Запчасти Komatsu SAA12V140E-3D КОЛЕНВАЛ (№9-) КОЛЕНВАЛ

|$0

6219-31-1100

Crankshaft Assembly

SN: 502369-UP

1шт.

1

Crankshaft

SN: 502369-UP

1шт.

2

6215-31-1140

Gear, Crankshaft

SN: 502369-UP

1шт.

3

04010-00728

Key

SN: 502369-UP

1шт.

3

6215-21-8000

Main Metal Assembly

SN: 502369-UP

1шт.

3

6215-21-8011

Main Metal Assembly,Standerd

SN: 502369-UP

6шт.

3

6215-29-8011

Main Metal Assembly,Undersized 0.25mm

SN: 502369-UP

6шт.

3

6215-28-8011

Main Metal Assembly,Undersized 0.50mm

SN: 502369-UP

6шт.

3

6215-27-8011

Main Metal Assembly,Undersized 0.75mm

SN: 502369-UP

6шт.

3

6215-26-8011

Main Metal Assembly,Undersized 1.00mm

SN: 502369-UP

6шт.

4

Metal, Upper, Standard

SN: 502369-UP

1шт.

4

Metal,Upper,Undersized 0.25mm

SN: 502369-UP

1шт.

4

Metal,Upper,Undersized 0.50mm

SN: 502369-UP

1шт.

4

Metal,Upper,Undersized 0.75mm

SN: 502369-UP

1шт.

4

Metal,Upper,Undersized 1.00mm

SN: 502369-UP

1шт.

5

Metal, Lower, Standard

SN: 502369-UP

1шт.

5

Metal,Lower,Undersized 0.25mm

SN: 502369-UP

1шт.

5

Metal,Lower,Undersized 0.50mm

SN: 502369-UP

1шт.

5

Metal,Lower,Undersized 0.75mm

SN: 502369-UP

1шт.

5

Metal,Lower,Undersized 1.00mm

SN: 502369-UP

1шт.

5

6215-21-8021

Main Metal Assembly,Standerd

SN: 502369-UP

1шт.

5

6215-29-8021

Main Metal Assembly,Undersized 0.25mm

SN: 502369-UP

1шт.

5

6215-28-8021

Main Metal Assembly,Undersized 0.50mm

SN: 502369-UP

1шт.

5

6215-27-8021

Main Metal Assembly,Undersized 0.75mm

SN: 502369-UP

1шт.

5

6215-26-8021

Main Metal Assembly,Undersized 1.00mm

SN: 502369-UP

1шт.

6

Metal, Upper, Standard

SN: 502369-UP

1шт.

6

Metal,Upper,Undersized 0.25mm

SN: 502369-UP

1шт.

6

Metal,Upper,Undersized 0.50mm

SN: 502369-UP

1шт.

6

Metal,Upper,Undersized 0.75mm

SN: 502369-UP

1шт.

6

Metal,Upper,Undersized 1.00mm

SN: 502369-UP

1шт.

7

Metal, Lower, Standard

SN: 502369-UP

1шт.

7

Metal,Lower,Undersized 0.25mm

SN: 502369-UP

1шт.

7

Metal,Lower,Undersized 0.50mm

SN: 502369-UP

1шт.

7

Metal,Lower,Undersized 0.75mm

SN: 502369-UP

1шт.

7

Metal,Lower,Undersized 1.00mm

SN: 502369-UP

1шт.

8

6215-21-8050

Metal Assembly,Standerd

SN: 502369-UP

1шт.

8

6215-29-8050

Metal Assembly,Oversize 0.25mm

SN: 502369-UP

1шт.

8

6215-28-8050

Metal Assembly,Oversize 0.50mm

SN: 502369-UP

1шт.

8

6215-27-8050

Metal Assembly,Oversize 0.75mm

SN: 502369-UP

1шт.

8

6215-26-8050

Metal Assembly,Oversize 1.00mm

SN: 502369-UP

1шт.

8

Metal,Thrust,Standerd

SN: 502369-UP

3шт.

8

Metal,Thrust,Oversize 0.25mm

SN: 502369-UP

3шт.

8

Metal,Thrust,Oversize 0.50mm

SN: 502369-UP

3шт.

8

Metal,Thrust,Oversize 0.75mm

SN: 502369-UP

3шт.

8

Metal,Thrust,Oversize 1.00mm

SN: 502369-UP

3шт.

|$0

6219-31-1100

Crankshaft Assembly

SN: 502369-UP

1шт.

1

Crankshaft

SN: 502369-UP

1шт.

2

6215-31-1140

Gear, Crankshaft

SN: 502369-UP

1шт.

3

04010-00728

Key

SN: 502369-UP

1шт.

3

6215-21-8000

Main Metal Assembly

SN: 502369-UP

1шт.

3

6215-21-8011

Main Metal Assembly,Standerd

SN: 502369-UP

6шт.

3

6215-29-8011

Main Metal Assembly,Undersized 0.25mm

SN: 502369-UP

6шт.

3

6215-28-8011

Main Metal Assembly,Undersized 0.50mm

SN: 502369-UP

6шт.

3

6215-27-8011

Main Metal Assembly,Undersized 0.75mm

SN: 502369-UP

6шт.

3

6215-26-8011

Main Metal Assembly,Undersized 1.00mm

SN: 502369-UP

6шт.

4

Metal, Upper, Standard

SN: 502369-UP

1шт.

4

Metal,Upper,Undersized 0.25mm

SN: 502369-UP

1шт.

4

Metal,Upper,Undersized 0.50mm

SN: 502369-UP

1шт.

4

Metal,Upper,Undersized 0.75mm

SN: 502369-UP

1шт.

4

Metal,Upper,Undersized 1.00mm

SN: 502369-UP

1шт.

5

Metal, Lower, Standard

SN: 502369-UP

1шт.

5

Metal,Lower,Undersized 0.25mm

SN: 502369-UP

1шт.

5

Metal,Lower,Undersized 0.50mm

SN: 502369-UP

1шт.

5

Metal,Lower,Undersized 0.75mm

SN: 502369-UP

1шт.

5

Metal,Lower,Undersized 1.00mm

SN: 502369-UP

1шт.

5

6215-21-8021

Main Metal Assembly,Standerd

SN: 502369-UP

1шт.

5

6215-29-8021

Main Metal Assembly,Undersized 0.25mm

SN: 502369-UP

1шт.

5

6215-28-8021

Main Metal Assembly,Undersized 0.50mm

SN: 502369-UP

1шт.

5

6215-27-8021

Main Metal Assembly,Undersized 0.75mm

SN: 502369-UP

1шт.

5

6215-26-8021

Main Metal Assembly,Undersized 1.00mm

SN: 502369-UP

1шт.

6

Metal, Upper, Standard

SN: 502369-UP

1шт.

6

Metal,Upper,Undersized 0.25mm

SN: 502369-UP

1шт.

6

Metal,Upper,Undersized 0.50mm

SN: 502369-UP

1шт.

6

Metal,Upper,Undersized 0.75mm

SN: 502369-UP

1шт.

6

Metal,Upper,Undersized 1.00mm

SN: 502369-UP

1шт.

7

Metal, Lower, Standard

SN: 502369-UP

1шт.

7

Metal,Lower,Undersized 0.25mm

SN: 502369-UP

1шт.

7

Metal,Lower,Undersized 0.50mm

SN: 502369-UP

1шт.

7

Metal,Lower,Undersized 0.75mm

SN: 502369-UP

1шт.

7

Metal,Lower,Undersized 1.00mm

SN: 502369-UP

1шт.

8

6215-21-8050

Metal Assembly,Standerd

SN: 502369-UP

1шт.

8

6215-29-8050

Metal Assembly,Oversize 0.25mm

SN: 502369-UP

1шт.

8

6215-28-8050

Metal Assembly,Oversize 0.50mm

SN: 502369-UP

1шт.

8

6215-27-8050

Metal Assembly,Oversize 0.75mm

SN: 502369-UP

1шт.

8

6215-26-8050

Metal Assembly,Oversize 1.00mm

SN: 502369-UP

1шт.

8

Metal,Thrust,Standerd

SN: 502369-UP

3шт.

8

Metal,Thrust,Oversize 0.25mm

SN: 502369-UP

3шт.

8

Metal,Thrust,Oversize 0.50mm

SN: 502369-UP

3шт.

8

Metal,Thrust,Oversize 0.75mm

SN: 502369-UP

3шт.

8

Metal,Thrust,Oversize 1.00mm

SN: 502369-UP

3шт.
