Запчасти Komatsu SAA4D95LE-5 ГЕНЕРАТОР, AMP.(№79-) ГЕНЕРАТОР, AMP.

|$0

600-861-6510

Alternator Assembly, 60A

SN: 501795-UP

1шт.

|$1

ND121400-5100

Frame Assembly

SN: 501795-UP

1шт.

1

ND021100-4210

Stator Assembly

SN: 501795-UP

1шт.

2

ND021401-4980

Frame,Front

SN: 501795-UP

1шт.

3

ND021411-0570

Plate

SN: 501795-UP

1шт.

4

ND021045-0530

Collar

SN: 501795-UP

1шт.

5

ND949006-5590

Screw

SN: 501795-UP

4шт.

6

ND949100-5010

Bearing, Ball

SN: 501795-UP

1шт.

7

ND949043-2000

Bolt

SN: 501795-UP

4шт.

8

ND021501-6690

Frame,Rear

SN: 501795-UP

1шт.

9

ND021580-4690

Rectifier Assembly

SN: 501795-UP

1шт.

10

ND021620-2720

Holder Assembly, Brush

SN: 501795-UP

1шт.

11

ND126000-2320

Regulator Assembly

SN: 501795-UP

1шт.

12

ND021551-2390

Cover,Rear

SN: 501795-UP

1шт.

13

ND021605-1970

Bushing

SN: 501795-UP

4шт.

14

ND021605-2150

Bushing

SN: 501795-UP

1шт.

15

ND949006-5460

Screw

SN: 501795-UP

3шт.

16

ND949007-5110

Screw

SN: 501795-UP

2шт.

|$18

ND91310-04251

Screw

SN: 501795-UP

2шт.

17

ND949056-2481

Nut

SN: 501795-UP

7шт.

18

ND949056-3300

Nut

SN: 501795-UP

1шт.

19

ND021200-8380

Rotor Assembly

SN: 501795-UP

1шт.

20

ND949100-2790

Bearing, Ball

SN: 501795-UP

1шт.

|$23

ND949100-3980

Bearing, Ball

SN: 501795-UP

1шт.

21

ND021506-0070

Cover

SN: 501795-UP

1шт.

22

ND121041-9920

Pulley

SN: 501795-UP

1шт.

23

ND949056-2520

Nut

SN: 501795-UP

1шт.

24

ND021626-0190

Seal

SN: 501795-UP

1шт.

25

ND021626-0250

Seal

SN: 501795-UP

1шт.

26

ND021542-0160

Washer

SN: 501795-UP

1шт.

27

ND949006-6401

Screw

SN: 501795-UP

1шт.

28

ND949007-6280

Screw

SN: 501795-UP

4шт.

29

ND021602-5230

Plate

SN: 501795-UP

1шт.
