Запчасти Komatsu SAA4D95LE-5D ЧАСТИ PERДЛЯMANCE(№-) ЧАСТИ PERДЛЯMANCE

1

6271-31-2110

Piston, Standard

SN: 535838-UP

4шт.

1

6271-39-2110

Piston, Oversize 0.25mm

SN: 535838-UP

4шт.

1

6271-38-2110

Piston, Oversize 0.50mm

SN: 535838-UP

4шт.

2

6207-31-2420

Pin, Piston, Piston

SN: 535838-UP

4шт.

3

04065-03012

Ring, Snap

SN: 535838-UP

8шт.

3

6271-31-2100

Piston Ring Assembly, Standard

SN: 535838-UP

4шт.

4

Ring, Top, Standard

SN: 535838-UP

1шт.

5

Ring, Second, Standard

SN: 535838-UP

1шт.

6

Ring, Oil, Standard

SN: 535838-UP

1шт.

6

6271-39-2100

Piston Ring Assembly, Oversize 0.25mm

SN: 535838-UP

4шт.

6

Ring, Top, Oversize 0.25mm

SN: 535838-UP

1шт.

6

Ring, Second, Oversize 0.25mm

SN: 535838-UP

1шт.

6

Ring, Oil, Oversize 0.25mm

SN: 535838-UP

1шт.

6

6271-38-2100

Piston Ring Assembly, Oversize 0.50mm

SN: 535838-UP

4шт.

6

Ring, Top, Oversize 0.50mm

SN: 535838-UP

1шт.

6

Ring, Second, Oversize 0.50mm

SN: 535838-UP

1шт.

6

Ring, Oil, Oversize 0.50mm

SN: 535838-UP

1шт.

6

6207-31-3800

Connecting Rod Assembly

SN: 535838-UP

4шт.

7

6207-31-3810

Rod

SN: 535838-UP

1шт.

8

6207-31-3130

Bushing

SN: 535838-UP

1шт.

9

6204-31-3310

Bolt

SN: 535838-UP

2шт.

|$21

6208-31-3500

Crank Pin Metal Assembly, Standard

SN: 535838-UP

4шт.

|$22

6207-39-3900

Crank Pin Metal Assembly, Undersized, 0.25mm

SN: 535838-UP

4шт.

|$23

6207-38-3900

Crank Pin Metal Assembly, Undersized, 0.50mm

SN: 535838-UP

4шт.

|$24

6207-37-3900

Crank Pin Metal Assembly, Undersized, 0.75mm

SN: 535838-UP

4шт.

|$25

6207-36-3900

Crank Pin Metal Assembly, Undersized, 1.00mm

SN: 535838-UP

4шт.

10

Metal,Upper

SN: 535838-UP

4шт.

10

Metal,Upper

SN: 535838-UP

4шт.

10

Metal,Upper

SN: 535838-UP

4шт.

10

Metal,Upper

SN: 535838-UP

4шт.

10

Metal,Upper

SN: 535838-UP

4шт.

11

Metal,Lower

SN: 535838-UP

4шт.

11

Metal,Lower

SN: 535838-UP

4шт.

11

Metal,Lower

SN: 535838-UP

4шт.

11

Metal,Lower

SN: 502660-UP

4шт.

11

Metal,Lower

SN: 502660-UP

4шт.
