Запчасти Komatsu SA8V170-1C ТОПЛИВН. ФОРСУНКА И СЛИВНАЯ ТРУБКА ТОПЛИВН. СИСТЕМА

|1

6162-13-3401

NOZZLE HOLDER ASS'Y

SN: 10040-UP

8шт.

1

6162-13-3110

HOLDER ASS'Y

SN: 10040-UP

1шт.

|$$3

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

2

DK150510-0700

ROD,PUSH

SN: 10040-UP

1шт.

3

DK150562-4500

SPRING,NOZZLE

SN: 10040-UP

1шт.

4

DK029998-0400

SHIM ASS'Y

SN: 10040-UP

1шт.

|4

DK150523-5000

SHIM¤ 0.50MM

SN: 10040-UP

-2шт.

|4

DK150523-5100

SHIM¤ 0.52MM

SN: 10040-UP

-2шт.

|4

DK150523-5200

SHIM¤ 0.54MM

SN: 10040-UP

-2шт.

|4

DK150523-5300

SHIM¤ 0.56MM

SN: 10040-UP

-2шт.

|4

DK150523-5400

SHIM¤ 0.58MM

SN: 10040-UP

-2шт.

|4

DK150523-5500

SHIM¤ 0.60MM

SN: 10040-UP

-2шт.

|4

DK150523-5600

SHIM¤ 0.62MM

SN: 10040-UP

-2шт.

|4

DK150523-5700

SHIM¤ 0.64MM

SN: 10040-UP

-2шт.

|4

DK150523-5800

SHIM¤ 0.66MM

SN: 10040-UP

-2шт.

|4

DK150523-5900

SHIM¤ 0.68MM

SN: 10040-UP

-2шт.

|4

DK150523-6000

SHIM¤ 0.70MM

SN: 10040-UP

-2шт.

|4

DK150523-6100

SHIM¤ 0.72MM

SN: 10040-UP

-2шт.

|4

DK150523-6200

SHIM¤ 0.74MM

SN: 10040-UP

-2шт.

|4

DK150523-6300

SHIM¤ 0.76MM

SN: 10040-UP

-2шт.

|4

DK150523-6400

SHIM¤ 0.78MM

SN: 10040-UP

-2шт.

|4

DK150523-6500

SHIM¤ 0.80MM

SN: 10040-UP

-2шт.

|4

DK150523-6600

SHIM¤ 0.82MM

SN: 10040-UP

-2шт.

|4

DK150523-6700

SHIM¤ 0.84MM

SN: 10040-UP

-2шт.

|4

DK150523-6800

SHIM¤ 0.86MM

SN: 10040-UP

-2шт.

|4

DK150523-6900

SHIM¤ 0.88MM

SN: 10040-UP

-2шт.

|4

DK150523-7000

SHIM¤ 0.90MM

SN: 10040-UP

-2шт.

|4

DK150523-7100

SHIM¤ 0.92MM

SN: 10040-UP

-2шт.

|4

DK150523-7200

SHIM¤ 0.94MM

SN: 10040-UP

-2шт.

|4

DK150523-7300

SHIM¤ 0.96MM

SN: 10040-UP

-2шт.

|4

DK150523-7400

SHIM¤ 0.98MM

SN: 10040-UP

-2шт.

|4

DK150523-7500

SHIM¤ 1.00MM

SN: 10040-UP

-2шт.

|4

DK150523-7600

SHIM¤ 1.02MM

SN: 10040-UP

-2шт.

|4

DK150523-7700

SHIM¤ 1.04MM

SN: 10040-UP

-2шт.

|4

DK150523-7800

SHIM¤ 1.06MM

SN: 10040-UP

-2шт.

|4

DK150523-7900

SHIM¤ 1.08MM

SN: 10040-UP

-2шт.

|4

DK150523-8000

SHIM¤ 1.10MM

SN: 10040-UP

-2шт.

|4

DK150523-8100

SHIM¤ 1.12MM

SN: 10040-UP

-2шт.

|4

DK150523-8200

SHIM¤ 1.14MM

SN: 10040-UP

-2шт.

|4

DK150523-8300

SHIM¤ 1.16MM

SN: 10040-UP

-2шт.

|4

DK150523-8400

SHIM¤ 1.18MM

SN: 10040-UP

-2шт.

|4

DK150523-8500

SHIM¤ 1.20MM

SN: 10040-UP

-2шт.

|4

DK150523-8600

SHIM¤ 1.22MM

SN: 10040-UP

-2шт.

|4

DK150523-8700

SHIM¤ 1.24MM

SN: 10040-UP

-2шт.

|4

DK150523-8800

SHIM¤ 1.26MM

SN: 10040-UP

-2шт.

|4

DK150523-8900

SHIM¤ 1.28MM

SN: 10040-UP

-2шт.

|4

DK150523-9000

SHIM¤ 1.30MM

SN: 10040-UP

-2шт.

|4

DK150523-9100

SHIM¤ 1.32MM

SN: 10040-UP

-2шт.

|4

DK150523-9200

SHIM¤ 1.34MM

SN: 10040-UP

-2шт.

|4

DK150523-9300

SHIM¤ 1.36MM

SN: 10040-UP

-2шт.

|4

DK150523-9400

SHIM¤ 1.38MM

SN: 10040-UP

-2шт.

|4

DK150523-9500

SHIM¤ 1.40MM

SN: 10040-UP

-2шт.

|4

DK150523-9600

SHIM¤ 1.42MM

SN: 10040-UP

-2шт.

|4

DK150523-9700

SHIM¤ 1.44MM

SN: 10040-UP

-2шт.

|4

DK150523-9800

SHIM¤ 1.46MM

SN: 10040-UP

-2шт.

|4

DK150523-9900

SHIM¤ 1.48MM

SN: 10040-UP

-2шт.

|4

DK150530-0000

SHIM¤ 1.50MM

SN: 10040-UP

-2шт.

|4

DK150530-0100

SHIM¤ 1.52MM

SN: 10040-UP

-2шт.

|4

DK150530-0200

SHIM¤ 1.54MM

SN: 10040-UP

-2шт.

5

DK150524-4400

SPACER

SN: 10040-UP

1шт.

6

DK150650-8000

NUT,RETAINING

SN: 10040-UP

1шт.

7

DK150628-1900

FLANGE

SN: 10040-UP

1шт.

8

6162-13-3421

NOZZLE

SN: 10040-UP

1шт.

9

6162-13-3510

BOLT

SN: 10040-UP

16шт.

|1

6162-13-3401

NOZZLE HOLDER ASS'Y

SN: 10040-UP

8шт.

1

6162-13-3110

HOLDER ASS'Y

SN: 10040-UP

1шт.

|$$3

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

2

DK150510-0700

ROD,PUSH

SN: 10040-UP

1шт.

3

DK150562-4500

SPRING,NOZZLE

SN: 10040-UP

1шт.

4

DK029998-0400

SHIM ASS'Y

SN: 10040-UP

1шт.

|4

DK150523-5000

SHIM¤ 0.50MM

SN: 10040-UP

-2шт.

|4

DK150523-5100

SHIM¤ 0.52MM

SN: 10040-UP

-2шт.

|4

DK150523-5200

SHIM¤ 0.54MM

SN: 10040-UP

-2шт.

|4

DK150523-5300

SHIM¤ 0.56MM

SN: 10040-UP

-2шт.

|4

DK150523-5400

SHIM¤ 0.58MM

SN: 10040-UP

-2шт.

|4

DK150523-5500

SHIM¤ 0.60MM

SN: 10040-UP

-2шт.

|4

DK150523-5600

SHIM¤ 0.62MM

SN: 10040-UP

-2шт.

|4

DK150523-5700

SHIM¤ 0.64MM

SN: 10040-UP

-2шт.

|4

DK150523-5800

SHIM¤ 0.66MM

SN: 10040-UP

-2шт.

|4

DK150523-5900

SHIM¤ 0.68MM

SN: 10040-UP

-2шт.

|4

DK150523-6000

SHIM¤ 0.70MM

SN: 10040-UP

-2шт.

|4

DK150523-6100

SHIM¤ 0.72MM

SN: 10040-UP

-2шт.

|4

DK150523-6200

SHIM¤ 0.74MM

SN: 10040-UP

-2шт.

|4

DK150523-6300

SHIM¤ 0.76MM

SN: 10040-UP

-2шт.

|4

DK150523-6400

SHIM¤ 0.78MM

SN: 10040-UP

-2шт.

|4

DK150523-6500

SHIM¤ 0.80MM

SN: 10040-UP

-2шт.

|4

DK150523-6600

SHIM¤ 0.82MM

SN: 10040-UP

-2шт.

|4

DK150523-6700

SHIM¤ 0.84MM

SN: 10040-UP

-2шт.

|4

DK150523-6800

SHIM¤ 0.86MM

SN: 10040-UP

-2шт.

|4

DK150523-6900

SHIM¤ 0.88MM

SN: 10040-UP

-2шт.

|4

DK150523-7000

SHIM¤ 0.90MM

SN: 10040-UP

-2шт.

|4

DK150523-7100

SHIM¤ 0.92MM

SN: 10040-UP

-2шт.

|4

DK150523-7200

SHIM¤ 0.94MM

SN: 10040-UP

-2шт.

|4

DK150523-7300

SHIM¤ 0.96MM

SN: 10040-UP

-2шт.

|4

DK150523-7400

SHIM¤ 0.98MM

SN: 10040-UP

-2шт.

|4

DK150523-7500

SHIM¤ 1.00MM

SN: 10040-UP

-2шт.

|4

DK150523-7600

SHIM¤ 1.02MM

SN: 10040-UP

-2шт.

|4

DK150523-7700

SHIM¤ 1.04MM

SN: 10040-UP

-2шт.

|4

DK150523-7800

SHIM¤ 1.06MM

SN: 10040-UP

-2шт.

|4

DK150523-7900

SHIM¤ 1.08MM

SN: 10040-UP

-2шт.

|4

DK150523-8000

SHIM¤ 1.10MM

SN: 10040-UP

-2шт.

|4

DK150523-8100

SHIM¤ 1.12MM

SN: 10040-UP

-2шт.

|4

DK150523-8200

SHIM¤ 1.14MM

SN: 10040-UP

-2шт.

|4

DK150523-8300

SHIM¤ 1.16MM

SN: 10040-UP

-2шт.

|4

DK150523-8400

SHIM¤ 1.18MM

SN: 10040-UP

-2шт.

|4

DK150523-8500

SHIM¤ 1.20MM

SN: 10040-UP

-2шт.

|4

DK150523-8600

SHIM¤ 1.22MM

SN: 10040-UP

-2шт.

|4

DK150523-8700

SHIM¤ 1.24MM

SN: 10040-UP

-2шт.

|4

DK150523-8800

SHIM¤ 1.26MM

SN: 10040-UP

-2шт.

|4

DK150523-8900

SHIM¤ 1.28MM

SN: 10040-UP

-2шт.

|4

DK150523-9000

SHIM¤ 1.30MM

SN: 10040-UP

-2шт.

|4

DK150523-9100

SHIM¤ 1.32MM

SN: 10040-UP

-2шт.

|4

DK150523-9200

SHIM¤ 1.34MM

SN: 10040-UP

-2шт.

|4

DK150523-9300

SHIM¤ 1.36MM

SN: 10040-UP

-2шт.

|4

DK150523-9400

SHIM¤ 1.38MM

SN: 10040-UP

-2шт.

|4

DK150523-9500

SHIM¤ 1.40MM

SN: 10040-UP

-2шт.

|4

DK150523-9600

SHIM¤ 1.42MM

SN: 10040-UP

-2шт.

|4

DK150523-9700

SHIM¤ 1.44MM

SN: 10040-UP

-2шт.

|4

DK150523-9800

SHIM¤ 1.46MM

SN: 10040-UP

-2шт.

|4

DK150523-9900

SHIM¤ 1.48MM

SN: 10040-UP

-2шт.

|4

DK150530-0000

SHIM¤ 1.50MM

SN: 10040-UP

-2шт.

|4

DK150530-0100

SHIM¤ 1.52MM

SN: 10040-UP

-2шт.

|4

DK150530-0200

SHIM¤ 1.54MM

SN: 10040-UP

-2шт.

5

DK150524-4400

SPACER

SN: 10040-UP

1шт.

6

DK150650-8000

NUT,RETAINING

SN: 10040-UP

1шт.

7

DK150628-1900

FLANGE

SN: 10040-UP

1шт.

8

6162-13-3421

NOZZLE

SN: 10040-UP

1шт.

9

6162-13-3510

BOLT

SN: 10040-UP

16шт.
