Артикул
Название
Примечание
Количество
|$0
6138-72-1310
INJECTION PUMP ASS'Y
SN: 54110-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 TO 0491.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
1
DK156133-0520
HOLDER,FLYWEIGHT
SN: 54110-UP
1шт.
2
DK156108-6200
FLYWEIGHT
SN: 54110-UP
2шт.
3
DK029310-9030
SHIM, 0.10MM
SN: 54110-UP
-2шт.
3
DK139409-0000
SHIM, 0.15MM
SN: 54110-UP
-2шт.
3
DK029310-9040
SHIM, 0.20MM
SN: 54110-UP
-2шт.
3
DK029310-9010
SHIM, 0.50MM
SN: 54110-UP
-2шт.
3
DK029310-9020
SHIM, 1.00MM
SN: 54110-UP
-2шт.
3
DK029310-9050
SHIM, 1.50MM
SN: 54110-UP
-2шт.
4
DK156104-7600
SPRING,TIMER
SN: 54110-UP
2шт.
5
DK156130-6520
FLANGE
SN: 54110-UP
1шт.
6
DK029622-8010
SEAL,OIL
SN: 54110-UP
1шт.
7
DK156114-1400
CASE
SN: 54110-UP
1шт.
8
DK156117-0100
O-RING
SN: 54110-UP
1шт.
9
DK156116-1920
SEAL,OIL
SN: 54110-UP
1шт.
10
DK131325-0400
NUT
SN: 54110-UP
1шт.
11
DK029321-4010
WASHER,SPRING
SN: 54110-UP
1шт.
12
DK156115-0100
PLUG
SN: 54110-UP
2шт.
13
DK029340-8010
GASKET
SN: 54110-UP
2шт.
|$0
6138-72-1310
INJECTION PUMP ASS'Y
SN: 54110-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 TO 0491.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
1
DK156133-0520
HOLDER,FLYWEIGHT
SN: 54110-UP
1шт.
2
DK156108-6200
FLYWEIGHT
SN: 54110-UP
2шт.
3
DK029310-9030
SHIM, 0.10MM
SN: 54110-UP
-2шт.
3
DK139409-0000
SHIM, 0.15MM
SN: 54110-UP
-2шт.
3
DK029310-9040
SHIM, 0.20MM
SN: 54110-UP
-2шт.
3
DK029310-9010
SHIM, 0.50MM
SN: 54110-UP
-2шт.
3
DK029310-9020
SHIM, 1.00MM
SN: 54110-UP
-2шт.
3
DK029310-9050
SHIM, 1.50MM
SN: 54110-UP
-2шт.
4
DK156104-7600
SPRING,TIMER
SN: 54110-UP
2шт.
5
DK156130-6520
FLANGE
SN: 54110-UP
1шт.
6
DK029622-8010
SEAL,OIL
SN: 54110-UP
1шт.
7
DK156114-1400
CASE
SN: 54110-UP
1шт.
8
DK156117-0100
O-RING
SN: 54110-UP
1шт.
9
DK156116-1920
SEAL,OIL
SN: 54110-UP
1шт.
10
DK131325-0400
NUT
SN: 54110-UP
1шт.
11
DK029321-4010
WASHER,SPRING
SN: 54110-UP
1шт.
12
DK156115-0100
PLUG
SN: 54110-UP
2шт.
13
DK029340-8010
GASKET
SN: 54110-UP
2шт.
Выбрано товаров: 44
