Запчасти Komatsu SAA4D95LE-5 СТАРТЕР, .KW F ДВИГАТЕЛЬ ЭЛЕКТРИКА

|$0

600-813-4461

Starting Motor Assembly, 4.5KW

SN: 501795-UP

1шт.

1

ND028100-2881

Yoke Assembly

SN: 501795-UP

1шт.

2

ND028062-0130

Cover

SN: 501795-UP

1шт.

3

ND028099-3570

Starting Motor Kit

SN: 501795-UP

2шт.

4

ND028200-1590

Armature Assembly

SN: 501795-UP

1шт.

5

ND949100-1930

Bearing, Ball

SN: 501795-UP

1шт.

6

ND949100-1750

Bearing, Ball

SN: 501795-UP

1шт.

7

ND028300-5091

Clutch Assembly

SN: 501795-UP

1шт.

|$8

ND028099-3310

Stator Kit

SN: 501795-UP

1шт.

|$9

ND028300-6750

Clutch Assembly

SN: 501795-UP

1шт.

|$10

ND949100-4500

Bearing, Ball,Front

SN: 501795-UP

1шт.

|$11

ND949100-1920

Bearing, Ball,Rear

SN: 501795-UP

1шт.

|$12

ND949170-4040

Spring

SN: 501795-UP

1шт.

|$13

ND028381-0071

Shaft

SN: 501795-UP

1шт.

8

ND228401-1440

Housing Assembly

SN: 501795-UP

1шт.

9

ND153400-2192

Magnet Assembly, Switch

SN: 501795-UP

1шт.

|$16

ND128099-5830

Starting Motor Kit

SN: 501795-UP

1шт.

|$17

ND028099-3160

Starting Motor Kit

SN: 501795-UP

1шт.

|$18

ND053660-0443

Plunger

SN: 501795-UP

1шт.

|$19

ND053404-0240

Gasket

SN: 501795-UP

1шт.

|$20

ND053505-0290

Cover

SN: 501795-UP

1шт.

|$21

ND053480-7560

Bolt Assembly

SN: 501795-UP

1шт.

10

ND028510-5390

Holder Assembly, Brush

SN: 501795-UP

1шт.

11

ND949173-0571

Spring

SN: 501795-UP

4шт.

12

ND028501-7880

Frame

SN: 501795-UP

1шт.

13

ND128961-0010

Ball

SN: 501795-UP

1шт.

14

ND949170-4070

Spring

SN: 501795-UP

1шт.

15

ND028371-1500

Pinion

SN: 501795-UP

1шт.

16

ND028306-0070

Roller

SN: 501795-UP

5шт.

17

ND028063-0030

Retainer

SN: 501795-UP

1шт.

18

ND028327-0171

Retainer

SN: 501795-UP

1шт.

19

ND949042-3741

Bolt

SN: 501795-UP

2шт.

20

ND90804-10050

O-Ring

SN: 501795-UP

2шт.

21

ND949011-5700

Washer

SN: 501795-UP

2шт.

22

ND90801-10050

O-Ring

SN: 501795-UP

3шт.

23

ND949007-6530

Screw

SN: 501795-UP

2шт.

24

ND949020-0600

Washer

SN: 501795-UP

1шт.

25

ND90170-10061

Nut

SN: 501795-UP

1шт.

26

ND90258-10001

Washer, Spring

SN: 501795-UP

1шт.

27

ND949017-1290

Washer

SN: 501795-UP

1шт.

28

ND90258-06001

Washer

SN: 501795-UP

2шт.

29

ND949006-6910

Screw

SN: 501795-UP

3шт.

30

ND90200-06241

Washer

SN: 501795-UP

3шт.

31

ND028062-5790

Cover

SN: 501795-UP

1шт.

32

ND90260-00501

Washer

SN: 501795-UP

1шт.

33

ND949007-6850

Screw

SN: 501795-UP

1шт.

34

ND028901-5190

Seal

SN: 501795-UP

1шт.

35

ND949056-4480

Nut

SN: 501795-UP

1шт.
