Запчасти Komatsu SA6D140-1C ТОПЛ. НАСОС (РЕГУЛЯТОР) (/)(№9-7) ТОПЛИВН. СИСТЕМА

|1

6212-71-1423

INJECTION PUMP A.

SN: 18866-20176

1шт.

|1

0

INJECTION PUMP A.

SN: 14953-18865

1шт.

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451B¤0461C¤0462C¤0471B AND 0481B.

-1шт.

|$$4

THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

ND190800-2702

GOVERNOR ASS'Y

SN: .-20176

1шт.

|1

0

GOVERNOR ASS'Y

SN: 14953-.

1шт.

|$$7

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0461C AND 0462C.

-1шт.

1

ND090995-0020

SPRING,START

SN: 14953-20176

1шт.

2

ND091006-0200

SCREW,ADJUSTING

SN: 14953-20176

1шт.

3

ND090944-0390

BUSHING

SN: 14953-20176

1шт.

4

ND091694-0140

GASKET

SN: 14953-20176

1шт.

5

ND949140-5740

O-RING

SN: 14953-20176

1шт.

6

ND949018-1020

WASHER¤ 1.0MM,COVER PLATE

SN: 14953-20176

2шт.

7

ND091031-0150

NUT,CAP

SN: 14953-20176

1шт.

8

ND949050-3390

NUT

SN: 14953-20176

1шт.

9

ND091051-0791

PLATE,COVER

SN: 14953-20176

1шт.

10

ND091031-0030

NUT,CAP

SN: 14953-20176

1шт.

11

ND090560-0240

CAPSULE,FULL STOP

SN: 14953-20176

1шт.

12

ND949053-0180

NUT

SN: 14953-20176

1шт.

13

ND090241-0010

WASHER¤ 1.6MM,NIPPLE

SN: 14953-20176

2шт.

14

ND090880-0150

LEVER,SWIVELLING

SN: 14953-20176

1шт.

15

ND091011-2180

COVER,GOVERNOR

SN: .-20176

1шт.

|15

ND091011-1980

COVER,GOVERNOR

SN: 14953-.

1шт.

16

ND090245-0300

SCREW,HOLLOW

SN: 14953-20176

1шт.

17

ND090252-0260

NIPPLE

SN: 14953-20176

1шт.

18

ND090224-0170

PLUG,SCREW

SN: 14953-20176

1шт.

19

ND090989-0020

SHAFT,LEVER SUPPORTING

SN: 14953-20176

1шт.

20

ND090991-0010

PLUG,SCREW

SN: 14953-20176

2шт.

21

ND949071-0090

WASHER

SN: 14953-20176

2шт.

22

ND949140-5760

O-RING

SN: 14953-20176

2шт.

23

ND090892-0170

BUSHING,LEVER

SN: .-20176

2шт.

|23

ND090892-0160

BUSHING,LEVER

SN: .-.

2шт.

|23

0

BUSHING,LEVER

SN: 14953-.

2шт.

24

ND090560-0270

CAPSULE,FULL STOP

SN: 14953-20176

1шт.

25

ND949053-0170

NUT

SN: 14953-20176

1шт.

26

ND949047-1190

BOLT

SN: 14953-20176

3шт.

27

ND91418-06251

BOLT

SN: 14953-20176

5шт.

28

ND949047-1750

BOLT

SN: 14953-20176

4шт.

29

ND949130-0030

KEY

SN: 14953-20176

1шт.

30

ND090222-0060

WASHER,UNION

SN: 14953-20176

2шт.

31

ND091094-0060

CAP,LEVER

SN: 14953-20176

1шт.

32

ND949047-1790

BOLT

SN: 14953-20176

2шт.

33

ND91418-06141

BOLT

SN: 14953-20176

4шт.

34

ND949150-2690

SEAL,OIL

SN: 14953-20176

1шт.

35

ND091071-3580

LEVER,ADJUSTING

SN: 14953-20176

1шт.

36

ND091071-4280

LEVER,ADJUSTING

SN: 14953-20176

1шт.

37

ND091013-0060

JOINT

SN: 14953-20176

1шт.

38

ND091014-0080

PIN,STOP

SN: 14953-20176

1шт.

39

ND949013-8210

WASHER¤ 0.3MM

SN: 14953-20176

-2шт.

|39

ND949013-8220

WASHER¤ 0.6MM

SN: 14953-20176

-2шт.

|39

ND949013-8230

WASHER¤ 0.9MM

SN: 14953-20176

-2шт.
