Запчасти Komatsu SA6D140-1B ТОПЛ. НАСОС (РЕГУЛЯТОР) (/) (ОГРАНИЧЕНИЯ ПО ВЫХЛОПУ ЕС)(№9-) ТОПЛИВН. СИСТЕМА

|1

6212-71-1241

INJECTION PUMP A.

SN: 16494-UP

1шт.

|1

0

INJECTION PUMP A.

SN: 10592-16493

1шт.

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0453¤0454¤0464¤0465¤0466¤ 0472 AND FIGS.0482.

-1шт.

|$$4

THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

ND090800-9883

GOVERNOR ASS'Y

SN: 16494-UP

1шт.

|1

0

GOVERNOR ASS'Y

SN: 10592-16493

1шт.

|$$7

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0464 TO 0466.

-1шт.

1

ND091524-0160

SCREW,STOPPER

SN: 10592-UP

1шт.

2

ND948053-0130

NUT

SN: 10592-UP

1шт.

3

ND949140-4670

O-RING

SN: 10592-UP

1шт.

4

ND91418-06201

BOLT

SN: 16494-UP

2шт.

|4

ND91418-06161

BOLT

SN: 10592-16493

2шт.

5

ND949047-1770

BOLT

SN: 10592-UP

1шт.

6

ND090222-0060

WASHER

SN: 10592-UP

2шт.

7

ND090252-0260

NIPPLE,OVER FLOW

SN: 10592-UP

1шт.

8

ND090245-0300

SCREW

SN: 10592-UP

1шт.

9

ND091011-1820

COVER,GOVERNOR

SN: 10592-UP

1шт.

10

ND091051-0200

PLATE

SN: 10592-UP

1шт.

11

ND949140-6210

O-RING

SN: 10592-UP

1шт.

12

ND949047-1790

BOLT

SN: 10592-UP

4шт.

13

ND949047-1740

BOLT

SN: 10592-UP

4шт.

14

ND949047-1780

BOLT

SN: 10592-UP

2шт.

15

ND949013-5040

WASHER¤ 0.1MM

SN: 10592-UP

-2шт.

|15

ND949013-1360

WASHER¤ 0.2MM

SN: 10592-UP

-2шт.

16

ND948053-0090

NUT

SN: 10592-UP

2шт.

17

ND192600-0170

COMPENSATOR SUB A.,BOOST

SN: 10592-UP

1шт.

18

ND090911-0220

SCREW,ADAPTER

SN: 10592-UP

1шт.

19

ND090251-0010

WASHER

SN: 10592-UP

2шт.

20

ND090923-0050

NUT,LOCK

SN: 10592-UP

1шт.

21

ND090911-0230

SCREW,ADAPTER

SN: 10592-UP

1шт.

22

ND090923-0011

NUT

SN: 10592-UP

1шт.

23

ND090917-0070

SEAT,SPRING

SN: 10592-UP

1шт.

24

ND090032-0040

CAP

SN: 10592-UP

1шт.

25

ND090918-2400

SPRING

SN: 10592-UP

1шт.

26

ND949018-0350

WASHER

SN: 10592-UP

2шт.

|27

ND090910-0421

ADAPTER ASS'Y

SN: 10592-UP

1шт.

27

ND090918-0441

SPRING

SN: 10592-UP

1шт.

28

ND090911-0061

SCREW

SN: 10592-UP

1шт.

29

ND090919-0170

ADAPTER

SN: 10592-UP

1шт.

30

ND090894-0010

E-RING

SN: 10592-UP

1шт.

31

ND90208-05000

WASHER

SN: 10592-UP

1шт.

32

ND949013-3910

SHIM¤ 0.2MM

SN: 10592-UP

-2шт.

|32

ND949013-3920

SHIM¤ 0.5MM

SN: 10592-UP

-2шт.

33

ND091050-0480

PLATE

SN: 10592-UP

1шт.

34

ND949140-6220

O-RING

SN: 10592-UP

1шт.

35

ND090918-2430

SPRING

SN: 10592-UP

1шт.

36

ND091337-0061

DAMPER

SN: 10592-UP

1шт.

37

ND949013-5550

WASHER

SN: 10592-UP

3шт.

38

ND091026-0040

SHAFT ASS'Y

SN: 10592-UP

1шт.

39

ND949150-2720

SEAL,OIL

SN: 10592-UP

2шт.

|40

ND091290-0281

LEVER ASS'Y

SN: 16494-UP

1шт.

|40

ND091290-0280

LEVER ASS'Y

SN: 10592-16493

1шт.

40

ND091070-2841

LEVER,ADJUST

SN: 16494-UP

1шт.

|40

ND091070-2840

LEVER,ADJUST

SN: 10592-16493

1шт.

41

ND091070-2851

LEVER,ADJUST

SN: 16494-UP

1шт.

|41

ND091070-2850

LEVER,ADJUST

SN: 10592-16493

1шт.

42

ND091041-0420

SPRING,RETURN

SN: 10592-UP

1шт.

43

ND90200-06241

WASHER

SN: 10592-UP

1шт.

44

ND90400-02151

PIN,SPLIT

SN: 10592-UP

1шт.

45

ND090918-2390

SPRING

SN: 10592-UP

1шт.

46

ND090991-0010

PLUG

SN: 10592-UP

1шт.

47

ND090251-0010

WASHER

SN: 10592-UP

2шт.

48

ND949053-0140

NUT

SN: 10592-UP

1шт.

49

ND949180-0060

SCREW

SN: 10592-UP

1шт.

50

ND091006-0180

SCREW,ADJUST

SN: 10592-UP

1шт.

51

ND090923-0070

NUT

SN: 10592-UP

1шт.

52

ND090032-0080

CAP

SN: 10592-UP

1шт.

53

ND091016-0221

BUSHING

SN: 10592-UP

2шт.

54

ND091048-0160

LEVER SUB ASS'Y

SN: 10592-UP

1шт.

55

ND090992-0431

SPRING,SPEED CONTROL

SN: 10592-UP

1шт.

56

ND090892-0011

BUSHING

SN: 10592-UP

1шт.

57

ND090892-0040

BUSHING

SN: 10592-UP

1шт.

58

ND091094-0010

CAP

SN: 10592-UP

1шт.

59

ND949071-0090

WASHER,SNAP

SN: 10592-UP

2шт.

60

ND949140-6230

O-RING

SN: 10592-UP

2шт.

61

ND090975-1340

ARM,SPRING

SN: 16494-UP

1шт.

62

ND091546-0010

SHIM

SN: 10592-UP

2шт.

63

ND091071-0941

LEVER,ADJUST

SN: 10592-UP

1шт.

64

ND091041-0710

SPRING SUB ASS'Y,RETURN

SN: 16494-UP

1шт.

65

ND090821-0080

STOPPER

SN: 10592-UP

1шт.

66

ND091049-0330

COLLAR

SN: 10592-UP

1шт.

67

ND090917-0090

SEAT¤ 1.0MM

SN: 10592-UP

-2шт.

|67

ND090917-0100

SEAT¤ 1.05MM

SN: 10592-UP

-2шт.

|67

ND090917-0110

SEAT¤ 1.1MM

SN: 10592-UP

-2шт.

|67

ND090917-0120

SEAT¤ 1.15MM

SN: 10592-UP

-2шт.

|67

ND090917-0130

SEAT¤ 1.2MM

SN: 10592-UP

-2шт.

|67

ND090917-0140

SEAT¤ 1.25MM

SN: 10592-UP

-2шт.

|67

ND090917-0150

SEAT¤ 1.3MM

SN: 10592-UP

-2шт.

|67

ND090917-0160

SEAT¤ 1.35MM

SN: 10592-UP

-2шт.

|67

ND090917-0170

SEAT¤ 1.4MM

SN: 10592-UP

-2шт.

|67

ND090917-0180

SEAT¤ 1.45MM

SN: 10592-UP

-2шт.

|67

ND090917-0190

SEAT¤ 1.5MM

SN: 10592-UP

-2шт.

|67

ND090917-0200

SEAT¤ 1.55MM

SN: 10592-UP

-2шт.

|67

ND090917-0210

SEAT¤ 1.6MM

SN: 10592-UP

-2шт.

68

ND091546-0080

SHIM¤ 0.1MM

SN: 10592-UP

-2шт.

|68

ND091546-0040

SHIM¤ 0.25MM

SN: 10592-UP

-2шт.

|68

ND091546-0030

SHIM¤ 0.3MM

SN: 10592-UP

-2шт.

|68

ND091546-0050

SHIM¤ 1.0MM

SN: 10592-UP

-2шт.

69

ND949046-1940

BOLT

SN: 10592-UP

8шт.

70

ND949013-6520

WASHER¤ 1.0MM

SN: 10592-UP

8шт.
