Запчасти Komatsu SAA4D95LE-5 БЛОК ЦИЛИНДРОВ(№79-) БЛОК ЦИЛИНДРОВ

|$0

6271-31-1110

Crankshaft Assembly

SN: 501795-UP

1шт.

1

Crankshaft

SN: 501795-UP

1шт.

2

6271-31-1220

Gear, Crankshaft, Crankshaft

SN: 501795-UP

1шт.

3

6206-31-1530

Key

SN: 501795-UP

1шт.

|$4

6204-21-8100

Main Metal Assembly, Stabdard

SN: 501795-UP

5шт.

|$5

6204-29-8100

Main Metal Assembly, Undersize 0.25mm

SN: 501795-UP

5шт.

|$6

6204-28-8100

Main Metal Assembly, Undersize 0.50mm

SN: 501795-UP

5шт.

|$7

6204-27-8100

Main Metal Assembly, Undersize 0.75mm

SN: 501795-UP

5шт.

|$8

6204-26-8100

Main Metal Assembly, Unsersize 1.00mm

SN: 501795-UP

5шт.

4

Metal, Upper, Stabdard

SN: 501795-UP

1шт.

|$10

Metal, Upper, Underzise 0.25mm

SN: 501795-UP

1шт.

|$11

Metal, Upper, Undersize 0.50mm

SN: 501795-UP

1шт.

|$12

Metal, Upper, Undersize 0.75mm

SN: 501795-UP

1шт.

|$13

Metal, Upper, Undersize 1.00mm

SN: 501795-UP

1шт.

5

Metal, Lower, Stabdard

SN: 501795-UP

1шт.

|$15

Metal, Lower, Undersize 0.25mm

SN: 501795-UP

1шт.

|$16

Metal, Lower, Undersize 0.50mm

SN: 501795-UP

1шт.

|$17

Metal, Lower, Undersize 0.75mm

SN: 501795-UP

1шт.

|$18

Metal, Lower, Undersize 1.00mm

SN: 501795-UP

1шт.

|$19

6204-21-8600

Thrust Metal Assembly, Stabdard, Standard

SN: 501795-UP

1шт.

|$20

6204-29-8600

Thrust Metal Assembly, Oversize 0.25mm

SN: 501795-UP

1шт.

|$21

6204-28-8600

Thrust Metal Assembly, Oversize 0.50mm

SN: 501795-UP

1шт.

|$22

6204-27-8600

Thrust Metal Assembly, Oversize 0.75mm

SN: 501795-UP

1шт.

|$23

6204-26-8600

Thrust Metal Assembly, Oversize 1.00mm

SN: 501795-UP

1шт.

6

6204-21-8510

Metal, Thrust, Stabdard, Thrust, Standard

SN: 501795-UP

2шт.

|$25

Metal, Thrust, Oversize 0.25mm, Oversize 0.25mm

SN: 501795-UP

2шт.

|$26

Metal, Thrust, Oversize 0.50mm, Oversize 0.50mm

SN: 501795-UP

2шт.

|$27

Metal, Thrust, Oversize 0.75mm, Oversize 0.75mm

SN: 501795-UP

2шт.

|$28

Metal, Thrust, Oversize 1.00mm, Oversize 1.00mm

SN: 501795-UP

2шт.
