Запчасти Komatsu SA6D140-1B-G ТОПЛ. НАСОС (РЕГУЛЯТОР) (/) (ВНУТР. ЧАСТИ)(№898-) ДВИГАТЕЛЬ

|$1

6212-71-1214

INJECTION PUMP A.

SN: 20888-UP

1шт.

|$2

0

INJECTION PUMP A.

SN: 18980-20887

1шт.

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.A4010-B4B2 T0 A4010-H4B2.

-1шт.

|$6

ND090800-9883

GOVERNOR ASS'Y

SN: 18980-UP

1шт.

|$$5

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-D4B2 TO A4010-F4B2.

-1шт.

1

ND090810-0450

HOUSING SUB ASS'Y

SN: 18980-UP

1шт.

2

ND091016-0020

BUSHING

SN: 18980-UP

1шт.

3

ND090119-0030

GASKET

SN: 18980-UP

1шт.

4

ND091159-0100

ARM SUB ASS'Y

SN: 18980-UP

1шт.

5

ND090823-0141

GASKET

SN: 18980-UP

1шт.

6

ND091284-0080

SCREW

SN: 18980-UP

1шт.

7

ND90160-06051

NUT

SN: 18980-UP

1шт.

8

ND192650-0060

LEVER SUB ASS'Y

SN: 18980-UP

1шт.

9

ND949015-0500

WASHER, 2.5MM,SPRING

SN: 18980-UP

1шт.

10

ND090844-0010

NUT

SN: 18980-UP

1шт.

11

ND090840-0681

FLYWEIGHT ASS'Y

SN: 18980-UP

1шт.

12

ND091340-0070

BUSHING,CAMSHAFT

SN: 18980-UP

1шт.

13

ND091349-0062

WASHER

SN: 18980-UP

1шт.

14

ND091337-0140

DAMPER

SN: 18980-UP

4шт.

15

ND949070-0850

RING,SNAP

SN: 18980-UP

1шт.

16

ND091331-0260

SHIM, 0.75MM

SN: 18980-UP

-2шт.

16

ND091331-0270

SHIM, 0.80MM

SN: 18980-UP

-2шт.

16

ND091331-0280

SHIM, 0.85MM

SN: 18980-UP

-2шт.

16

ND091331-0290

SHIM, 0.90MM

SN: 18980-UP

-2шт.

16

ND091331-0300

SHIM, 0.95MM

SN: 18980-UP

-2шт.

16

ND091331-0310

SHIM, 1.00MM

SN: 18980-UP

-2шт.

16

ND091331-0320

SHIM, 1.05MM

SN: 18980-UP

-2шт.

16

ND091331-0330

SHIM, 1.10MM

SN: 18980-UP

-2шт.

17

ND091042-1050

SPRING,RETURN

SN: 18980-UP

1шт.

18

ND091042-0690

SPRING,RETURN

SN: 18980-UP

1шт.

19

ND091098-1740

STOPPER

SN: 18980-UP

1шт.

20

ND090993-0180

SPRING,START

SN: 18980-UP

1шт.

21

ND949140-6170

O-RING

SN: 18980-UP

1шт.

22

ND090919-0380

ADAPTER

SN: 18980-UP

1шт.

|$37

ND090929-0210

CONTROL LEVER A.

SN: 18980-UP

1шт.

23

ND090920-0270

CONTROL LEVER SET

SN: 18980-UP

1шт.

|$39

ND090930-0580

LEVER ASS'Y,CONTROL

SN: 18980-UP

1шт.

24

ND090970-0230

SHACKLE

SN: 18980-UP

1шт.

25

ND090940-0380

LEVER SUB ASS'Y

SN: 18980-UP

1шт.

26

ND90577-05000

E-RING

SN: 18980-UP

1шт.

27

ND949013-3960

WASHER, 0.2MM

SN: 18980-UP

1шт.

28

ND090983-0191

PIN,CONNECTING

SN: 18980-UP

1шт.

29

ND90577-05000

E-RING

SN: 18980-UP

3шт.

30

ND949013-3950

WASHER, 0.1MM

SN: 18980-UP

-2шт.

30

ND949013-3960

WASHER, 0.2MM

SN: 18980-UP

-2шт.

31

ND091436-0230

LEVER SUB ASS'Y,FLOATING

SN: 18980-UP

1шт.

32

ND090861-0010

SLEEVE,GOVERNOR

SN: 18980-UP

1шт.

33

ND949100-0010

BEARING,BALL

SN: 18980-UP

1шт.

34

ND090989-0051

SHAFT

SN: 18980-UP

1шт.

35

ND949013-1960

WASHER, 0.1MM

SN: 18980-UP

-2шт.

35

ND949013-1970

WASHER, 0.2MM

SN: 18980-UP

-2шт.

35

ND949013-1980

WASHER, 0.5MM

SN: 18980-UP

-2шт.

35

ND949013-2220

WASHER, 0.5MM

SN: 18980-UP

-2шт.

36

ND090959-0301

GUIDE LEVER ASS'Y

SN: 18980-UP

1шт.

37

ND949053-0140

NUT

SN: 18980-UP

1шт.

38

ND091035-0183

SHAFT,GOVERNOR

SN: 18980-UP

1шт.

39

ND090821-0080

STOPPER,ADJUST

SN: 18980-UP

1шт.

40

ND949013-4090

WASHER, 0.1MM

SN: 18980-UP

-2шт.

40

ND949013-4060

WASHER, 0.2MM

SN: 18980-UP

-2шт.

40

ND949013-4070

WASHER, 0.3MM

SN: 18980-UP

-2шт.

40

ND949013-4080

WASHER, 0.4MM

SN: 18980-UP

-2шт.

40

ND949013-4100

WASHER, 1.0MM

SN: 18980-UP

-2шт.

41

ND949013-5890

WASHER, 1.0MM

SN: 18980-UP

-2шт.

41

ND949011-3240

WASHER, 1.2MM

SN: 18980-UP

-2шт.

41

ND949011-3250

WASHER, 1.4MM

SN: 18980-UP

-2шт.

41

ND949011-3260

WASHER, 1.6MM

SN: 18980-UP

-2шт.

41

ND949011-3270

WASHER, 1.8MM

SN: 18980-UP

-2шт.

41

ND949011-3280

WASHER, 2.0MM

SN: 18980-UP

-2шт.
