Запчасти Komatsu SAA4D95LE-5D БЛОК ЦИЛИНДРОВ, КОЛЕНВАЛ БЛОК ЦИЛИНДРОВ

Схема запчастей Komatsu SAA4D95LE-5D - БЛОК ЦИЛИНДРОВ, КОЛЕНВАЛ БЛОК ЦИЛИНДРОВ
1
2
3
4
5
5
6
6

Артикул

Название

Примечание

Количество

|1

6271-31-1110

Crankshaft Assembly

SN: 26501795-UP

1шт.

1

Crankshaft

SN: 26501795-UP

1шт.

2

6271-31-1220

Gear, Crankshaft

SN: 26501795-UP

1шт.

3

6206-31-1530

Key

SN: 26501795-UP

1шт.

|3

6204-21-8100

Main Metal Assembly, Standard

SN: 26501795-UP

5шт.

|3

6204-29-8100

Main Metal Assembly, Undersize 0.25mm

SN: 26501795-UP

5шт.

|3

6204-28-8100

Main Metal Assembly, Undersize 0.50mm

SN: 26501795-UP

5шт.

|3

6204-27-8100

Main Metal Assembly, Undersize 0.75mm

SN: 26501795-UP

5шт.

|3

6204-26-8100

Main Metal Assembly, Undersize 1.00mm

SN: 26501795-UP

5шт.

4

Metal, Upper, Standard

SN: 26501795-UP

1шт.

|4

Metal, Upper, Undersize 0.25mm

SN: 26501795-UP

1шт.

|4

Metal, Upper, Undersize 0.50mm

SN: 26501795-UP

1шт.

|4

Metal, Upper, Undersize 0.75mm

SN: 26501795-UP

1шт.

|4

Metal, Upper, Undersize 1.00mm

SN: 26501795-UP

1шт.

5

Metal, Lower, Standard

SN: 26501795-UP

1шт.

|5

Metal, Lower, Undersize 0.25mm

SN: 26501795-UP

1шт.

|5

Metal, Lower, Undersize 0.50mm

SN: 26501795-UP

1шт.

|5

Metal, Lower, Undersize 0.75mm

SN: 26501795-UP

1шт.

|5

Metal, Lower, Undersize 1.00mm

SN: 26501795-UP

1шт.

6

6204-21-8600

Thrust Metal Assembly, Standard

SN: 26501795-UP

1шт.

|6

6204-29-8600

Thrust Metal Assembly, Oversize 0.25mm

SN: 26501795-UP

1шт.

|6

6204-28-8600

Thrust Metal Assembly, Oversize 0.50mm

SN: 26501795-UP

1шт.

|6

6204-27-8600

Thrust Metal Assembly, Oversize 0.75mm

SN: 26501795-UP

1шт.

|6

6204-26-8600

Thrust Metal Assembly, Oversize 1.00mm

SN: 26501795-UP

1шт.

|6

6204-21-8510

Metal, Thrust, Standard

SN: 26501795-UP

2шт.

|6

Metal, Thrust, Oversize 0.25mm

SN: 26501795-UP

2шт.

|6

Metal, Thrust, Oversize 0.50mm

SN: 26501795-UP

2шт.

|6

Metal, Thrust, Oversize 0.75mm

SN: 26501795-UP

2шт.

|6

Metal, Thrust, Oversize 1.00mm

SN: 26501795-UP

2шт.

Выбрано товаров: 29
