Запчасти Komatsu SA6D110-1J ТОПЛ. НАСОС (ПОДКАЧИВАЮЩ. НАСОС) ТОПЛИВН. СИСТЕМА

|1

6138-72-1110

INJECTION PUMP ASS'Y

SN: 50202-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451¤0461¤0462¤0471¤0481 AND 0491.

-1шт.

|1

6138-72-1130

INJECTION PUMP ASS'Y,(TUNNEL SPEC.)

SN: 50202-UP

1шт.

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451¤0467¤0468¤0471¤0481 AND 0491.

-1шт.

|$$5

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

DK105210-4690

FEED PUMP ASS'Y

SN: 50202-UP

1шт.

1

DK152051-0020

HOUSING

SN: 50202-UP

1шт.

2

DK152100-1120

PISTON

SN: 50202-UP

1шт.

3

DK152102-1600

SPRING,PISTON

SN: 50202-UP

1шт.

4

DK152105-1500

PLUG

SN: 50202-UP

1шт.

5

DK029332-6030

GASKET

SN: 50202-UP

1шт.

6

DK152111-2920

TAPPET ASS'Y

SN: 50202-UP

1шт.

7

DK152112-0100

ROLLER

SN: 50202-UP

1шт.

8

DK152113-0100

PIN

SN: 50202-UP

1шт.

9

DK152114-0700

GUIDE

SN: 50202-UP

2шт.

10

DK152115-0100

VALVE

SN: 50202-UP

2шт.

11

DK152116-0200

SPRING

SN: 50202-UP

2шт.

12

DK152117-0100

PLUG

SN: 50202-UP

1шт.

13

DK029331-6030

GASKET

SN: 50202-UP

1шт.

14

DK029631-6060

O-RING

SN: 50202-UP

1шт.

15

DK152121-0200

RING,SNAP

SN: 50202-UP

1шт.

16

DK152200-5420

PUMP,PRIMING

SN: 50202-UP

1шт.

17

DK152300-5920

BOLT,EYE

SN: 50202-UP

1шт.

18

DK029731-4680

BOLT,EYE

SN: 50202-UP

1шт.

19

DK029341-4130

GASKET

SN: 50202-UP

4шт.

20

DK152320-0100

COVER

SN: 50202-UP

1шт.

|1

6138-72-1110

INJECTION PUMP ASS'Y

SN: 50202-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451¤0461¤0462¤0471¤0481 AND 0491.

-1шт.

|1

6138-72-1130

INJECTION PUMP ASS'Y,(TUNNEL SPEC.)

SN: 50202-UP

1шт.

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451¤0467¤0468¤0471¤0481 AND 0491.

-1шт.

|$$5

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

DK105210-4690

FEED PUMP ASS'Y

SN: 50202-UP

1шт.

1

DK152051-0020

HOUSING

SN: 50202-UP

1шт.

2

DK152100-1120

PISTON

SN: 50202-UP

1шт.

3

DK152102-1600

SPRING,PISTON

SN: 50202-UP

1шт.

4

DK152105-1500

PLUG

SN: 50202-UP

1шт.

5

DK029332-6030

GASKET

SN: 50202-UP

1шт.

6

DK152111-2920

TAPPET ASS'Y

SN: 50202-UP

1шт.

7

DK152112-0100

ROLLER

SN: 50202-UP

1шт.

8

DK152113-0100

PIN

SN: 50202-UP

1шт.

9

DK152114-0700

GUIDE

SN: 50202-UP

2шт.

10

DK152115-0100

VALVE

SN: 50202-UP

2шт.

11

DK152116-0200

SPRING

SN: 50202-UP

2шт.

12

DK152117-0100

PLUG

SN: 50202-UP

1шт.

13

DK029331-6030

GASKET

SN: 50202-UP

1шт.

14

DK029631-6060

O-RING

SN: 50202-UP

1шт.

15

DK152121-0200

RING,SNAP

SN: 50202-UP

1шт.

16

DK152200-5420

PUMP,PRIMING

SN: 50202-UP

1шт.

17

DK152300-5920

BOLT,EYE

SN: 50202-UP

1шт.

18

DK029731-4680

BOLT,EYE

SN: 50202-UP

1шт.

19

DK029341-4130

GASKET

SN: 50202-UP

4шт.

20

DK152320-0100

COVER

SN: 50202-UP

1шт.
