 550 H91

SPRING,COMPRESSION COIL

SN: .-UP

1шт.

11

1308 867 H1

SHAFT

SN: .-UP

1шт.

12

1316 571 H1

HOUSING,STARTER

SN: .-UP

1шт.

13

1316 572 H91

SWITCH ASS'Y,MAGNETIC

SN: .-UP

1шт.

14

1316 573 H1

STARTER KIT,TERMINAL KIT M

SN: .-UP

1шт.

15

1308 957 H1

STARTER KIT,TERMINAL KIT C

SN: .-UP

1шт.

16

1308 958 H1

PLUNGER

SN: .-UP

1шт.

17

1308 872 H1

GASKET,SWITCH A

SN: .-UP

1шт.

18

1308 873 H1

COVER,SOLENOID

SN: .-UP

1шт.

19

1308 960 H1

BOLT ASS'Y,WASHER

SN: .-UP

3шт.

20

1308 875 H1

BUSHING,DRAIN

SN: .-UP

1шт.

21

1308 961 H1

HOLDER ASS'Y,STARTER BRUSH

SN: .-UP

1шт.

22

1308 962 H1

SPRING,BRUSH

SN: .-UP

4шт.

23

1316 574 H1

FRAME,STARTER END

SN: .-UP

1шт.

24

1308 879 H1

BALL,STEEL

SN: .-UP

1шт.

25

1308 880 H1

SPRING,COMPRESSION COIL

SN: .-UP

1шт.

26

1308 964 H1

PINION,STARTER

SN: .-UP

1шт.

27

1308 882 H1

ROLLER,CLUTCH

SN: .-UP

5шт.

28

1308 883 H1

RETAINER

SN: .-UP

1шт.

29

1316 557 H1

COVER

SN: .-UP

1шт.

30

1308 965 H1

BOLT,THROUGH

SN: .-UP

1шт.

31

1308 966 H1

BOLT,THROUGH

SN: .-UP

1шт.

32

1308 890 H1

SCREW

SN: .-UP

3шт.

33

1308 893 H1

NUT,HEXAGON

SN: .-UP

2шт.

34

1308 884 H1

RETAINER,SNAP

SN: .-UP

1шт.

35

1308 894 H1

WASHER,SPRING

SN: .-UP

2шт.

36

1316 558 H1

SEAL,STARTER

SN: .-UP

2шт.

37

1308 968 H1

PINION,STARTER

SN: .-UP

1шт.

38

1308 889 H1

SCREW,WASHER

SN: .-UP

4шт.

39

1308 969 H1

BRUSH ASS'Y,(+) SUB-ASSEMBLY, STARTER

SN: .-UP

2шт.

40

1308 970 H1

BRUSH ASS'Y,(-) SUB-ASSEMBLY, STARTER

SN: .-UP

2шт.

41

1308 892 H1

SCREW,WASHER

SN: .-UP

1шт.

42

1308 895 H1

COVER

SN: .-UP

1шт.

43

1308 898 H1

NUT

SN: .-UP

1шт.

44

1308 896 H1

SEAL,STARTER

SN: .-UP

1шт.

45

1308 897 H1

WASHER,PLATE

SN: .-UP

3шт.

46

1308 891 H1

O-RING

SN: .-UP

3шт.

47

1316 575 H1

BOLT,STARTER

SN: .-UP

1шт.

|$50

09842-A0481

PLATE, CAUTION,DO NOT JUMP START

SN: .-UP

1шт.

|$$52

(F1)

-1шт.

|$$53

PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER THE SERVICE STARTING MOTOR.

-1шт.
