Запчасти Komatsu SA6D110-1P ТОПЛ. НАСОС (СОЕДИНЕНИЕ) ТОПЛИВН. СИСТЕМА

|$0

6138-72-1400

INJECTION PUMP ASS'Y

SN: 50001-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.

-1шт.

|$$3

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$3

DK105662-0870

COUPLING ASS'Y

SN: 50001-UP

1шт.

1

DK156630-0700

COUPLING

SN: 50001-UP

1шт.

2

DK156633-6200

BOLT

SN: 50001-UP

2шт.

3

DK156615-3300

WASHER

SN: 50001-UP

2шт.

4

DK156605-2320

PLATE

SN: 50001-UP

2шт.

5

DK029200-8050

NUT

SN: 50001-UP

2шт.

6

DK156633-6200

BOLT

SN: 50001-UP

4шт.

7

DK156609-7500

COUPLING,CROSS

SN: 50001-UP

1шт.

8

DK156633-6300

BOLT

SN: 50001-UP

2шт.

9

DK156633-1200

BOLT

SN: 50001-UP

1шт.
