Запчасти Komatsu SA8V170-1C ТОПЛ. НАСОС (НАСОС) (/)(№-) ТОПЛИВН. СИСТЕМА

|1

6164-71-1411

INJECTION PUMP ASS'Y

SN: 10516-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451A TO 0462A.

-1шт.

|$$3

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

DK103086-9140

PUMP ASS'Y

SN: 10516-UP

1шт.

|$$5

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451A AND 0451B.

-1шт.

1

DK133034-0100

PLUG

SN: 10516-UP

8шт.

2

DK029633-4010

O-RING

SN: 10516-UP

8шт.

3

DK133151-7420

PLUNGER ASS'Y

SN: 10516-UP

8шт.

4

DK133110-3120

VALVE,DELIVERY

SN: 10516-UP

8шт.

5

DK133112-0700

SPRING

SN: 10516-UP

8шт.

6

DK133115-1500

GASKET

SN: 10516-UP

8шт.

7

DK133116-3520

HOLDER,DELIVERY VALVE

SN: 10516-UP

8шт.

8

DK029632-5030

O-RING

SN: 10516-UP

8шт.

9

DK134117-0500

STOPPER

SN: 10516-UP

8шт.

10

DK133122-1420

PLATE

SN: 10516-UP

4шт.

11

DK133200-1920

TAPPET

SN: 10516-UP

8шт.

12

DK133201-0300

NUT

SN: 10516-UP

1шт.

13

DK133202-0400

BOLT

SN: 10516-UP

1шт.

14

DK133203-0400

PIN

SN: 10516-UP

1шт.

15

DK133204-0600

ROLLER

SN: 10516-UP

1шт.

16

DK133205-0300

BUSHING

SN: 10516-UP

1шт.

17

DK133215-0300

SPRING,PLUNGER

SN: 10516-UP

8шт.

18

DK133216-0200

SEAT,SPRING

SN: 10516-UP

8шт.

19

DK133217-0100

SEAT,SPRING

SN: 10516-UP

8шт.

20

DK133258-1900

RACK,CONTROL

SN: 10516-UP

1шт.

21

DK133226-0700

SCREW

SN: 10516-UP

1шт.

22

DK133516-0400

WASHER,LOCK

SN: 10516-UP

1шт.

23

DK133240-0100

PINION

SN: 10516-UP

8шт.

24

DK133241-0200

SLEEVE,CONTROL

SN: 10516-UP

8шт.

25

DK131242-0100

SCREW

SN: 10516-UP

8шт.
