Артикул
Название
Примечание
Количество
|$0
6162-73-1410
INJECTION PUMP A.
SN: 15320-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0455 TO 0485.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$3
DK105235-1910
FEED PUMP ASS'Y
SN: 15320-UP
1шт.
1
DK152002-2220
HOUSING
SN: 15320-UP
1шт.
2
DK152100-1120
PISTON
SN: 15320-UP
1шт.
3
DK152104-0400
SPRING,PISTON
SN: 15320-UP
1шт.
4
DK152105-1500
PLUG
SN: 15320-UP
1шт.
5
DK152111-4620
TAPPET ASS'Y
SN: 15320-UP
1шт.
6
DK152112-0800
ROLLER
SN: 15320-UP
1шт.
8
DK152114-1600
GUIDE
SN: 15320-UP
2шт.
9
DK152115-0500
VALVE
SN: 15320-UP
4шт.
11
DK152117-0400
PLUG
SN: 15320-UP
3шт.
12
DK139716-0000
O-RING
SN: 15320-UP
1шт.
13
DK152121-0200
RING,SNAP
SN: 15320-UP
1шт.
14
DK152200-6120
PUMP,PRIMING
SN: 15320-UP
1шт.
15
DK152300-3620
BOLT,EYE
SN: 15320-UP
1шт.
16
DK029731-4680
BOLT,EYE
SN: 15320-UP
1шт.
17
DK029711-4430
EYE
SN: 15320-UP
1шт.
19
DK132400-0200
ADAPTER
SN: 15320-UP
2шт.
|$0
6162-73-1410
INJECTION PUMP A.
SN: 15320-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0455 TO 0485.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$3
DK105235-1910
FEED PUMP ASS'Y
SN: 15320-UP
1шт.
1
DK152002-2220
HOUSING
SN: 15320-UP
1шт.
2
DK152100-1120
PISTON
SN: 15320-UP
1шт.
3
DK152104-0400
SPRING,PISTON
SN: 15320-UP
1шт.
4
DK152105-1500
PLUG
SN: 15320-UP
1шт.
5
DK152111-4620
TAPPET ASS'Y
SN: 15320-UP
1шт.
6
DK152112-0800
ROLLER
SN: 15320-UP
1шт.
8
DK152114-1600
GUIDE
SN: 15320-UP
2шт.
9
DK152115-0500
VALVE
SN: 15320-UP
4шт.
11
DK152117-0400
PLUG
SN: 15320-UP
3шт.
12
DK139716-0000
O-RING
SN: 15320-UP
1шт.
13
DK152121-0200
RING,SNAP
SN: 15320-UP
1шт.
14
DK152200-6120
PUMP,PRIMING
SN: 15320-UP
1шт.
15
DK152300-3620
BOLT,EYE
SN: 15320-UP
1шт.
16
DK029731-4680
BOLT,EYE
SN: 15320-UP
1шт.
17
DK029711-4430
EYE
SN: 15320-UP
1шт.
19
DK132400-0200
ADAPTER
SN: 15320-UP
2шт.
Выбрано товаров: 48
