Запчасти Komatsu SA6D110-1U ТОПЛ. НАСОС (РЕГУЛЯТОР) (/) ТОПЛИВН. СИСТЕМА

|$0

6138-72-1321

INJECTION PUMP ASS'Y

SN: 56994-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0452,0463,0464,0472,0482 AND 0492.

-1шт.

|$$3

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$3

DK105411-1341

GOVERNOR ASS'Y

SN: 56994-UP

1шт.

|$$5

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0463 AND 0464.

-1шт.

1

DK154011-0100

NUT,LOCK

SN: 56994-UP

1шт.

2

DK154022-5520

COVER ASS'Y

SN: 56994-UP

1шт.

3

DK154316-6600

ADAPTER

SN: 56994-UP

1шт.

4

DK026516-2040

GASKET

SN: 56994-UP

1шт.

5

DK154031-4400

SCREW

SN: 56994-UP

1шт.

6

DK029240-6010

NUT

SN: 56994-UP

1шт.

7

DK154036-0300

PLUG

SN: 56994-UP

1шт.

8

DK020106-5040

BOLT

SN: 56994-UP

6шт.

9

DK154010-0100

SCREW

SN: 56994-UP

1шт.

10

DK154063-5100

COVER

SN: 56994-UP

1шт.

11

DK029020-6210

BOLT

SN: 56994-UP

2шт.

12

DK020006-1640

BOLT

SN: 56994-UP

2шт.

13

DK154150-2700

SPRING,GOVERNOR

SN: 56994-UP

1шт.

14

DK154158-1620

CAPSULE,SPRING

SN: 56994-UP

1шт.

15

DK029201-2140

NUT

SN: 56994-UP

1шт.

16

DK026512-1540

GASKET

SN: 56994-UP

2шт.

17

DK154159-1200

NUT,CAP

SN: 56994-UP

1шт.

18

DK154200-3120

LEVER,SWIVEL

SN: 56994-UP

1шт.

19

DK154204-1900

BUSHING

SN: 56994-UP

2шт.

20

DK029631-8020

O-RING

SN: 56994-UP

2шт.

21

DK016010-1640

RING,SNAP

SN: 56994-UP

2шт.

22

DK139611-0000

SEAL,OIL

SN: 56994-UP

1шт.

23

DK139411-0000

SHIM, 0.40MM

SN: 56994-UP

1шт.

24

DK029311-1090

SHIM, 0.30MM

SN: 56994-UP

-2шт.

25

DK029141-7010

PLUG

SN: 56994-UP

1шт.

26

DK025803-1310

KEY, 13MM,WOODRUFF

SN: 56994-UP

1шт.

27

DK154206-2800

COLLAR

SN: 56994-UP

1шт.

28

DK154237-1100

PIN

SN: 56994-UP

1шт.

29

DK154343-7120

LEVER

SN: 56994-UP

1шт.

30

DK154350-7800

GASKET

SN: 56994-UP

1шт.

31

DK029635-2020

O-RING

SN: 56994-UP

1шт.

32

DK029731-2040

BOLT,EYE

SN: 56994-UP

1шт.

33

DK029341-2140

GASKET

SN: 56994-UP

2шт.

34

DK154400-0520

DIAPHRAGM

SN: 56994-UP

1шт.

35

DK154400-4800

ROD,PUSH

SN: 56994-UP

1шт.

36

DK029330-8050

GASKET

SN: 56994-UP

2шт.

37

DK139308-0700

WASHER,SPRING

SN: 56994-UP

1шт.

38

DK013030-6040

NUT

SN: 56994-UP

1шт.

39

DK026510-1440

GASKET

SN: 56994-UP

1шт.

40

DK154401-2100

BOLT

SN: 56994-UP

1шт.

41

DK154402-5700

SPRING

SN: 56994-UP

1шт.

42

DK154404-5000

COVER

SN: 56994-UP

1шт.

43

DK020106-2540

BOLT

SN: 56994-UP

2шт.

44

DK154034-1900

SCREW

SN: 56994-UP

1шт.

45

DK023040-6040

NUT

SN: 56994-UP

1шт.

46

DK029711-0140

EYE,(FOR SHIPPING)

SN: 56994-UP

1шт.

47

DK029731-0120

BOLT,EYE

SN: 56994-UP

1шт.

48

DK029341-0110

GASKET

SN: 56994-UP

2шт.

49

DK029312-0210

SHIM, 0.2MM

SN: 56994-UP

-2шт.

49

DK029312-0180

SHIM, 0.5MM

SN: 56994-UP

-2шт.

50

DK154035-0320

NUT,CAP

SN: 56994-UP

1шт.

51

DK014110-6440

WASHER,SPRING

SN: 56994-UP

1шт.

52

DK154352-0700

GASKET

SN: 56994-UP

2шт.

53

DK029010-6310

BOLT

SN: 56994-UP

1шт.

54

DK026506-1040

GASKET

SN: 56994-UP

2шт.

55

DK154035-1600

NUT,CAP

SN: 56994-UP

1шт.

56

DK029310-9080

SHIM

SN: 56994-UP

3шт.
