Запчасти Komatsu SA6D110-1W КОМПРЕССОР АКСЕССУАРЫ

|$0

6138-81-3112

AIR COMPRESSOR ASS'Y

SN: 61375-UP

1шт.

|$1

0

AIR COMPRESSOR ASS'Y

SN: 54110-61374

1шт.

|$$3

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

1

DK487000-1200

CASE,CRANK

SN: 54110-UP

1шт.

2

DK487001-2500

CYLINDER

SN: 54110-UP

1шт.

3

DK010110-2570

BOLT

SN: 54110-UP

8шт.

4

DK014011-0140

WASHER

SN: 54110-UP

4шт.

5

DK014111-0440

WASHER,SPRING

SN: 54110-UP

8шт.

6

DK487003-3200

COVER,BEARING

SN: 54110-UP

1шт.

7

DK029622-8060

SEAL,OIL

SN: 54110-UP

1шт.

8

DK010006-1670

BOLT

SN: 54110-UP

5шт.

9

DK014110-6440

WASHER,SPRING

SN: 54110-UP

5шт.

10

DK487008-5900

CRANKSHAFT

SN: 54110-UP

1шт.

11

DK035620-6000

BEARING

SN: 54110-UP

2шт.

12

DK487009-0400

PISTON

SN: 54110-UP

1шт.

13

DK487010-3320

RING KIT,PISTON

SN: 54110-UP

1шт.

14

DK487012-1100

PIN,PISTON

SN: 61375-UP

1шт.

14

0

PIN,PISTON

SN: 54110-61374

1шт.

15

DK016110-1610

RING,SNAP

SN: 54110-UP

2шт.

16

DK487013-2920

CONNECTING ROD A.

SN: 61375-UP

1шт.

16

0

CONNECTING ROD A.

SN: 54110-61374

1шт.

17

DK487014-0600

METAL,CRANK PIN

SN: 54110-UP

2шт.

18

DK487018-2020

HEAD,CYLINDER

SN: 54110-UP

1шт.

19

DK487028-1100

GUIDE,INTAKE VALVE

SN: 54110-UP

1шт.

20

DK487027-0300

SPRING,INTAKE VALVE

SN: 54110-UP

1шт.

21

DK487026-0800

VALVE,INLET

SN: 54110-UP

1шт.

22

DK487025-0400

SEAT,INTAKE VALVE

SN: 54110-UP

1шт.

23

DK487021-2420

UNLOADER VALVE A.

SN: 54110-UP

1шт.

24

DK487030-1420

DELIVERY VALVE A.

SN: 54110-UP

1шт.

25

DK029332-2100

GASKET

SN: 54110-UP

1шт.

26

DK487020-0400

GASKET

SN: 54110-UP

1шт.

27

DK487046-0101

STUD

SN: 54110-UP

2шт.

28

DK487007-0400

ADAPTER

SN: 54110-UP

1шт.

|$0

6138-81-3112

AIR COMPRESSOR ASS'Y

SN: 61375-UP

1шт.

|$1

0

AIR COMPRESSOR ASS'Y

SN: 54110-61374

1шт.

|$$3

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

1

DK487000-1200

CASE,CRANK

SN: 54110-UP

1шт.

2

DK487001-2500

CYLINDER

SN: 54110-UP

1шт.

3

DK010110-2570

BOLT

SN: 54110-UP

8шт.

4

DK014011-0140

WASHER

SN: 54110-UP

4шт.

5

DK014111-0440

WASHER,SPRING

SN: 54110-UP

8шт.

6

DK487003-3200

COVER,BEARING

SN: 54110-UP

1шт.

7

DK029622-8060

SEAL,OIL

SN: 54110-UP

1шт.

8

DK010006-1670

BOLT

SN: 54110-UP

5шт.

9

DK014110-6440

WASHER,SPRING

SN: 54110-UP

5шт.

10

DK487008-5900

CRANKSHAFT

SN: 54110-UP

1шт.

11

DK035620-6000

BEARING

SN: 54110-UP

2шт.

12

DK487009-0400

PISTON

SN: 54110-UP

1шт.

13

DK487010-3320

RING KIT,PISTON

SN: 54110-UP

1шт.

14

DK487012-1100

PIN,PISTON

SN: 61375-UP

1шт.

14

0

PIN,PISTON

SN: 54110-61374

1шт.

15

DK016110-1610

RING,SNAP

SN: 54110-UP

2шт.

16

DK487013-2920

CONNECTING ROD A.

SN: 61375-UP

1шт.

16

0

CONNECTING ROD A.

SN: 54110-61374

1шт.

17

DK487014-0600

METAL,CRANK PIN

SN: 54110-UP

2шт.

18

DK487018-2020

HEAD,CYLINDER

SN: 54110-UP

1шт.

19

DK487028-1100

GUIDE,INTAKE VALVE

SN: 54110-UP

1шт.

20

DK487027-0300

SPRING,INTAKE VALVE

SN: 54110-UP

1шт.

21

DK487026-0800

VALVE,INLET

SN: 54110-UP

1шт.

22

DK487025-0400

SEAT,INTAKE VALVE

SN: 54110-UP

1шт.

23

DK487021-2420

UNLOADER VALVE A.

SN: 54110-UP

1шт.

24

DK487030-1420

DELIVERY VALVE A.

SN: 54110-UP

1шт.

25

DK029332-2100

GASKET

SN: 54110-UP

1шт.

26

DK487020-0400

GASKET

SN: 54110-UP

1шт.

27

DK487046-0101

STUD

SN: 54110-UP

2шт.

28

DK487007-0400

ADAPTER

SN: 54110-UP

1шт.
