Запчасти Komatsu SAA4D95LE-5 ЧАСТИ PERДЛЯMANCE (№79-9) G ДВИГАТЕЛЬ АКСЕССУАРЫ И ДР.

1

6271-31-2110

Piston, Standard

SN: 501795-502659

4шт.

|$1

6271-39-2110

Piston, Oversize 0.25mm

SN: 501795-502659

4шт.

|$2

6271-38-2110

Piston, Oversize 0.50mm

SN: 501795-502659

4шт.

2

6207-31-2420

Pin, Piston, Piston

SN: 501795-502659

4шт.

3

04065-03012

Ring, Snap

SN: 501795-502659

8шт.

|$5

6271-31-2100

Piston Ring Assembly, Standard

SN: 501795-502659

4шт.

4

0

Ring, Top, Standard

SN: 501795-502659

1шт.

5

0

Ring, Second, Standard

SN: 501795-502659

1шт.

6

0

Ring, Oil, Standard

SN: 501795-502659

1шт.

|$9

6271-39-2100

Piston Ring Assembly, Oversize 0.25mm

SN: 501795-502659

4шт.

|$10

0

Ring, Top, Oversize 0.25mm

SN: 501795-502659

1шт.

|$11

0

Ring, Second, Oversize 0.25mm

SN: 501795-502659

1шт.

|$12

0

Ring, Oil, Oversize 0.25mm

SN: 501795-502659

1шт.

|$13

6271-38-2100

Piston Ring Assembly, Oversize 0.50mm

SN: 501795-502659

4шт.

|$14

0

Ring, Top, Oversize 0.50mm

SN: 501795-502659

1шт.

|$15

0

Ring, Second, Oversize 0.50mm

SN: 501795-502659

1шт.

|$16

0

Ring, Oil, Oversize 0.50mm

SN: 501795-502659

1шт.

|$17

6207-31-3101

Connecting Rod Assembly

SN: 501795-502659

4шт.

7

0

Rod, Connecting

SN: 501795-502659

1шт.

8

0

Cap

SN: 501795-502659

1шт.

9

6207-31-3130

Bushing

SN: 501795-502659

1шт.

10

6204-31-3310

Bolt

SN: 501795-502659

2шт.

11

6207-31-3140

Pin

SN: 501795-502659

2шт.

|$23

6208-31-3400

Metal Assembly, Crank Pin, Standard

SN: 501795-502659

4шт.

|$24

6208-39-3400

Metal Assembly, Crank Pin, Undersize 0.25mm

SN: 501795-502659

4шт.

|$25

6208-38-3400

Metal Assembly, Crank Pin, Undersize 0.50mm

SN: 501795-502659

4шт.

|$26

6208-37-3400

Metal Assembly, Crank Pin, Undersize 0.75mm

SN: 501795-502659

4шт.

|$27

6208-36-3400

Metal Assembly, Crank Pin, Undersize 1.00mm

SN: 501795-502659

4шт.

12

0

Metal, Upper, Standard

SN: 501795-502659

1шт.

|$29

0

Metal, Upper, Undersize 0.25mm

SN: 501795-502659

1шт.

|$30

0

Metal, Upper, Undersize 0.50mm

SN: 501795-502659

1шт.

|$31

0

Metal, Upper, Undersize 0.75mm

SN: 501795-502659

1шт.

|$32

0

Metal, Upper, Undersize 1.00mm

SN: 501795-502659

1шт.

13

0

Metal, Lower, Standard

SN: 501795-502659

1шт.

|$34

0

Metal, Lower, Undersize 0.25mm

SN: 501795-502659

1шт.

|$35

0

Metal, Lower, Undersize 0.50mm

SN: 501795-502659

1шт.

|$36

0

Metal, Lower, Undersize 0.75mm

SN: 501795-502659

1шт.

|$37

0

Metal, Lower, Undersize 1.00mm

SN: 501795-502659

1шт.
