Запчасти Komatsu SAA4D95LE_5A ПОРШЕНЬ (№-) AA ДВИГАТЕЛЬ

1

6271-31-2110

PISTON, STANDARD

SN: 502022-UP

4шт.

|$2

6271-39-2110

PISTON, OVERSIZE 0.25MM

SN: 502022-UP

4шт.

|$3

6271-38-2110

PISTON, OVERSIZE 0.50MM

SN: 502022-UP

4шт.

2

6207-31-2420

PIN, PISTON

SN: 502022-UP

4шт.

3

04065-03012

RING, SNAP

SN: 502022-UP

8шт.

|$6

6271-31-2100

PISTON RING ASSEMBLY, STANDARD

SN: 502022-UP

4шт.

4

0

RING, TOP, STANDARD

SN: 502022-UP

1шт.

5

0

RING, SECOND, STANDARD

SN: 502022-UP

1шт.

6

0

RING, OIL, STANDARD

SN: 502022-UP

1шт.

|$10

6271-39-2100

PISTON RING ASSEMBLY, OVERSIZE 0.25MM

SN: 502022-UP

4шт.

|$11

0

RING, TOP, OVERSIZE 0.25MM

SN: 502022-UP

1шт.

|$12

0

RING, SECOND, OVERSIZE 0.25MM

SN: 502022-UP

1шт.

|$13

0

RING, OIL, OVERSIZE 0.25MM

SN: 502022-UP

1шт.

|$14

6271-38-2100

PISTON RING ASSEMBLY, OVERSIZE 0.50MM

SN: 502022-UP

4шт.

|$15

0

RING, TOP, OVERSIZE 0.50MM

SN: 502022-UP

1шт.

|$16

0

RING, SECOND, OVERSIZE 0.50MM

SN: 502022-UP

1шт.

|$17

0

RING, OIL, OVERSIZE 0.50MM

SN: 502022-UP

1шт.

|$18

6207-31-3800

CONNECTING ROD ASSEMBLY

SN: 502022-UP

4шт.

7

0

ROD

SN: 502022-UP

1шт.

8

0

BUSHING

SN: 502022-UP

1шт.

9

6204-31-3310

BOLT

SN: 502022-UP

2шт.

|$22

6208-31-3500

CRANK PIN METAL ASSEMBLY, STANDARD

SN: 502022-UP

4шт.

10

0

METAL

SN: 502022-UP

1шт.

11

0

METAL

SN: 502022-UP

1шт.

|$25

6207-39-3900

CRANK PIN METAL ASSEMBLY, UNDERSIZED 0.25MM

SN: 502022-UP

4шт.

|$26

0

METAL

SN: 502022-UP

1шт.

|$27

0

METAL

SN: 502022-UP

1шт.

|$28

6207-38-3900

CRANK PIN METAL ASSEMBLY, UNDERSIZED 0.50MM

SN: 502022-UP

4шт.

|$29

0

METAL

SN: 502022-UP

1шт.

|$30

0

METAL

SN: 502022-UP

1шт.

|$31

6207-37-3900

CRANK PIN METAL ASSEMBLY, UNDERSIZED 0.75MM

SN: 502022-UP

4шт.

|$32

0

METAL

SN: 502022-UP

1шт.

|$33

0

METAL

SN: 502022-UP

1шт.

|$34

6207-36-3900

CRANK PIN METAL ASSEMBLY, UNDERSIZED 1.00MM

SN: 502022-UP

4шт.

|$35

0

METAL

SN: 502022-UP

1шт.

|$36

0

METAL

SN: 502022-UP

1шт.
