Запчасти Komatsu SA6D110-1P ТОПЛ. НАСОС (РЕГУЛЯТОР) (/) ТОПЛИВН. СИСТЕМА

|$0

6138-72-1400

INJECTION PUMP ASS'Y

SN: 50001-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.

-1шт.

|$$3

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$3

DK105410-7262

GOVERNOR ASS'Y

SN: 50001-UP

1шт.

|$$5

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0461 AND 0462.

-1шт.

1

DK154011-0100

NUT,LOCK

SN: 50001-UP

1шт.

2

DK154500-3020

COVER ASS'Y

SN: 50001-UP

1шт.

3

DK154321-0400

BUSHING

SN: 50001-UP

1шт.

4

DK154031-2400

SCREW

SN: 50001-UP

1шт.

5

DK029240-6010

NUT

SN: 50001-UP

1шт.

6

DK154036-0300

PLUG

SN: 50001-UP

1шт.

7

DK020106-5040

BOLT

SN: 50001-UP

2шт.

8

DK154010-0100

SCREW

SN: 50001-UP

1шт.

9

DK020106-3840

BOLT

SN: 50001-UP

4шт.

10

DK154063-1400

COVER

SN: 50001-UP

1шт.

11

DK029020-6210

BOLT

SN: 50001-UP

2шт.

12

DK020006-1640

BOLT

SN: 50001-UP

2шт.

13

DK154150-0100

SPRING

SN: 50001-UP

1шт.

14

DK154158-0820

CAPSULE,SPRING

SN: 50001-UP

1шт.

15

DK154011-1700

NUT

SN: 50001-UP

1шт.

16

DK026512-1540

GASKET

SN: 50001-UP

2шт.

17

DK154159-1200

NUT

SN: 50001-UP

1шт.

18

DK154200-0120

LEVER,SWIVEL

SN: 50001-UP

1шт.

19

DK154204-1900

BUSHING

SN: 50001-UP

2шт.

20

DK029631-8020

O-RING

SN: 50001-UP

2шт.

21

DK016010-1640

RING,SNAP

SN: 50001-UP

2шт.

22

DK139611-0000

SEAL,OIL

SN: 50001-UP

1шт.

23

DK139411-0000

SHIM, 0.40MM

SN: 50001-UP

1шт.

24

DK029311-1090

SHIM, 0.30MM

SN: 50001-UP

-2шт.

25

DK029141-7010

PLUG

SN: 50001-UP

1шт.

26

DK025803-1310

KEY, 13MM,WOODRUFF

SN: 50001-UP

1шт.

27

DK154206-2800

COLLAR

SN: 50001-UP

1шт.

28

DK154206-0200

WASHER, 1.0MM

SN: 50001-UP

-2шт.

29

DK154237-1100

PIN

SN: 50001-UP

1шт.

30

DK154341-6220

LEVER

SN: 50001-UP

1шт.

31

DK154304-9100

LEVER

SN: 50001-UP

1шт.

32

DK020006-1640

BOLT

SN: 50001-UP

1шт.

33

DK029631-0030

O-RING

SN: 50001-UP

1шт.

34

DK154322-0100

CAP

SN: 50001-UP

1шт.

35

DK154327-7300

SPRING

SN: 50001-UP

1шт.

36

DK029311-0520

SHIM, 0.2MM

SN: 50001-UP

-2шт.

36

DK029311-0530

SHIM, 0.25MM

SN: 50001-UP

-2шт.

36

DK029311-0540

SHIM, 0.3MM

SN: 50001-UP

-2шт.

36

DK029311-0550

SHIM, 0.35MM

SN: 50001-UP

-2шт.

36

DK029311-0560

SHIM, 0.4MM

SN: 50001-UP

-2шт.

36

DK029311-0570

SHIM, 0.5MM

SN: 50001-UP

-2шт.

37

DK154350-7800

GASKET

SN: 50001-UP

1шт.

38

DK029635-2020

O-RING

SN: 50001-UP

1шт.

39

DK026506-1040

GASKET

SN: 50001-UP

2шт.

40

DK154035-1600

NUT,CAP

SN: 50001-UP

1шт.
