Запчасти Komatsu SAA4D95LE_5A СТАРТЕР (.KW) (ВНУТР. ЧАСТИ) ДВИГАТЕЛЬ

|$1

600-813-4461

STARTING MOTOR ASS'Y,(4.5KW)

SN: 500001-UP

1шт.

1

ND028100-2881

YOKE ASS'Y

SN: 500001-UP

1шт.

2

ND028062-0130

COVER

SN: 500001-UP

1шт.

3

ND028099-3570

STARTER KIT

SN: 500001-UP

2шт.

4

ND028200-1590

ARMATURE ASS'Y

SN: 500001-UP

1шт.

5

ND949100-1930

BEARING,BALL

SN: 500001-UP

1шт.

6

ND949100-1750

BEARING,BALL

SN: 500001-UP

1шт.

7

ND028300-5091

CLUTCH ASS'Y

SN: 500001-UP

1шт.

7

ND028099-3310

STARTER KIT

SN: 500001-UP

1шт.

7

ND028300-6750

CLUTCH ASS'Y

SN: 500001-UP

1шт.

7

ND949100-4500

BEARING,BALL, FRONT

SN: 500001-UP

1шт.

7

ND949100-1920

BEARING,BALL, REAR

SN: 500001-UP

1шт.

7

ND949170-4040

SPRING

SN: 500001-UP

1шт.

7

ND028381-0071

SHAFT

SN: 500001-UP

1шт.

8

ND228401-1440

HOUSING ASS'Y

SN: 500001-UP

1шт.

9

ND153400-2192

MAGNETIC SWITCH A.

SN: 500001-UP

1шт.

9

ND128099-5830

STARTER KIT

SN: 500001-UP

1шт.

9

ND028099-3160

STARTER KIT

SN: 500001-UP

1шт.

9

ND053660-0443

PLUNGER

SN: 500001-UP

1шт.

9

ND053404-0240

GASKET

SN: 500001-UP

1шт.

9

ND053505-0290

COVER

SN: 500001-UP

1шт.

9

ND053480-7560

BOLT ASS'Y

SN: 500001-UP

1шт.

10

ND028510-5390

BRUSH HOLDER ASS'Y

SN: 500001-UP

1шт.

11

ND949173-0571

SPRING

SN: 500001-UP

4шт.

12

ND028501-7880

FRAME

SN: 500001-UP

1шт.

13

ND128961-0010

BALL

SN: 500001-UP

1шт.

14

ND949170-4070

SPRING

SN: 500001-UP

1шт.

15

ND028371-1500

PINION

SN: 500001-UP

1шт.

16

ND028306-0070

ROLLER

SN: 500001-UP

5шт.

17

ND028063-0030

RETAINER

SN: 500001-UP

1шт.

18

ND028327-0171

RETAINER

SN: 500001-UP

1шт.

19

ND949042-3741

BOLT

SN: 500001-UP

2шт.

20

ND90804-10050

O-RING

SN: 500001-UP

2шт.

21

ND949011-5700

WASHER

SN: 500001-UP

2шт.

22

ND90801-10050

O-RING

SN: 500001-UP

3шт.

23

ND949007-6530

SCREW

SN: 500001-UP

2шт.

24

ND949020-0600

WASHER

SN: 500001-UP

1шт.

25

ND90170-10061

NUT

SN: 500001-UP

1шт.

26

ND90258-10001

WASHER

SN: 500001-UP

1шт.

27

ND949017-1290

WASHER

SN: 500001-UP

1шт.

28

ND90258-06001

WASHER

SN: 500001-UP

2шт.

29

ND949006-6910

SCREW

SN: 500001-UP

3шт.

30

ND90200-06241

WASHER

SN: 500001-UP

3шт.

31

ND028062-5790

COVER

SN: 500001-UP

1шт.

32

ND90260-00501

WASHER

SN: 500001-UP

1шт.

33

ND949007-6850

SCREW

SN: 500001-UP

1шт.

34

ND028901-5190

SEAL

SN: 500001-UP

1шт.

35

ND949056-4480

NUT

SN: 500001-UP

1шт.
