Запчасти Komatsu SA6D110-1J ТОПЛ. НАСОС (СОЕДИНЕНИЕ) ТОПЛИВН. СИСТЕМА

|1

6138-72-1110

INJECTION PUMP ASS'Y

SN: 50202-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451¤0461¤0462¤0471¤0481 AND 0491.

-1шт.

|1

6138-72-1130

INJECTION PUMP ASS'Y,(TUNNEL SPEC.)

SN: 50202-UP

1шт.

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451¤0467¤0468¤0471¤0481 AND 0491.

-1шт.

|$$5

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

DK105662-0810

COUPLING ASS'Y

SN: 50202-UP

1шт.

1

DK156630-0700

COUPLING

SN: 50202-UP

1шт.

2

DK156633-6200

BOLT

SN: 50202-UP

2шт.

3

DK156615-3300

WASHER,LOCK

SN: 50202-UP

2шт.

4

DK156605-2320

PLATE

SN: 50202-UP

1шт.

5

DK029200-8050

NUT

SN: 50202-UP

2шт.

6

DK156633-0900

BOLT

SN: 50202-UP

2шт.

7

DK156622-1100

BUSHING

SN: 50202-UP

2шт.

8

DK156609-7500

COUPLING,CROSS

SN: 50202-UP

1шт.

9

DK156633-0900

BOLT

SN: 50202-UP

2шт.

10

DK156622-1100

BUSHING

SN: 50202-UP

2шт.

11

DK156605-4620

PLATE

SN: 50202-UP

1шт.

12

DK156633-0900

BOLT

SN: 50202-UP

2шт.

13

DK156615-3800

WASHER

SN: 50202-UP

2шт.

14

DK156633-1200

BOLT

SN: 50202-UP

1шт.

|1

6138-72-1110

INJECTION PUMP ASS'Y

SN: 50202-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451¤0461¤0462¤0471¤0481 AND 0491.

-1шт.

|1

6138-72-1130

INJECTION PUMP ASS'Y,(TUNNEL SPEC.)

SN: 50202-UP

1шт.

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451¤0467¤0468¤0471¤0481 AND 0491.

-1шт.

|$$5

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

DK105662-0810

COUPLING ASS'Y

SN: 50202-UP

1шт.

1

DK156630-0700

COUPLING

SN: 50202-UP

1шт.

2

DK156633-6200

BOLT

SN: 50202-UP

2шт.

3

DK156615-3300

WASHER,LOCK

SN: 50202-UP

2шт.

4

DK156605-2320

PLATE

SN: 50202-UP

1шт.

5

DK029200-8050

NUT

SN: 50202-UP

2шт.

6

DK156633-0900

BOLT

SN: 50202-UP

2шт.

7

DK156622-1100

BUSHING

SN: 50202-UP

2шт.

8

DK156609-7500

COUPLING,CROSS

SN: 50202-UP

1шт.

9

DK156633-0900

BOLT

SN: 50202-UP

2шт.

10

DK156622-1100

BUSHING

SN: 50202-UP

2шт.

11

DK156605-4620

PLATE

SN: 50202-UP

1шт.

12

DK156633-0900

BOLT

SN: 50202-UP

2шт.

13

DK156615-3800

WASHER

SN: 50202-UP

2шт.

14

DK156633-1200

BOLT

SN: 50202-UP

1шт.
